Datasheet> All Categories > Discrete semiconductor> diode> FBI2M5S2-4

Preview

FBI2M5S2-4: DescriptionBridge Rectifier Diode, 1 Phase, 2A, 1000V V(RRM), Silicon, PLASTIC PACKAGE-4; CategoryDiscrete semiconductor diode; File Size32KB，2 Pages; ManufacturerFagor Electrónica; Environmental Compliance

Download Datasheet Parametric Compare View All

FBI2M5S2-4 Overview

Bridge Rectifier Diode, 1 Phase, 2A, 1000V V(RRM), Silicon, PLASTIC PACKAGE-4

FBI2M5S2-4 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	R-PSFM-T4
Contacts	4
Reach Compliance Code	unknown
Other features	UL RECOGNIZED
Minimum breakdown voltage	500 V
Shell connection	ISOLATED
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
JESD-30 code	R-PSFM-T4
JESD-609 code	e3
Maximum non-repetitive peak forward current	100 A
Number of components	1
Phase	1
Number of terminals	4
Maximum operating temperature	150 °C
Minimum operating temperature	-40 °C
Maximum output current	2 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1000 V
surface mount	NO
Terminal surface	TIN
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

FBI2B5S2.......FBI2M5S2

2. Amp. Glass Passivated Bridge Rectifier

Dimensions in mm.

20

Plastic

Case

3.5

Voltage

100 to 1000 V.

Current

2.0 A.

®

+

1.5

1

+ 0.05

1.5

_

L

5

suffix

–4

1

0.5

• Glass Passivated Junction Chips.

•

UL recognized under component index file

number E130180.

•

Lead and polarity identifications.

•

Case: Molded Plastic.

•

Ideal for printed circuit board (P.C.B.).

•

The plastic material carries U/L recognition 94 V-O.

13.5

7

• Mounting Instructions

•

High temperature soldering guaranteed: 260 ºC – 10 sc.

•

Recommended mounting torque: 8 Kg.cm.

Maximum Ratings, according to IEC publication No. 134

FBI2B

5S2

FBI2D

5S2

200

140

80

FBI2F

5S2

300

210

125

FBI2J

5S2

600

420

250

FBI2L

5S2

900

630

380

FBI2M

5S2

1000

700

500

V

RRM

V

RMS

V

R

I

F(AV)

I

FRM

I

FSM

I

2

t

V

DIS

T

j

T

stg

Peak Recurrent Reverse Voltage (V)

Maximum RMS Voltage (V)

Recommended Input Voltage (V)

Max. Average forward current with heatsink

without heatsink

Recurrent peak forward current

10 ms. peak forward surge current

I

2

t value for fusing (t = 10 ms)

Dielectric strength

(terminals to case, AC 1 min.)

Operating temperature range

Storage temperature range

100

70

40

4.5 A at 65 ºC

2.0 A at 25 ºC

15 A

100 A

50 A

2

sec

1500 V

– 40 to + 150 °C

– 40 to +150 ºC

Electrical Characteristics at Tamb = 25°C

V

F

I

R

th (j-c)

R

th (j-a)

Max. forward voltage drop per element at I

F

=3 A

Max. reverse current per element at V

RRM

MAXIMUM THERMAL RESISTANCE

Junction-Case. With Heatsink.

Junction-Ambient. Without Heatsink.

1.1 V

5 A

12 ºC/W

40 ºC/W

Jan - 00
