Surface Mount
Power Splitter/Combiner
2 Way-0° 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-40°C to 85°C
-65°C to 150°C
0.75W max.
0.375W max.
SP-2W+
3300 to 3800 MHz
•
•
•
•
•
Features
Permanent damage may occur if any of these limits are exceeded.
low insertion loss, 0.5 dB typ.
good isolation, 25 dB typ.
good output VSWR, 1.1:1 typ.
small size
aqueous washable
CASE STYLE: CA531
PRICE: $ 0.96 ea. QTY (20)
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
and Reel
Available Tape cost
at no extra
Pin Connections
SUM PORT
PORT 1
PORT 2
GROUND
5
1
3
2,4,6
Applications
• WIMAX
• defense radar
• fixed satellite service
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
Typ.
3300-3800
25
Min.
16
Reel Size
7”
Devices/Reel
20, 50, 100, 200, 500,1000
Electrical Specifications
INSERTION LOSS (dB)
ABOVE 3.0 dB
Typ.
0.5
Max.
0.9
Outline Drawing
PC B L and Patter n
PHASE
UNBALANCE
(Degrees)
Max.
7
AMPLITUDE
UNBALANCE
(dB)
Max.
0.2
S-Port
Typ.
1.2
VSWR
(:1)
Output Ports
Typ.
1.1
Typical Performance Data
Frequency
(MHz)
Suggested L ayout,
T olerance to be within ±.002
Total Loss
1
(dB)
S-2
S-1
3.42
3.42
3.42
3.42
3.42
3.43
3.44
3.45
3.46
3.48
3.50
3.52
3.54
3.56
3.58
SP-2W+
TOTAL LOSS
Amplitude
Unbalance
(dB)
0.02
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.01
0.02
0.02
0.03
0.02
0.03
0.03
Isolation
(dB)
16.77
19.60
21.04
21.84
22.72
24.72
27.06
29.80
31.45
30.44
27.86
25.44
23.37
22.48
21.67
Phase
Unbalance
(deg.)
1.28
1.27
1.26
1.26
1.25
1.24
1.23
1.21
1.19
1.17
1.17
1.16
1.17
1.16
1.15
SP-2W+
ISOLATION
VSWR
S
1.22
1.19
1.18
1.18
1.18
1.18
1.19
1.20
1.22
1.24
1.27
1.30
1.34
1.36
1.38
VSWR
1
1.13
1.07
1.04
1.03
1.02
1.03
1.05
1.08
1.11
1.14
1.17
1.20
1.24
1.25
1.27
VSWR
2
1.14
1.08
1.06
1.04
1.03
1.01
1.02
1.05
1.07
1.10
1.13
1.16
1.19
1.20
1.22
3125.00
3250.00
3300.00
3325.00
3350.00
3400.00
3450.00
3500.00
3550.00
3600.00
3.40
3.41
3.41
3.41
3.41
3.42
3.43
3.44
3.45
3.46
3.48
3.49
3.52
3.53
3.54
Outline Dimensions (
inch
)
mm
A
.052
1.32
K
.083
2.11
B
.067
1.70
L
.033
0.84
C
.106
2.69
M
.042
1.07
D
.122
3.10
N
.012
0.30
E
.035
0.89
P
.020
0.51
F
.064
1.63
Q
.012
0.30
G
.087
2.21
R
.006
0.15
H
.118
3.00
J
.067
1.70
3650.00
3700.00
3750.00
3775.00
3800.00
1. Total Loss = Insertion Loss + 3dB splitter loss.
S
wt
.018 grams
0.46
0.020
TOTAL LOSS (dB)
3.60
ISOLATION (dB)
33
3.55
3.50
3.45
3.40
3.35
3200
S-1
S-2
30
27
24
21
18
15
3200
3300
3400
3500
3600
3700
3800
Demo Board MCL P/N: TB-374
Suggested PCB Layout (PL-232)
3300
3400
3500
3600
3700
3800
FREQUENCY (MHz)
FREQUENCY (MHz)
SP-2W+
VSWR
1.50
1.40
VSWR (:1)
1.30
1.20
1.10
1.00
3200
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
3300
3400
3500
3600
3700
3800
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M127604
ED-12593/5+
SP-2W+
RS/LC/CP/AM
120509
