SI4925DYF011: DescriptionPower Field-Effect Transistor, 6A I(D), 30V, 0.032ohm, 2-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, SO-8; CategoryDiscrete semiconductor The transistor; File Size206KB，8 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/

Download Datasheet Parametric View All

SI4925DYF011 Overview

Power Field-Effect Transistor, 6A I(D), 30V, 0.032ohm, 2-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, SO-8

SI4925DYF011 Parametric

Parameter Name	Attribute value
Parts packaging code	SOT
package instruction	SMALL OUTLINE, R-PDSO-G8
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	30 V
Maximum drain current (ID)	6 A
Maximum drain-source on-resistance	0.032 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 code	R-PDSO-G8
Number of components	2
Number of terminals	8
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	P-CHANNEL
Maximum pulsed drain current (IDM)	20 A
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

January 2001

Si4925DY

Dual P-Channel, Logic Level, PowerTrench

MOSFET

General Description

These P-Channel Logic Level MOSFETs are produced

using Fairchild Semiconductor's advanced PowerTrench

process that has been especially tailored to minimize the

on-state resistance and yet maintain low gate charge for

superior switching performance.

These devices are well suited for notebook computer

applications: load switching and power management,

battery charging circuits, and DC/DC conversion.

Features

-6 A, -30 V. R

DS(ON)

= 0.032

Ω

@ V

= -10 V,

DS(ON)

= 0.045

Ω

@ V

= -4.5 V.

Low gate charge (14.5nC typical).

High performance trench technology for extremely low

DS(ON)

High power and current handling capability.

SOT-23

SuperSOT

-6

SuperSOT

-8

SO-8

SOT-223

SOIC-16

SO-8

Absolute Maximum Ratings

Symbol

DSS

GSS

Parameter

Drain-Source Voltage

Gate-Source Voltage

Drain Current - Continuous

- Pulsed

= 25

C unless otherwise noted

Si4925DY

-30

±20

(Note 1a)

Units

-6

-20

Power Dissipation for Dual Operation

Power Dissipation for Single Operation

(Note 1a)

(Note 1b)

(Note 1c)

1.6

0.9

-55 to 150

°C

STG

Operating and Storage Temperature Range

THERMAL CHARACTERISTICS

Thermal Resistance, Junction-to-Ambient

Thermal Resistance, Junction-to-Case

(Note 1a)

(Note 1)

°C/W

Si4925DY Rev.A
