480W Three-Phase Industrial DIN Rail Power Supply
F ea tures :
PST-480 Series
T hree-P ha s e AC 340 ~ 5 50V w ide r a nge i nput
High e fficiency 8 9% a nd low dis s ipa tion
P rotections :S hort circuit/O ver loa d/O ver v olta ge/O ver tempera ture
C ooling by f ree a ir c onvection
B uilt-in c ons ta nt current limiting c ircuit
C a n be i ns ta lled on D IN r a il T S -35/7.5 o r 1 5
U L 5 08(indus tria l c ontrol e quipment)a pproved
E N61000-6-2(E N50082-2) i ndus tria l immunity l evel
100% f ull loa d burn-in tes t
3 y ea rs w a rra nty
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
VOLTAGE ADJ . R ANGE
LINE R EGULATION
LOAD REGULATION
SETUP, R ISE, HOLD TIME
VOLTAGE R ANGE
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE C URRENT
OVER L OAD
PROTECTION OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
PST-48024
24V
20A
0 ~ 20A
480W
PST-48048
48V
10A
0 ~ 10A
480W
80mVp-p
48 ~ 55V
1.0%
0.5%
0.5%
8 00ms, 40ms, 35ms/500VAC at full load
4 80 ~ 780VDC
90%
R
RIPPLE & NOISE (max.)
Note.2
80mVp-p
24 ~ 28V
VOLTAGE TOLERANCE
Note.3
1.0%
0.5%
0.5%
1200ms, 40ms, 16ms/400VAC
Three-Phase 340 ~ 550VAC
47 ~ 63Hz
89%
1.7A/400VAC
1 .3A/500VAC
COLD START 50A
<3.5mA / 530VAC
105 ~ 150% rated output power
Protection type :
Constant current limiting, recovers automatically after fault condition is removed
30 ~ 36V
Protection type : Shut down o/p voltage, re-power on to recover
110 5 (TSW) Detect on heatsink of power switch
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
-20 ~ +
70
(Refer to output load derating curve)
20 ~ 90% RH non-condensing
-40 ~ +
85 , 10 ~ 95% RH
0.03%/
(0 ~ 50
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
UL508, EN60950-1 Approved, UL60950-1
I/P-O/P:3KVAC I /P-FG:1.5KVAC O/P-FG:0.5KVAC
59 ~ 66V
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
SAFETY & ISOLATION RESISTANCE
EMI CONDUCTION & RADIATION
Compliance to EN55011 (CISPR11), E N55022 (CISPR22), E N61204-3 Class B
EMC
(Note 4)
HARMONIC CURRENT
EMS IMMUNITY
MTBF
Compliance to EN61000-3-2,-3
Compliance to EN61000-4-2,3,4,5,6,8,1
1, ENV50204, EN61204-3, EN61000-6-2 (EN50082-2) Heavy industry level, criteria
A
91.1Khrs min. MIL-HDBK-217F (25 )
227*125.2*100mm (W*H*D)
2.5Kg; 6pcs/16Kg/1.75CUFT
OTHERS
NOTE
DIMENSION
PACKING
1. A ll parameters N OT s pecially mentioned a re measured a t 400VAC i nput, r ated load a nd 25 of ambient temperature.
2. R ipple & n oise a re measured a t 20MHz o f bandwidth by using a 1 2" twisted pair-wire terminated with a 0 .1uf & 4 7uf parallel capacitor.
3. T olerance : i ncludes s et up tolerance, line regulation a nd load regulation.
4. T he power s upply is c onsidered a c omponent which will be installed into a f inal equipment. T he final equipment must be re-confirmed that it still meets
E MC d irectives.
5. D ual phase operation: d erating of 20% i s r equired.
