FEP16JT, FEPF16JT, FEPB16JT Series
Vishay Semiconductors
formerly General Semiconductor
Dual Ultrafast Plastic Rectifier
Reverse Voltage
50 to 600V
Forward Current
16A
Reverse Recovery Time
35 to 50ns
ITO-220AB (FEPF16JT Series)
0.405 (10.27)
0.383 (9.72)
0.188 (4.77)
0.172 (4.36)
0.110 (2.80)
0.100 (2.54)
TO-220AB (FEP16JT Series)
0.415 (10.54) MAX.
0.154 (3.91)
0.370 (9.40)
0.360 (9.14)
0.148 (3.74)
0.113 (2.87)
0.103 (2.62)
0.145 (3.68)
0.135 (3.43)
0.410 (10.41)
0.390 (9.91)
1
0.160 (4.06)
0.140 (3.56)
PIN
2
3
0.603 (15.32)
0.573 (14.55)
0.560 (14.22)
0.530 (13.46)
0.055 (1.39)
0.045 (1.14)
1
0.140 (3.56)
DIA.
0.130 (3.30)
0.185 (4.70)
0.175 (4.44)
0.600 (15.5)
0.580 (14.5)
PIN
2
3
0.131 (3.39)
DIA.
0.122 (3.08)
0.676 (17.2)
0.646 (16.4)
0.350 (8.89)
0.330 (8.38)
0.191 (4.85)
0.171 (4.35)
0.060 (1.52)
PIN 1
PIN 3
PIN 2
0.635 (16.13)
0.625 (15.87)
0.350 (8.89)
0.330 (8.38)
0.110 (2.80)
0.100 (2.54)
1.148 (29.16)
1.118 (28.40)
0.110 (2.79)
0.100 (2.54)
0.560 (14.22)
0.530 (13.46)
0.105 (2.67)
0.095 (2.41)
0.037 (0.94)
0.027 (0.69)
0.022 (0.55)
0.014 (0.36)
PIN 1
PIN 3
PIN 2
CASE
Dimensions in inches
and (millimeters)
0.022 (0.56)
0.014 (0.36)
0.205 (5.20)
0.195 (4.95)
0.105 (2.67)
0.095 (2.41)
0.104 (2.65)
0.096 (2.45)
0.035 (0.90)
0.028 (0.70)
0.205 (5.20)
0.195 (4.95)
TO-263AB (FEPB16JT Series)
0.411 (10.45)
0.380 (9.65)
0.245 (6.22)
MIN
0.190 (4.83)
0.160 (4.06)
0.055 (1.40)
0.045 (1.14)
0.42
(10.66)
K
0.055 (1.40)
0.047 (1.19)
0.624 (15.85)
1
K
2
0.591(15.00)
0-0.01 (0-0.254)
0.021 (0.53)
0.014 (0.36)
0.037 (0.940)
0.027 (0.686)
0.105 (2.67)
0.022 (0.56)
0.015 (0.38)
0.140 (3.56)
0.205 (5.20)
0.195 (4.95)
0.110 (2.79)
Mounting Pad
Layout
TO-263AB
0.63
(17.02)
0.360 (9.14)
0.33
(8.38)
0.320 (8.13)
0.08
(2.032)
0.24
(6.096)
0.095 (2.41)
0.12
(3.05)
PIN 1
PIN 2
K - HEATSINK
Features
• Plastic package has Underwriters Laboratory
Flammability Classification 94V-0
• Dual recitifier construction, positive centertap
• Glass passivated chip junction
• Low power loss
• High surge current capability
• Low forward voltage, high current capability
• Superfast recovery times for high efficiency
Mechanical Data
Case:
JEDEC TO-220AB, ITO-220AB & TO-263AB
molded plastic body
Terminals:
Plated leads, solderable per
MIL-STD-750, Method 2026
High temperature soldering guaranteed:
250°C/10 seconds at terminals
Polarity:
As marked
Mounting Position:
Any
Mounting Torque:
10 in-lbs maximum
Weight:
0.08 oz., 2.24 g
www.vishay.com
1
Document Number 88596
02-Apr-03
FEP16JT, FEPF16JT, FEPB16JT Series
Vishay Semiconductors
formerly General Semiconductor
Maximum Ratings
Ratings at 25°C ambient temperature unless otherwise specified.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
at T
C
= 100°C
Peak forward surge current
8.3 ms single half sine-wave superimposed
on rated load (JEDEC Method) at T
C
= 100°C per leg
Operating storage and temperature range
RMS Isolation voltage (FEPF) from terminals to
heatsink with t = 1.0 second, RH
≤
30%
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
FEP FEP FEP FEP FEP FEP FEP FEP
16AT 16BT 16CT 16DT 16FT 16GT 16HT 16JT
Unit
V
V
V
A
50
35
50
100 150 200
70
105 140
300 400 500 600
210 280
350 420
100 150 200
16
300 400 500 600
I
FSM
T
J
, T
STG
V
ISOL
200
– 55 to +150
4500
3500
1500
(1)
(2)
(3)
125
A
°C
V
Electrical Characteristics
Parameter
Ratings at 25°C ambient temperature unless otherwise specified.
