30-Series General Oscillator Specifications
Typ
Max
48
100
5
-40~+85
15
Deg C
ppm
V
Unit
MHz
Description
Frequency Range
Min
2
Overall Stability (+/-)
Supply Voltage (+/-10%)
20
1.8
Operating Temperature Range
0~70
Capacitive Load on Output
TTL Load on Output
1
50
10
pF
TTL
Supply Current:
5V 2.0-48MHz
3.3V 2.0-48MHz
30
30
mA
mA
4.5
2.97
0.5
0.33
45:55
1
10
10
48:52
%
pS
nS
mS
Tri-State Voltages
N.C
Output Active
>2.2V
Output Active
<0.8V
Output Disabled
(Pin 1 has internal pull up resistor to allow
it to float High)
Output Voltage :
High (5Vdd)
High (3.3Vdd)
Low (5Vdd)
Low (3.3Vdd)
V
V
V
V
Pin Assignments
Pin 1
Tri-State (301-)
Pin 2
Ground
Pin 3
Output
Pin 4
+V DC
Symmetry
Jitter
Rise/Fall time (frequency dependant)
Start up Time
40:60
Options and How to Specify
AEL Crystals Ltd. Reserve the right to amend specifications without notification. Please ensure you have the latest issue
*please contact our Sales Office for further options
AEL30
Pin 1:
1=E/D
Supply voltage:
0=5V, 3=3.3, 2=2.5V, 1=1.8V
Stability* (+/-ppm):
C=100, B=50, A=25
Temperature range:
S=0~+70, I=-40~+85C
e.g. AEL3010AI 30MHz = E/D, 5V, +/-25ppm, -40~+85C, 30MHz
Module "D", Airtech II
Jenner Road, Manor Royal
Crawley RH10 9GA
AEL 30-series oscillator
Contact Sales Office
Contact Sales Office
17/07/2007
TITLE
Part Number
Stock Number
Issue Date
Issue Number
5
Not to be reproduced without permission of AEL Crystals Ltd
