KOA SPEER ELECTRONICS, INC.
SS-219 R6
AHA 12/19/01
Multi Layer Ferrite Chip Beads
Type MCB
1. General
I
Designed to reduce noise at high frequencies
I
Standard EIA Packages: 0402, 0603, 0805, 1206
I
Nickel barrier with solder overcoat for excellent solderability
I
Magnetically shielded
2. 2.1 Dimensions
Table 1
W
H
L
CERTIFIED
Part
0402
L
0.039±0.004
(1.00±0.10)
0.063±0.006
(1.60±0.15)
0.079±0.008
(2.00±0.20)
0.126±0.008
(3.20±0.20)
Dimensions - inches (mm)
W
H
0.020±0.004
(0.50±0.10)
0.031±0.006
(0.80±0.15)
0.049±0.008
(1.25±0.20)
0.063±0.008
(1.60±0.20)
0.020±0.004
(0.50±0.10)
0.031±0.006
(0.80±0.15)
0.035±0.008
(0.90±0.20)
0.043±0.008
(1.10±0.20)
P
0.010±0.004
(0.25±0.10)
0.014±0.006
(0.36±0.15)
0.020±0.010
(0.51±0.25)
0.020±0.010
(0.51±0.25)
Terminations
(metalization
bands)
0603
P
Solder
0805
1206
Nickel
Silver
Metalization
Electrodes
3. Ordering and Specifying Information*
MCB
Type
0603
Size
0402
0603
0805
1206
G
Material
Permability
Code:
F
G
S
L
P
I
TE
Packaging
500
Impedance
J
Tolerance
J:±5%
K:±10%
M:±20%
P:±25%
* Please note: KSE’s part
numbers do not contain
any spaces or hyphens.
TE: 7" Embossed Plastic 2 Significant Figure
T: 7" Paper Tape
+ 1 Multiplier
(0402 size only)
Example: 500 = 50Ω
0402: 10,000 pcs/reel
0603: 4,000 pcs/reel
0805: 4,000 pcs/reel
1206: 3,000 pcs/reel
I
PAGE 1 OF 8
Bradford, PA 16701
USA
I
Bolivar Drive
I
P.O. Box 547
814-362-5536
I
Fax 814-362-8883
I
www.koaspeer.com
KOA SPEER ELECTRONICS, INC.
SS-219 R6
4. Standard Applications
Ordering
Code
MCB0402GT100*
MCB0402GT150*
MCB0402GT700*
MCB0402GT121*
MCB0402GT221*
MCB0402GT601*
MCB0402GT102*
MCB0603GTE300*
MCB0603GTE400*
MCB0603GTE600*
MCB0603GTE750*
MCB0603GTE800*
MCB0603GTE900*
MCB0603GTE101*
MCB0603GTE121*
MCB0603GTE141*
MCB0603GTE151*
MCB0603GTE181*
MCB0603GTE221*
MCB0603GTE301*
MCB0603GTE421*
MCB0603GTE601*
MCB0603GTE102*
MCB0603GTE152*
MCB0603GTE182*
MCB0603GTE202*
MCB0603STE180*
MCB0603STE121*
MCB0603STE141*
Impedance
@ 100MHz
Ω
10
15
70
120
220
600
1000
30
40
60
75
80
90
100
120
140
150
180
220
300
420
600
1,000
1,500
1,800
2,000
18
120
140
Maximum DC
Resistance
Ω
0.05
0.07
0.4
0.5
0.7
1.1
1.5
0.1
0.1
0.2
0.2
0.2
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.35
0.4
0.45
0.6
0.85
0.95
0.8
0.1
0.4
0.3
Allowable
DC Current
(mA)
500
300
200
200
100
50
50
400
400
300
300
300
250
250
250
250
250
250
250
230
210
210
190
100
50
50
400
200
200
PAGE 2 OF 8
Operating
Temperature
-55°C
to
125°C
T: Paper Tape (0402 size only) TE: Embossed Plastic * Add Tolerance Character (J, K, M, P)
Bolivar Drive
I
P.O. Box 547
I
Bradford, PA 16701
I
USA
I
814-362-5536
I
Fax 814-362-8883
I
www.koaspeer.com
KOA SPEER ELECTRONICS, INC.
SS-219 R6
4. Standard Applications
(continued)
Ordering
Code
MCB0603STE421*
MCB0603STE601*
MCB0603STE721*
MCB0603STE102*
MCB0805FTE050*
MCB0805FTE070*
MCB0805FTE100*
MCB0805FTE110*
MCB0805FTE170*
MCB0805FTE300*
MCB0805FTE400*
MCB0805FTE500*
MCB0805FTE600*
MCB0805FTE750*
MCB0805FTE800*
MCB0805GTE900*
MCB0805GTE101*
MCB0805GTE121*
MCB0805GTE151*
MCB0805GTE181*
MCB0805GTE201*
MCB0805GTE301*
MCB0805GTE401*
MCB0805GTE421*
MCB0805GTE601*
MCB0805GTE751*
MCB0805GTE102*
MCB0805GTE152*
MCB0805GTE182*
Impedance
@ 100MHz
Ω
420
600
720
1,000
5
7
10
11
17
30
40
50
60
75
80
90
100
120
150
180
200
300
400
420
600
750
1,000
1,500
1,800
Maximum DC
Resistance
Ω
0.5
0.65
0.7
0.6
0.07
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.15
0.15
0.15
0.15
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.4
0.55
0.8
Allowable
DC Current
(mA)
200
200
150
50
800
800
800
800
800
800
800
800
800
800
400
400
400
400
200
200
200
200
200
200
200
200
200
200
200
PAGE 3 OF 8
I
Operating
Temperature
-55°C
to
125°C
TE: Embossed Plastic * Add Tolerance Character (J, K, M, P)
Bolivar Drive
I
P.O. Box 547
I
Bradford, PA 16701
I
USA
I
814-362-5536
Fax 814-362-8883
I
www.koaspeer.com
KOA SPEER ELECTRONICS, INC.
