This data sheet contains core information only. Please click here for the full data sheet.
www.murata-ps.com
UWR Models
Single Output, High-Density,
6 Amp/15 Watt DC/DC Converters
Typical units
PR
PRODUCT OVERVIEW
The new 1.2, 1.5V, 1.8V and 2.5V models in
Mu
Murata Power Solutions’ flagship 7-15 Watt
A-Series can source a continuous 6 Amps. This
A-S
is the most "low-voltage" current available from
t
a standard 1" x 2" package, and these power
s
converters exemplify Murata Power Solutions’
con
relentless drive to bring you more power/current,
from standard packages, without compromising
reliability or resorting to thermal specmanship.
By combining a high-frequency, high-effi-
ciency (to 88%), synchronous-rectifier topology
with the newest components and time-tested,
fully automated, SMT-on-pcb construction, these
UWR Models are able to bring you 7-15W (@
up to 6A) in the standard 1" x 2" package from
which most competitors can only get 5-10W (@
3-4A). All UWR’s deliver their full output power
over ambient temperature ranges from –40°C
to as high as +70°C (model and input voltage
dependent) without heat sinks or supplemental
forced-air cooling. Devices derate to +100°C.
Output voltages are 1,2, 1.5, 1.8, 2, 2.5, 3.3, 5,
12 or 15 Volts. Input voltage ranges are 10-18V
(D12 models), 18-36V (D24 models) or 36-75V
(D48 models). All models feature input pi filters,
input undervoltage and overvoltage lockout, input
reverse-polarity protection, output overvoltage
protection, output current limiting, and continuous
short-circuit protection. On/off control and output-
trim functions are optional (see Optional Func-
tions). All models are designed to meet IEC950,
UL1950 and EN60950-1 safety requirements.
D48 models (36-75V inputs) are CE marked.
UWR 7-15W DC/DC’s are packaged in low-
cost, light-weight, diallyl phthalate (UL94V-0
rated) plastic packages with standoffs. EMC
compliance is achieved via a low-noise design
rather than through expensive metal shielding.
FEATURES
1.2-2.5V
OUT
models source 6 Amps
3.3V
OUT
models source 4.25 Amps
5/12/15V
OUT
models deliver full 15 Watts
Synchronous-rectifier topologies
Guaranteed efficiencies to 88%
Choice of 3 input voltage ranges:
10-18V, 18-36V, 36-75V
–40 to +60/70°C ambient w/o derating
Fully isolated (1500Vdc); I/O protected
Designed to meet UL1950/EN60950-1
certification
CE mark (75V
IN
models)
Standard 1" x 2" packages and pinouts
Optional V
OUT
trim and on/off control
Pin compatible with Lucent LC/LW Series
+V
IN
(1)
+V
OUT
(4)
SWITCH
CONTROL
COMMON
(6)
–V
IN
(2)
PWM
CONTROLLER
OPTO
ISOLATION
REFERENCE &
ERROR AMP
TRIM
(5)
(OPTIONAL)
ON/OFF
CONTROL
(3)
(OPTIONAL)
UVLO & OVLO
COMPARATORS
Typical topology is shown.
Figure 1. Simplified Schematic
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com
13 Nov 2009
email: sales@murata-ps.com
MDC_UWR_7-15.F06_short
Page 1 of 2
This data sheet contains core information only. Please click here for the full data sheet.
UWR Models
Single Output, High-Density,
6 Amp/15 Watt DC/DC Converters
Performance Specifications and Ordering Guide
➀
Output
Input
Root Model
➆
UWR-1.2/6000-D12A-C
UWR-1.2/6000-D24A-C
UWR-1.2/6000-D48A-C
UWR-1.5/6000-D12A-C
UWR-1.5/6000-D24A-C
UWR-1.5/6000-D48A-C
UWR-1.8/6000-D12A-C
UWR-1.8/6000-D24A-C
UWR-1.8/6000-D48A-C
UWR-2/6000-D12A-C
UWR-2/6000-D24A-C
UWR-2/6000-D48A-C
UWR-2.5/6000-D12A-C
UWR-2.5/6000-D24A-C
UWR-2.5/6000-D48A-C
UWR-3.3/4250-D12A-C
UWR-3.3/4250-D24A-C
UWR-3.3/4250-D48A-C
UWR-3.3/4500-D48ANT-C
➄
UWR-5/3000-D12A-C
UWR-5/3000-D24A-C
UWR-5/3000-D48A-C
UWR-5/3000-D48ANST-C
➅
UWR-12/1250-D12A-C
UWR-12/1250-D24A-C
UWR-12/1250-D48A-C
UWR-15/1000-D12A-C
UWR-15/1000-D24A-C
UWR-15/1000-D48A-C
V
OUT
(Volts)
1.2
1.2
1.2
1.5
1.5
1.5
1.8
1.8
1.8
2
2
2
2.5
2.5
2.5
3.3
3.3
3.3
3.3
5
5
5
5
12
12
12
15
15
15
I
OUT
(mA)
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
6000
4250
4250
4250
4500
3000
3000
3000
3000
1250
1250
1250
1000
1000
1000
R/N (mVp-p)
➁
Typ.
