8
6
revision for dwg #
1PB-2ALFxLB-yyy
rev
ch.no.
-
11/2/2007
1
3
2
6
-
description
original design
date
revised by
Philipp E.
max. 6 mm
[.25 in]
61 mm
[2.4 in]
85 mm
[3.4 in]
7
5
4
19.00 mm
[.7 in]
Up to
four
switch contacts can be installed.
* = Selector Switch is supplied with mounting bracket, bulb holder
and LED (ITEM 1,2,3,4 and 5)
** = Switch Contacts must be ordered separatly
ITEM DESCRIPTION
max. 6 mm
[.25 in]
37 mm
[1.5 in]
50 mm
[2.0 in]
74 mm
[2.9 in]
98 mm
[3.9 in]
For maintained action use Cat. No.
2PPM (ITEM 7)
yyy
=
Voltage
012
=
12V AC/DC
024
=
24V AC/DC
048
=
48V AC/DC
110
=
110V AC/DC
230
=
230V AC
230D
=
230V DC
titel
R
CAT. NO.
2ALF1LB-yyy
2ALF3LB-yyy
LED Illuminated Metal
2ALF4LB-yyy
1* Selector Switch (Flush,
2ALF5LB-yyy
Momentary)
2ALF6LB-yyy
2ALF7LB-yyy
2ALF8LB-yyy
2* Mounting Bracket
2BRK
3* LED Bulb
MCB9xyyy
4* Mounting Bracket Screws
incl. in 2BRK
5* Blub Holder
2LHB
6 Panel
-
7 Maintained Action mechanisim 2PPM
S1
S2
8** Switch Contacts
S3
S4
COLOR
MIN. QTY. MAX. QTY.
White
1
1
Green
1
1
Red
1
1
Amber
1
1
Blue
1
1
Clear
1
1
Yellow
1
1
-
1
1
-
1
1
-
2
2
-
1
1
-
-
-
Black
1
1
Green
1
4
Red
1
4
Green/Black
1
4
Red/Black
1
4
unless otherwise specified:
all dimensions are in millimeters
third angle projection
This Drawing is the property of
22 mm LED Illuminated Metal Flush Momentary Operator
2ALFxLB-yyy (x=color, yyy=voltage)
11/2/2007
11/2/2007
11/2/2007
drawing no.:
tolerance
XX
XX.X
XX.XX
ALL
=
=
=
=
±
0.5 mm
±
0.2 mm
−
mm
±
1 mm
28.90 mm
[1.1 in]
37 mm
[1.5 in]
rev.:
35 Royal Road
Flemington, NJ 08822-6000
(908) 806-9400
Fax (908) 806-9490
1PB-2ALFxLB-yyy
-
M
E
T
R
I
C
and is a confidential
disclosurelent without
consideration other than the
borrower’s agreement that it
shall not be reproduced,
copied, lent or disposed of
directly or indirectly nor
used for any purpose other
than that for which it is
specifically furnished.
drawn by:
Philipp Ernstberger
checked by:
Laszlo Gyorgypal
released by:
Laszlo Gyorgypal
scale:
-
sheet:
1
of:
1
