BG 1600 SERIES
This
component
is RoHS
compliant
Pb
LED BARGRAPH
6 ELEMENT
1.9x3.9mm
DESCRIPTION
A six element end stackable Array of
1.9x3.9mm LEDs.Colours can be mixed or
elements excluded.Castellations supports
3.25mm thick panel
FEATURES
•
•
•
•
•
6 elements 3.9 x 1.9mm.
End stackable .
3.25mm panel standoff
Red Yellow green mixed
110 Deg Viewing angle
MECHANICAL DATA
CATHODES
ANODES
1.9
3.9
12.25
9.0
3.5
5 PITCHES 1.9
11.40
5.4
BEDFORD OPTO TECHNOLOGY LTD
1,BIGGAR BUSINESS PARK, BIGGAR,LANARKSHIRE, ML12 6FX
Tel: +44 (0) 1899 221221 Fax: +44 (0) 1899 221009
Website: bot.co.uk E-mail: bill@bot.co.uk
ISS A 13.4.06
ABSOLUTE MAXIMUM RATINGS
(Ta = 25
o
C)
This
component
is RoHS
compliant
SUPER
RED
BG 1600
Pb
PARAMETER
BRIGHT
RED
HE
RED
ORANGE
YELLOW
GREEN
UNITS
FORWARD CURRENT
PEAK CURRENT 10% DUTY CYCLE
@ 1KHZ
POWER DISSIPATION
REVERSE VOLTAGE
OPERATING TEMP
STORAGE TEMP
LEAD SOLDERING TEMP
25
130
120
5
30
160
105
5
30
155
100
5
30
160
105
5
-40 C TO +85
o
C
-40 C TO +85
o
C
30
140
105
5
25
140
105
5
mA
mA
mW
Volts
260
o
C FOR 3 SECONDS 2mm FROM BODY
OPTO ELECTRONIC DATA
TYPE NO.
COLOUR
PEAK
WAVELENGTH
nm
700
FORWARD VOLTAGE
[MAX]
VF VOLTS
If mA
2.5
20
LUMINOUS INTENSITY
mcd
MIN
TYP
If mA
0.4
1.0
10
BG1600BR
BRIGHT
RED
HE
RED
SUPER
RED
ORANGE
YELLOW
GREEN
BG1600HER
BG1600SR
627
660
2.5
2.5
20
20
3.0
36
6.0
70
10
20
BG1600 O
BG1600Y
BG1600G
627
590
565
2.5
2.5
2.5
20
20
20
3.0
1.0
1.0
6.0
3.0
4.0
10
10
10
NOTES
VIEWING ANGLE -
110 deg
MIXED COLOUR- Any combination of the above colours within the same package
are available- custom part numbers will be issued to identify.
BEDFORD OPTO TECHNOLOGY LTD
1,BIGGAR BUSINESS PARK, BIGGAR,LANARKSHIRE, ML12 6FX
Tel: +44 (0) 1899 221221 Fax: +44 (0) 1899 221009
Website: bot.co.uk E-mail: bill@bot.co.uk
ISS A 13.4.06
