CCRT-33S7E-T Overview

RF Coaxial Relay

CCRT-33S7E-T Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
ECCN code	EAR99
Relay type	RF COAXIAL RELAY
Base Number Matches	1

Preview

Download Datasheet

View All

Commercial

CCRT-33

Latching

Internal Terminations DC-18GHz SPDT Switch

The CCRT-33 Switch is an internally terminated, broadband, SPDT, electromechanical coaxial

switch designed to switch a microwave signal from a common input to either of two outputs. The

characteristic impedance is 50 Ohms. Internal terminations provide an impedance match for the

unselected port. The switches are small with the minimum spacing that is compatible with SMA

connectors.

The CCRT-33 is available with either a failsafe or latching actuator.

Specifications

RF Contacts:

Actuator

Break before make

Voltage (VDC) 20

Current (mA)

Switching Time:

Terminations:

Connectors:

Weight:

Temperature Range:

Shock:

10 msec max

50 Ohm 2 Watts CW max

SMA (f)

2.65 oz. max

-40

C to +65

C (Operating)

MIL-STD-202 Method 213, Condition D

(500G Non Operating)

Vibration:

MIL-STD-202 Method 214, Condition D

(10G RMS Non Operating)

Humidity:

Typical

Contact Life:

Moisture Seal Available

Million

Cycles

H = 1.75 MAX. STD MODEL

H = 1.86 MAX. TTL MODEL

420 350 200

Insertion Loss Repeatability (1 Million Cycles):

DC to 6 GHz: 0.05 dB

DC to 20 GHz: 0.1 dB

Return Loss

Typical Performance

RF Power Handling (Non-terminated)

3000

800

400

200

Sta

nda

rd S

Power CW (Watts)

nne

cto

0.01

Frequency GHz

18.0

0.0

0.4

0.1

1.0

4.0

Frequency GHz

IL dB

Specifications

VSWR (max)

Insertion Loss (max)

Isolation (min)

DC-6 GHz 6-12 GHz 12-18 GHz

1.25:1

0.20 dB

70.0 dB

1.40:1

0.40 dB

60.0 dB

1.50:1

0.50 dB

60.0 dB

0.01

Frequency GHz

18.0

Specifications subject to change without notice.

www.teledynecoax.com

email: coax@teledyne.com

Tel: (800) 351-7368

10/2007

Isolation dB
