BZT52C2V0T - BZT52C24T
SURFACE MOUNT ZENER DIODE
Features
•
•
•
•
Ultra-Small Surface Mount Package
Flat Lead Package Design for Low Profile and High Power
Dissipation.
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
•
•
•
•
•
•
Case: SOD523
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Band
Terminals: Finish - Matte Tin annealed over Alloy 42 leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.001 grams (approximate)
SOD523
Top View
Ordering Information
(Note 3)
Part Number
(Note 4)
(Type Number)-7*
(Type Number)Q-7
(Type Number)-13*
(Type Number)Q-13*
Notes:
Qualification
Commercial
Automotive
Commercial
Automotive
Case
SOD523
SOD523
SOD523
SOD523
Packaging
3000/Tape & Reel
3000/Tape & Reel
10000/Tape & Reel
10000/Tape & Reel
*For (Type Number), please see the Electrical Characteristics Table. Example: 6.2V Zener = BZT52C6V2T-7.
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com.
3. For packaging details, go to our website at http://www.diodes.com.
4. Dispensed in every other cavity of the tape.
Marking Information
xx
xx = Product Type Marking Code
(See Electrical Characteristics Table)
BZT52C2V0T - BZT52C24T
Document number: DS30502 Rev. 12 - 2
1 of 4
www.diodes.com
January 2012
© Diodes Incorporated
BZT52C2V0T - BZT52C24T
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Forward Voltage
@ I
F
= 10mA
Symbol
V
F
Value
0.9
Unit
V
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient Air (Note 5)
Thermal Resistance, Junction to Case (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
R
θ
JC
T
J,
T
STG
Value
300
417
160
-65 to +150
Unit
mW
°C/W
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Type
Number
Marking
Codes
Zener Voltage Range
(Note 6)
V
Z
@ I
ZT
Nom (V)
Min (V)
2.0
1.91
2.4
2.2
2.7
2.5
3.0
2.8
3.3
3.1
3.6
3.4
3.9
3.7
4.3
4.0
4.7
4.4
5.1
4.8
5.6
5.2
6.2
5.8
6.8
6.4
7.5
7.0
8.2
7.7
9.1
8.5
10
9.4
11
10.4
12
11.4
13
12.4
15
13.8
16
15.3
18
16.8
20
18.8
22
20.8
24
22.8
I
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Maximum Zener Impedance
f = 1kHz
Z
ZT
@ I
ZT
Ω
100
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
600
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
Z
ZK
@ I
ZK
I
ZK
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Maximum
Reverse
Current
(Note 6)
I
R
@ V
R
uA
V
150
1.0
50
1.0
20
1.0
10
1.0
5.0
1.0
5.0
1.0
3.0
1.0
3.0
1.0
3.0
2.0
2.0
2.0
1.0
2.0
3.0
4.0
2.0
4.0
1.0
5.0
0.7
5.0
0.5
6.0
0.2
7.0
0.1
8.0
0.1
8.0
0.1
8.0
0.1
10.5
0.1
11.2
0.1
12.6
0.1
14.0
0.1
15.4
0.1
16.8
Temperature
Coefficient
@ I
ZT
mV/°C
Min
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-2.7
-2
0.4
1.2
2.5
3.2
3.8
4.5
5.4
6.0
7.0
9.2
10.4
12.4
14.4
16.4
18.4
Max
0
0
0
0
0
0
0
0
0.2
1.2
2.5
3.7
4.5
5.3
6.2
7.0
8.0
9.0
10.0
11.0
13.0
14.0
16.0
18.0
20.0
22.0
BZT52C2V0T
BZT52C2V4T
BZT52C2V7T
BZT52C3V0T
BZT52C3V3T
BZT52C3V6T
BZT52C3V9T
BZT52C4V3T
BZT52C4V7T
BZT52C5V1T
BZT52C5V6T
BZT52C6V2T
BZT52C6V8T
BZT52C7V5T
BZT52C8V2T
BZT52C9V1T
BZT52C10T
BZT52C11T
BZT52C12T
BZT52C13T
BZT52C15T
BZT52C16T
BZT52C18T
BZT52C20T
BZT52C22T
BZT52C24T
Notes:
WY
WX
W1
W2
W3
W4
W5
W6
W7
W8
W9
WA
WB
WC
WD
WE
WF
WG
WH
WI
WJ
WK
WL
WM
WN
WO
Max (V)
2.09
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
5. Part mounted on FR-4 PC board, single-sided, 2oz. copper with pad areas 1.92mm
2
.
6. Short duration pulse test used to minimize self-heating effect.
BZT52C2V0T - BZT52C24T
Document number: DS30502 Rev. 12 - 2
2 of 4
www.diodes.com
January 2012
© Diodes Incorporated
BZT52C2V0T - BZT52C24T
Suggested Pad Layout
C
X
Dimensions Value (in mm)
Z
2.3
G
1.1
X
0.8
Y
0.6
C
1.7
Y
G
Z
