EMI/RFI POWER LINE FILTERS
Adam Technologies, Inc.
INLET SOCKET WITH FLANGE MOUNTING
PLF SERIES
.250 x .031
[6.30 x 0.80]
3 PLCS.
ø.138
[3.50]
1.575
[40.00]
1.968
[50.00]
1.181
[30.00]
1.102
[28.00]
.630
[16.00]
.886
[22.50]
1.575 [40.00]
1.122 [28.50]
.236
[6.00]
1.575
[40.00]
2.047
[52.00]
PLF-3DZ2
4.72 [120.00]
ø.138
[3.50]
.807
[20.50]
R.118
[3.0]
RECOMENDED
PANEL CUT-OUT
Recommended Panel Cut-Out
WIRE LEAD OPTION
PART
NUMBER
PLF-1DZ2
PLF-3DZ2
PLF-6DZ2
PLF-10DZ2
RATED
VOLTAGE
250V AC
250V AC
250V AC
250V AC
RATED
CURRENT
1 AMP
3 AMP
6 AMP
10 AMP
GROUND
CAPACITANCE
2.2 nF
3.3 nF
3.3 nF
4.7 nF
LEAKAGE
CURRENT
0.5mA MAX.
0.5mA MAX.
0.5mA MAX.
0.5mA MAX.
LINE
L mH
L
Cy
Cx
Cy
N
L mH
CIRCUIT DIAGRAM
N
G
L
Medical r ade available, PLF-XDZW2
G
Insertion Loss in dB (Measured in 50Ω systems, as IEC / cispr No. 17)
PLF-1DZ2
PLF-1DZ2
100
90
80
Attenuation (dB)
Attenuation (dB)
Attenuation (dB)
PLF-3DZ2
PLF-3DZ2
100
90
80
70
60
50
40
30
20
10
0
0.15 0.2
DM
0.4 0.6
1
2
4 6 8 10
Frequency (MHz)
20 30
CM
70
60
50
40
30
20
10
0
0.15 0.2
DM
CM
0.4 0.6
1
2
4 6 8 10
Frequency (MHz)
20 30
PLF-6DZ2
PLF-6DZ2
100
90
80
Attenuation (dB)
PLF-10DZ2
PLF-10DZ2
100
90
80
70
60
50
40
30
20
10
0
0.15 0.2
CM
DM
70
60
50
40
30
20
10
0
0.15 0.2
DM
0.4 0.6
1
2
4 6 8 10
Frequency (MHz)
20 30
CM
0.4 0.6
1
2
4 6 8 10
Frequency (MHz)
20 30
LOAD
909 Rahway Avenue
•
Union, New Jersey 07083
•
T: 908-687-5000
•
F: 908-687-5710
•
WWW.ADAM-TECH.COM
167