Symbol
V
F
I
R
t
rr
C
J
FEP FEP FEP FEP FEP FEP FEP FEP
16AT 16BT 16CT 16DT 16FT 16GT 16HT 16JT
Unit
V
µA
Maximum instantaneous forward voltage per leg at 8.0A
Maximum DC reverse current per leg
at rated DC blocking voltage
T
C
= 25°C
T
C
= 100°C
0.95
10
500
35
85
1.30
1.50
Maximum reverse recovery time per leg at
I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A
Typical junction capacitance per leg at 4V, 1MH
z
50
60
ns
pF
Thermal Characteristics
(T
Parameter
C
= 25°C unless otherwise noted)
Symbol
R
ΘJC
FEP
2.2
FEPF
3.1
FEPB
2.2
Unit
°C/W
Typical thermal resistance from junction to case per leg
Notes:
(1) Clip mounting (on case), where lead does not overlap heatsink with 0.110” offset
(2) Clip mounting (on case), where leads do overlap heatsink
(3) Screw mounting with 4-40 screw, where washer diameter is
≤
4.9mm (0.19”)
(4) Pulse test: 300µs pulse width, 1% duty cycle
Ordering Information
Product
FEP16AT - FEP16JT
FEPF16AT - FEPF16JT
FEPB16AT - FEPB16JT
Case
TO-220AB
ITO-220AB
TO-263AB
Package Code
45
45
31
45
81
Package Option
Anti-Static tube, 50/tube, 2K/carton
Anti-Static tube, 50/tube, 2K/carton
13” reel, 800/reel, 4.8K/carton
Anti-Static tube, 50/tube, 2K/carton
Anti-Static 13” reel, 800/reel, 4.8K/carton
www.vishay.com
2
Document Number 88596
02-Apr-03
FEP16JT, FEPF16JT, FEPB16JT Series
Vishay Semiconductors
formerly General Semiconductor
Ratings and
Characteristic Curves
(T
A
= 25°C unless otherwise noted)
Fig. 1 – Forward Current
Derating Curve
20
300
Fig. 2 – Maximum Non-Repetitive Peak
Forward Surge Current
Peak Forward Surge Current (A)
T
C
= 100°C
8.3ms Single Half Sine-Wave
(JEDEC Method)
Resistive or Inductive Load
Average Forward Current (A)
16
250
200
12
150
100
8.0
4.0
50
0
0
0
50
100
150
1
10
100
Case Temperature (°C)
Number of Cycles at 60 H
Z
40
Instantaneous Reverse Leakage Current (µA)
Fig. 3 – Typical Instantaneous
Forward Characteristics Per Leg
Instantaneous Forward Current (A)
T
J
= 125°C
10
Fig. 4 – Typical Reverse
Characteristics Per Leg
100
50 - 400V
500 - 600V
T
J
= 125°C
10
T
J
= 25°C
1
Pulse width = 300µs
1% Duty Cycle
50 - 400V
300 - 400V
500 - 600V
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
1
T
J
= 100°C
T
J
= 25°C
0.1
0.1
0.01
0
20
40
60
80
100
Instantaneous Forward Voltage (V)
Percent of Rated Peak Reverse Voltage (%)
Fig. 5 – Typical Junction Capacitance
Per Leg
1,000
T
J
= 125°C
f = 1.0 MHz
Vsig = 50mVp-p
Junction Capacitance (pF)
100
50 - 400V
500 - 600V
10
0.1
1
10
100
Reverse Voltage (V)
Document Number 88596
02-Apr-03
www.vishay.com
3