SS-219 R6
4. Standard Applications
(continued)
Ordering
Code
MCB0805GTE202*
MCB0805STE272*
MCB0805LTE601*
MCB0805STE180*
MCB0805STE201*
MCB0805STE601*
MCB0805STE751*
MCB0805STE102*
MCB1206FTE190*
MCB1206FTE260*
MCB1206FTE300*
MCB1206FTE310*
MCB1206FTE500*
MCB1206FTE600*
MCB1206FTE700*
MCB1206FTE800*
MCB1206FTE900*
MCB1206FTE101*
MCB1206FTE121*
MCB1206FTE151*
MCB1206FTE201*
MCB1206FTE301*
MCB1206FTE601*
MCB1206GTE102*
MCB1206GTE152*
MCB1206GTE202*
MCB1206STE300*
MCB1206STE181*
MCB1206STE601*
Impedance
@ 100MHz
Ω
2,000
2,700
600
18
200
600
750
1,000
19
26
30
31
50
60
70
80
90
100
120
150
200
300
600
1,000
1,500 @ 50MHz
2,000 @ 30MHz
30
180
600
Maximum DC
Resistance
Ω
0.7
0.8
0.4
0.1
0.4
0.4
0.7
0.75
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.2
0.2
0.2
0.2
0.15
0.3
0.4
0.5
0.7
0.9
0.6
0.1
0.3
0.3
Allowable
DC Current
(mA)
200
200
100
600
200
200
200
100
600
600
600
600
600
600
200
400
400
400
400
300
300
300
200
150
100
100
600
300
200
PAGE 4 OF 8
I
Operating
Temperature
-55°C
to
125°C
TE: Embossed Plastic * Add Tolerance Character (J, K, M, P)
Bolivar Drive
I
P.O. Box 547
I
Bradford, PA 16701
I
USA
I
814-362-5536
Fax 814-362-8883
I
www.koaspeer.com
KOA SPEER ELECTRONICS, INC.
SS-219 R6
5. Characteristics
Item
Operating Temperature
Storage Temperature
Requirement
-55°C ~ +125°C
40°C @ 70% Humidity
Sealed plastic bags with desiccant shall be
used to reduce the potential of oxidation on
the terminations during storage.
Flux:
5-10 sec dip
After Flux:
Air dry for 15 sec
Preheat:
150°C ±10°C
Preheat Time:
60 sec
Solder Temp:
260°C ±5°C
Dip Time:
10 ±1 sec
Flux:
5-10 sec dip
After Flux:
Air dry for 15 sec
Solder Temp:
245°C ±5°C
Dip Time:
5 ±0.5 sec
The bead shall be subjected to the following
5 steps for the period of time shown below.
The 5 steps constitute one (1) rotation.
4 rotations shall be carried out.
1) Flux:
5-10 sec
2) After Flux:
Air dry for 15 sec
3) Solder Temp:
230°C ±5°C
4) Dip Time:
5 ±0.5 sec
5) Cool:
Air cool for 60 seconds
Conditions
Resistance to Solder
Heat
Change in Impedance:
Relative to value before
test ±20%.
Appearance:
There shall be no cracking
Solder Coverage:
More than 75% of the terminal
electrode shall be covered with solder.
Solderability
Solder Coverage:
More than 95% of the
termination shall be covered with solder.
Leach Resistance
Appearance:
There shall be no visible signs of
physical or mechanical damage (i.e. no cracks)
Terminations:
Termination must not be leached
away for more than 5%.
Insulation Resistance
Solvent Resistance
Insulation Resistance:
Min 1G ohms
Change in Impedance:
Relative to value before
test ±10%.
Cleaning by:
Washer:
Ultrasonic washer (100W)
Solvent:
Isopropyl alcohol
Time:
3 minutes
Type
0402
0603
0805
1206
Type
0402
0603
0805
1206
W(kgf)
0.5
1.0
1.5
W(kgf)
1.4
1.8
2.3
Time
N/A
30 sec ±2 sec
30 sec ±2 sec
30 sec ±2 sec
Time
N/A
60 sec
60 sec
60 sec
Terminal Strength
(hanging test)
Appearance:
The terminal electrode shall not
break off, nor shall there be damage to the body.
Terminal Strength
(push test)
Appearance:
There shall be no evidence of
mechanical degradations to terminals or body.
PAGE 5 OF 8
Bolivar Drive
I
P.O. Box 547
I
Bradford, PA 16701
I
USA
I
814-362-5536
I
Fax 814-362-8883
I
www.koaspeer.com
