THE CONNOR-WINFIELD CORP.
2111 COMPREHENSIVE DRIVE.
AURORA, IL 60505.
FAX
(630) 851-5040.
PHONE (630) 851-4722.
WWW.CONWIN.COM
PRODUCT
D AT A
SHEET
CRYSTAL CONTROLLED OSCILLATORS
3.3V SURFACE MOUNT VCSO OSCILLATOR
ABSOLUTE M AXIMUM RATING S
PARAMETER
Storage Temperature
Supply Voltage
Control Voltage
(Vcc)
(Vc)
UNITS
MINIMUM
-55
-0.5
-0.5
NOMINAL
-
-
-
MAXIMUM
125
7.0
7.0
UNITS
°C
Vdc
Vdc
TABLE 2.0
MINIMUM
(Fo)
NOMINAL
622.08
+/-150
-
3.3
-
-
-
-70
-105
-145
-155
MAXIMUM
UNITS
MHz
ppm
°C
Vdc
mA
ps rms
ps rms
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
1
NOTE
TABLE 1.0
NOTE
CW 0639
VSPLD63TE
622.08M
VSPLD63TE
DESCRIPTION
OPERATING SPECIFIC ATIONS
PARAMETER
Center Frequency
Frequency Stability
Operating Temperature Range
Supply Voltage
Supply Current
Jitter (BW=10Hz to 20MHz)
Jitter (BW=12kHz to 80MHz)
SSB Phase Noise at 100Hz offset
SSB Phase Noise at 1KHz offset
SSB Phase Noise at 10KHz offset
SSB Phase Noise at 100KHz offset
(Vcc)
(Icc)
-
-
-40
3.135
-
-
-
-
-
-
-
-
-
85
3.465
80
3.0
0.5
-
-
-
-
The Connor-Winfield
VSPLD63TE is a 3.3V Voltage
Controlled SAW Oscillator
(VCSO) with Differential LVPECL
outputs and Enable/Disable
function. The VSPLD63TE is
designed for use with PLL
systems in SONET/SDH systems
requiring low jitter and wide pull
range over the industrial
temperature range. No
multiplication schemes are used
in this oscillator design.
FEATURES
VOLTAGE CONTROLLED SAW
OSCILLATOR
LOW PROFILE, SURFACE MOUNT
PACKAGE
3.3V OPERATION
INPUT CHARACTERISTICS
PARAMETER
Control Voltage Range
Absolute Pull Range (APR)
Gain Transfer (Kv)
Monotonic Linearity
Input Impedance
Modulation Bandwidth (3dB)
Enable Input Voltage (Low)
Disable Input Voltage (High)
(Vil)
(Vih)
(Vc)
MINIMUM
0.3
+/-50
-
-15
-
10
-
2.275
NOMINAL
1.65
-
175
-
50K
MAXIMUM
3.0
-
-
15
-
-
1.68
-
UNITS
Vdc
ppm
ppm/volt
%
Ohm
KHz
Vdc
Vdc
TABLE 3.0
NOTE
2
-
-
-
3
3
TABLE 4.0
LOW JITTER <0.5pS RMS
ABSOLUTE PULL RANGE (APR): ±50ppm
LOW VOLTAGE PECL OUTPUT CHARACTERISTICS
PARAMETER
LOAD
Voltage
(High)
(Low)
Duty Cycle at 50% Level
Rise and fall times (Measured 20% to 80%)
(Voh)
(Vol)
MINIMUM
-
2.275
-
45
-
NOMINAL
-
-
-
50
250
MAXIMUM
50
-
1.68
55
400
UNITS
Ohms
Vdc
Vdc
%
ps
NOTE
4
TEMPERATURE RANGE: -40 to 85°C
DIFFERENTIAL LVPECL OUTPUTS
ENABLE / DISABLE FUNCTION
TAPE AND REEL PACKAGING
RoHS 5/6 COMPLIANT
PACKAG E CHARACTERISTICS
Package
TABLE 5.0
Non-hermetic package consisting of an FR4 substrate with grounded metal
cover.
TABLE 6.0
See solder profile page 2.
Ultrasonic cleaning is not recommended.
PROCESS RECOMMENDATIONS
Soldering Process
Wash
Notes
1.0
2.0
3.0
4.0
ORDERING INFORMATION
VSPLD63TE - 622.08MHz
VCSO
SERIES
CENTER
FREQUENCY
I Frequency stability vs. change in temperature, control voltage (Vc) = 1.65 Vdc.
Control voltage for (Fo) = 1.65 Vdc Typical. Positive Transfer Function.
When oscillator is disabled the pin 4 output is in a low state (Vol) and the pin 5 output is in the high state (VoH)
50 ohm termination into Vcc-2V or Thevein equivalent.
Specifications subject to change without notice.
DATA SHEET #:
Vs001
PAGE
1
OF
2
REV:
01
DATE:
9/29/06
a
Copyright 2001 Connor-Winfield all rights reserved.
