RB521G-30: DescriptionRectifier Diode, Schottky, 1 Element, 0.1A, Silicon, SOD-723, 2 PIN; CategoryDiscrete semiconductor diode; File Size89KB，3 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric View All

RB521G-30 Overview

Rectifier Diode, Schottky, 1 Element, 0.1A, Silicon, SOD-723, 2 PIN

RB521G-30 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	SOD
package instruction	R-PDSO-F2
Contacts	2
Manufacturer packaging code	SOD-723
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	HIGH RELIABILITY
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	R-PDSO-F2
JESD-609 code	e0
Number of components	1
Number of terminals	2
Maximum output current	0.1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Certification status	Not Qualified
surface mount	YES
technology	SCHOTTKY
Terminal surface	TIN LEAD
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	30
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

TM

Micro Commercial Components

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

RB521G-30

Features

•

Case Material:Molded Plastic. UL Flammability

Classificatio Rating 94-0 and MSL Rating 1

Lead Free Finish/RoHS Compliant ("P" Suffix

designates RoHS Compliant. See ordering information)

High Reliability

Low Reverse Current and Low Forward Voltage.

Small Surface Mount Type

Marking : F

100 mA

Schottky Barrier Diode

30 Volts

SOD-723

A

B

Maximum Ratings

Symbol

V

R

I

O

I

FSM

T

J

T

STG

Rating

DC Reverse Voltage

Mean Rectifying Current

Peak Forward Surge Current*

Junction Temperature

Storage Temperature

Rating

30

100

1

125

-40 to +125

Unit

V

mA

A

C

E

Electrical Characteristics @ 25

O

C Unless Otherwise Specified

Symbol

Parameter

Forward Voltage

(I

F

=10mAdc)

Reverse Current

(V

R

=10Vdc)

Min

Typ

Max

Units

F

D

V

F

I

R

---

0.35

10

Vdc

uAdc

DIMENSIONS

INCHES

DIM

A

B

C

D

E

F

MIN

.051

.035

.022

.021

.010

.003

MAX

.059

.043

.026

.014

.006

MIN

1.30

0.90

0.55

0.525

0.25

0.08

MM

MAX

1.50

1.10

0.65

0.35

0.15

NOTE

www.mccsemi.com

Revision: 4

2008/01/30
