High-power-density, an industrial temperature range of -40°C to +100°C and extra features like
On-Off-control are just some of the characteristics of this converter, ideal for highly sophisticated
industrial-designs. The RSO series is available with isolation of 2kV or 3kV by choosing option „/H2“ or
„/H3“. The standard version offers 2:1 input voltage range, while the “Z” version features 4:1 input
voltage range, which includes an input voltage range covering both 5V and 12V supplies.
1 Watt
SIP8
Single & Dual
Output
Selection Guide
Part
Number
RSO-xx3.3S
RSO-xx3.3SZ
RSO-xx05S
RSO-xx05SZ
RSO-xx09S
RSO-xx09SZ
RSO-xx12S
RSO-xx12SZ
RSO-xx15S
RSO-xx15SZ
RSO-xx3.3D
RSO-xx3.3DZ
RSO-xx05D
RSO-xx05DZ
RSO-xx09D
RSO-xx09DZ
RSO-xx12D
RSO-xx12DZ
RSO-xx15D
RSO-xx15DZ
Input
Voltage Range
[VDC]
(1)
4.5-9 , 9-18, 18-36, 36-72
9-36, 18-72
(1)
4.5-9 , 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
9-36, 18-72
(1)
4.5-9 , 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
4.5-9
(1)
, 9-18, 18-36, 36-72
4.5-18
(1,2)
, 9-36, 18-72
Output
Voltage
[VDC]
3.3
5
9
12
15
±3.3
±5
±9
±12
±15
Output
Current
[mA]
300
200
111
83
67
±150
±100
±56
±42
±34
Efficiency
typ.
[%]
68-72
68-70
73-78
74-81
75-78
75-83
77-83
75-83
78-83
68-72
70-74
73-76
77
74-78
74-78
75-80
75-80
75-80
75-80
max. Capacitive
Load
(3)
[µF]
3300
1200
680
680
680
±1500
±470
±470
±330
±330
E224736
UL60950-1 certified
CAN/CSA No. 60950-1-07 certified
IEC/EN60950-1 certified
IEC/EN60601-1 certified
CB Report
Notes:
Note1: Derate to 75% if V
IN
is <5VDC (refer to „Line Derating“ graph on page 2)
Note2: 12V 4:1 input also requires an external 10µF capacitor (refer to „Protection Circuit“ on page 3)
Note3: Maximum capacitive load is defined as the capacitive load that will allow start up in under 1 second
without damage the converter
Model Numbering
RSO- __ __ _ _ /__
nom. Input Voltage
Output Voltage
Single
or
Dual
Notes:
Note4: add „Z“ for 4:1 Input Voltage (12= 4.5-18VDC; 24= 9-36VDC; 48= 18-72VDC)
Note5: add suffix „/H2“ for 2kVDC isolation or
„/H3“
for 3kVDC isolation, without = standard 1kVDC isolation
Ordering Examples:
RSO-0512S:
RSO-0505DZ/H3
RSO-1212SZ/H2
4.5-9Vin
4.5-9Vin
4.5-18Vin
12Vout
±5Vout
12Vout
Single
Dual
Single
2:1 Input Voltage
4:1 Input Voltage
4:1 Input Voltage
1kVDC Isolation
3kVDC Isolation
2kVDC Isolation
ECO-1
Isolation
(5)
2:1 or 4:1 Input
(4)
www.recom-power.com
REV.: 3/2019
RSO-S(D)(Z)
DC/DC Converter
Specifications
(measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
BASIC CHARACTERISTICS
Parameter
2:1 Input
Input Voltage Range
4:1 Input
Series
Condition
5VDC
12VDC
nom Vin=
24VDC
48VDC
12VDC
nom Vin= 24VDC
48VDC
5VDC
12VDC
nom Vin=
24VDC
48VDC
10%
DC-DC ON
DC-DC OFF
DC-DC ON
DC-DC OFF
2:1 Input
4:1 Input
20MHz BW
200kHz
100kHz
open or high impedance
external V
CTRL
= 5-12VDC + 1N4148 and 68W resistor
3mA
10mA
500kHz
800kHz
50mVp-p
6mA
Min.
4.5VDC
(1)
9VDC
18VDC
36VDC
4.5VDC
(1,2)
9VDC
18VDC
Typ.
Max.