Max.
40
40
40
30
30
30
30
30
30
30
30
30
30
30
30
85
45
85
85
85
85
85
85
85
85
85
85
85
85
75
75
75
55
55
55
55
55
55
55
55
55
55
50
55
100
70
100
100
100
100
100
100
100
100
100
100
100
100
Regulation (Max.)
Line
Load
➂
±0.2%
±0.05%
±0.2%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.075%
±0.1%
±0.2%
±0.05%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.2%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.25%
±0.5%
±0.5%
±0.15%
±0.5%
±0.5%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
±0.3%
➃
➄
➅
➆
V
IN
Nom.
(Volts)
12
24
48
12
24
48
12
24
48
12
24
48
12
24
48
12
24
48
48
12
24
48
48
12
24
48
12
24
48
Range
(Volts)
10-18
18-36
36-75
10-18
18-36
36-75
10-18
18-36
36-75
10-18
18-36
36-75
10-18
18-36
36-75
10-18
18-36
36-75
36-75
10-18
18-36
36-75
36-75
10-18
18-36
36-75
10-18
18-36
36-75
I
IN
➃
(mA)
80/769
45/375
80/188
75/914
40/454
25/226
70/1084
35/539
25/268
80/1176
55/588
25/291
80/1489
45/727
25/367
80/1375
45/672
35/336
35/356
110/1471
55/710
35/355
35/355
45/1471
45/718
20/359
45/1471
45/718
20/359
Efficiency
Min.
Typ.
76%
78%
78%
77.5%
78%
78.5%
81%
82.5%
83%
83%
83%
84%
83%
84.75%
84%
83%
85%
85%
85%
83%
85.5%
85.5%
85.5%
82.5%
85%
85%
82.5%
85%
85%
78%
80%
80%
79.5%
80%
80.5%
83%
84.5%
85%
85%
85%
86%
86%
86%
86%
86%
87%
87%
87%
85%
88%
88%
88%
85%
87%
87%
85%
87%
87%
Package
(Case,
Pinout)
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
C14, P22
➀
Typical at T
A
= +25°C under nominal line voltage and full-load conditions, unless otherwise noted.
➁
Ripple/Noise (R/N) is tested/speciifed over a 20MHz bandwidth. All models are specified with
two external 0.47µF multi-layer ceramic capacitors located 2-3 inches from the module being
tested.
➂
Load regulation is specified over 10%-100% load conditions. 1.5-5V models are stable and
regulate under no-load conditions. 12/15V models have minimum loading requirements See
Performance/Functional Specifications.
Nominal line voltage, no-load/full-load conditions.
See
page 12.
Special trim version. See Trim Equations, page 5. Quantity order required.
Please refer to the
Part Number Structure
for additional options when ordering.
MECHANICAL SPECIFICATIONS
50.8
2.00
25.4
1.00
For Part Number Structure, please see
page 12.
I/O Connections
Function P22
Pin
Function P22
+Input
4
+Output
–Input
5
Trim*
On/Off Control*
6
Common
SIDE VIEW
5.1 MIN
.20 MIN
12.07
.475
END VIEW
Pin
1
2
3
*Pins 3 and 5 are optional.
See Optional Functions and
Technical Notes for details.
Standard pin length is shown.
Please refer to the Part Number
Structure for special order pin
lengths.
PLASTIC CASE
6X
1.02±0.05
.040±.002
.020 STANDOFF
(4 PLACES)
BOTTOM VIEW
20.32
.800
15.2
.60
4
1
2
3
5
6
10.16
.400
20.32
.800
12.70
.500
7.62
.300
2.5
.10
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
ISO 9001 and 14001 REGISTERED
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2009 Murata Power Solutions, Inc.
www.murata-ps.com/locations
13 Nov 2009
email: sales@murata-ps.com
MDC_UWR_7-15.F06_short
Page 2 of 2
