BR5A5: Description1 A, 50 V, SILICON, SIGNAL DIODE, DO-41; CategoryDiscrete semiconductor diode; File Size1MB，2 Pages; ManufacturerEDAL; Websitehttp://www.edal.com/

Download Datasheet Parametric Compare View All

BR5A5 Overview

1 A, 50 V, SILICON, SIGNAL DIODE, DO-41

BR5A5 Parametric

Parameter Name	Attribute value
Maker	EDAL
Parts packaging code	DO-41
package instruction	O-PALF-W2
Contacts	2
Reach Compliance Code	unknow
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V
JEDEC-95 code	DO-41
JESD-30 code	O-PALF-W2
Number of components	1
Number of terminals	2
Maximum operating temperature	75 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	50 V
Maximum reverse recovery time	0.4 µs
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

EDAL

SERIES BR5/BS5/BT5

SILICON FAST RECOVERY 1.0 AMP DIODES

DIM

A

B

C

D

INCHES

MIN.

MAX.

0.028

0.034

0.08

0.107

0.160

0.205

1.0

MILLIMETER

MIN.

MAX.

0.71

0.86

2.03

2.74

4.10

5.20

25.4

Io

1 Amp

@

50

C

Is

60

AMPS

Vf

1.4 max.

v@

1.0 amp

@

25

C

Ir

10 uA max.

@

PIV

@

25

C

STYLE

DO – 41 Plastic

Trr – Recovery Time measured from .5 amp forward to 1 amp reverse to .25 amp

PIV

(VOLTS)

50

100

200

300

400

500

600

700

800

1000

P/N

BR5A5

BR5B5

BR5C5

BR5D5

BR5E5

BR5F5

BR5G5

BR5H5

BR5K5

BR5M5

Trr

NSec

P/N

BS5A5

BS5B5

BS5C5

BS5D5

BS5E5

BS5F5

BS5G5

BS5H5

BS5K5

BS5M5

Trr

NSec

P/N

BT5A5

BT5B5

BT5C5

BT5D5

BT5E5

BT5F5

BT5G5

BT5H5

BT5K5

BT5M5

Trr

NSec

400

500

150

250

50

100

(203) 467-2591 TEL

(203) 469-5928 FAX

Email: Info@edal.com

Internet:http://www.edal.com

EDAL

Industries, inc.

51 Commerce St. East Haven, CT 06512

BR5A5 Related Products

	BR5A5	BR5B5	BR5C5	BR5D5
Description	1 A, 50 V, SILICON, SIGNAL DIODE, DO-41	1 A, 100 V, SILICON, SIGNAL DIODE, DO-41	1 A, 200 V, SILICON, SIGNAL DIODE, DO-41	1 A, 300 V, SILICON, SIGNAL DIODE, DO-41
Maker	EDAL	EDAL	EDAL	EDAL
Parts packaging code	DO-41	DO-41	DO-41	DO-41
package instruction	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Contacts	2	2	2	2
Reach Compliance Code	unknow	unknow	unknow	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99
Shell connection	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	1.4 V	1.4 V	1.4 V	1.4 V
JEDEC-95 code	DO-41	DO-41	DO-41	DO-41
JESD-30 code	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Number of components	1	1	1	1
Number of terminals	2	2	2	2
Maximum operating temperature	75 °C	75 °C	75 °C	75 °C
Maximum output current	1 A	1 A	1 A	1 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	ROUND	ROUND	ROUND
Package form	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	50 V	100 V	200 V	300 V
Maximum reverse recovery time	0.4 µs	0.4 µs	0.4 µs	0.4 µs
surface mount	NO	NO	NO	NO
Terminal form	WIRE	WIRE	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL	AXIAL
