1
84
Terminal Strips 1.5 mm
2
/AWG 16,
Pin Spacing 3.5 mm/0.137 in; Series 805
Pin spacing 3.5 mm / 0.137 in
AWG 24 — 16
0.2
— 1.5 mm
2
500 V/4 kV/2
IN
10 A
l
9 — 10 mm / 0.37 in
S
VOLUME 2
Pin spacing 3.5 mm / 0.137 in
AWG 24 — 16
0.2
— 1.5 mm
2
500 V/4 kV/2
IN
10 A
l
9 — 10 mm / 0.37 in
Internal commoning
Internal commoning
For example, the requirement of not routing the
ground (earth) conductors over the board is met
by WAGO through the “internal commoning” of
805 Series terminal strips. This way, custom termi-
nal strips can be commoned to each other and
marked at the factory.
See also page 85.
No. of poles
Item no.
No. of poles
Item no.
Terminal strips,
gray, with push button,
with test slot for test plug Ø 2 mm/0.039 in
2-pole
3-pole
4-pole
5-pole
6-pole
7-pole
8-pole
9-pole
10-pole
11-pole
12-pole
13-pole
14-pole
:
24-pole
805-102
805-103
805-104
805-105
805-106
805-107
805-108
805-109
805-110
805-111
805-112
805-113
805-114
:
805-124
Terminal strips,
gray, with push button,
without test slot
2-pole
3-pole
4-pole
5-pole
6-pole
7-pole
8-pole
9-pole
10-pole
11-pole
12-pole
13-pole
14-pole
:
24-pole
805-302
805-303
805-304
805-305
805-306
805-307
805-308
805-309
805-310
805-311
805-312
805-313
805-314
:
805-324
Push in connection of solid conductors.
Connection and removal of fine-stranded conductors
using push button
Direct printing on request
Other numbers of poles and pin spacings on request
Additional item nos. for colored terminal blocks:
blue
. . . /000-006
orange
. . . /000-012
Test plug,
with cable 500mm/1’7.7’’,
Ø 2 mm/0.079 in, red
210-136
Direct printing on request
Other numbers of poles and pin spacings on request
Additional item nos. for colored terminal blocks:
blue
. . . /000-006
orange
. . . /000-012
Dimensions (in mm)
Testing with test plug Ø 2 mm/0.079 in. Insert the test
plug slightly inclined into the test slot
_>
_>
<__
<__
>
>
___> <
>
<
> <
__> <
__> >< <_
<__
_
___
>
___> <
>
<
> <
__> <
__> >< <_
<__
_
___
>
first solder pin
front side
Diameter of drilled hole: 1.1
-0.1
mm
L = (No. of poles x pin spacing) + 1.5 mm
Diameter of drilled hole: 1.1
-0.1
mm
L = (No. of poles x pin spacing) + 1.5 mm
>
>
<
__< <_
>
<
<
<____________ ___________> <__
<__
__
___
>
<____________ ___________> <__
<__
__
___
>
