PLL Product Specification
Model:
Customer:
PLL401-1750
SIRENZA
MICRODEVICES, INC.
Rev:
B
AppNote:
Date:
4/17/2003
108
Operating Temperature Range:
( -35 ° to 85 ° C)
Parameter
Frequency Range -
Step Size -
Settling Time - To within 1.0 kHz
Output Power -
Output Phase Noise:
1 kHz
10 kHz
100 kHz
Power Supply -
Supply Current -
Spurious Product - 200 kHz
Reference Feedthrough -
Harmonic Suppression:
2nd Harmonic
3rd Harmonic
Ref Osc Signal:
Frequency
Amplitude
Phase Noise - 1 kHz
Input Impedance
Output Impedance -
Min
1700
Typ
1750
200
4
Max
1800
10
0
Units
MHz
kHz
mSec
dBm
X
X
X
X
Remarks
-6
-3
-70
-93
-113
2.85
3
18
-75
-80
-64
-87
-107
3.15
25
-70
-70
dBc/Hz
dBc/Hz
dBc/Hz
Volts
mA
dBc
dBc
X
X
X
-10
-15
-8
-12
dBc
dBc
X
X
10
0.4
-145
10
50
2
MHz
Vp-p
dBc/Hz
k
Ω
Ω
Package Information
Package Type:
Dimensions:
PLL400
0.6 x 0.6 x 0.14 inches
Drawing Number:
Drawing Revision:
60080
B
Comments
X
Indicates parameter to be tested 100% in production
Performance tests and ratings for Sirenza Microdevices’ products were performed internally by Sirenza and measured using specific computer systems
and/or components and reflect the approximate performance of the the products as measured by those tests. Any difference in circuit implementation, test
software, or test equipment may affect actual performance. The information provided herein is believed to be reliable at press time and Sirenza
Microdevices assumes no responsibility for the use of this information. All such use shall be entirely at the user’s own risk. Prices and specifications for
Sirenza Microdevices’ products are subject to change without notice. Buyers should consult Sirenza Microdevices’ standard terms and conditions of sale
for Sirenza’s limited warranty with regard to its products. These products may be patented or include patented technology. No patent rights or licenses to
any of the circuits described herein are implied or granted to any third party. Sirenza Microdevices does not authorize or warrant any product for use in
life-support devices and/or systems.
Page 1 of 1
Sirenza Microdevices, Inc.
303 S. Technology Ct.
Broomfield, CO 80021
tel 303.327.3030
fax 303.410.7988