9VDC
18VDC
36VDC
72VDC
18VDC
36VDC
72VDC
Quiescent Current
Minimum Load
(6)
ON/OFF CTRL
Input Current of CTRL Pin
Standby Current
Internal Operating Frequency
Output Ripple and Noise
40mA
32mA
25mA
15mA
Notes:
Note6: Operation below 10% load won‘t harm the converter, but specifications may not be met
Efficiency vs. Load
100
90
80
RSO-24xx
Line Derating
100
90
75
80
70
60
50
40
30
5Vout
9Vout
12Vout
15Vout
60
50
40
30
20
10
0
0
10
20
30
40
50
60
Output Load [%]
70
80
90
100
Efficiency [%]
70
20
10
0
4.5
5.0
Output Load [%]
Input Voltage [VDC]
ON/OFF CTRL
+V
in
68Ω
1N4148
+V
out
+V
in
V
CTRL
-V
in
+V
out
CTRL
-V
in
-V
out
DC-DC ON:
Open or high impedance
DC-DC OFF: V
CTRL
=
5-12VDC + 1N4148 and 68W resistor
-V
out
continued on next page
www.recom-power.com
REV.: 3/2019
ECO-2
RSO-S(D)(Z)
DC/DC Converter
Specifications
(measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
+V
in
V
CTRL
-V
in
10kΩ
Q
1
+V
in
+V
out
Series
+V
out
V
CTRL
0
DC-DC ON
DC-DC OFF
-V
in
-V
out
-V
out
REGULATIONS
Parameter
Output Accuracy
Line Regulation
Load Regulation
2:1 Input
4:1 Input
10% to 100% full load
2:1 Input
4:1 Input
Condition
Value
±2.0% typ.
±0.2% max.
±0.5% max.
0.4% max.
0.5% typ.
PROTECTIONS
Parameter
Short Circuit Protection (SCP)
standard without suffix
Isolation Voltage
(7)
/H2 version
/H3 version
Isolation Resistance
standard without suffix
Isolation Capacitance
/H2 and /H3 version
Insulation Grade
2:1 Input
2:1 Input
4:1 Input
2:1 Input
4:1 Input
Single
Dual
Single
Single/Dual
Single/Dual
Type
below 100mW
tested for 1 second
rated for 1 minute
tested for 1 second
rated for 1 minute
tested for 1 second
rated for 1 minute
Value
continuous, auto recovery
1kVDC
500VAC/60Hz
2kVDC
1kVAC/60Hz
3kVDC
1.5kVAC/60Hz
1GW min.
10pF min. / 40pF typ. / 60pF max.
120pF min. / 170pF typ. / 250pF max.
200pF max.
5pF min. / 30pF typ. / 60pF max.
30pF max.
basic (IEC/EN60950-1)
functional (IEC/EN6060-1)
Notes:
Note7: For repeat Hi-Pot testing, reduce the time and/or the test voltage
Note8: Refer to local safety regulations if input over-current protection is also required. Recommended fuse: slow blow type
Protection Circuit
+V
in
F
1
+V
in
C
1
+V
out
+V
out
RSO-12xxSZ(DZ) requires a 10µF MLCC capacitor (C1) on input side
-V
in
-V
out
-V
in
-V
out
ENVIRONMENTAL
Parameter
Operating Temperature Range
Operating Altitude
continued on next page
www.recom-power.com
REV.: 3/2019
ECO-3
Condition
with derating @ free air convection (see graph)
Value
-40°C to +100°C
5000m
RSO-S(D)(Z)
DC/DC Converter
Specifications
(measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
Parameter
Operating Humidity
Pollution Degree
MTBF
according to MIL-HDBK-217F, G.B.
100
90
80
Series
Condition
non-condensing
+25°C
+85°C
Value
95% RH max.
PD2
1685 x 10 hours
254 x 10
3
hours
3
Derating Graph
(@ Chamber and free air convection)
Output Load [%]
70
60
50
40
30
20
10
0
-40
-20
4:1 Input Volatge
2:1 Input Voltage
0
20
40
60
Ambient Temperature [°C]
80
100
75 85
120
SAFETY AND CERTIFICATIONS
Certificate Type (Safety)
Information Technology Equipment, General Requirements for Safety (LVD)
Information Technology Equipment, General Requirements for Safety (CB)
Information Technology Equipment, General Requirements for Safety
Medical Electric Equipment, General Requirements for Safety and
Essential Performance
EAC
RoHS2
Report / File Number
SPCLVD1605077-10
L0339L48-CB-1-B1
E224736-A34-UL
WD-SE-R-180675-A0
RU-AT.AB49.B.09571
Standard
IEC60950-1, 2nd Edition, AM2: 2013
EN60950-1, 2nd Edition, A2:2013
IEC60950-1:2005, 2nd Edition + A2:2013
UL60950-1, 2nd Edition, 2014
CAN/CSA C22.2 No. 60950-1-07
IEC60601-1:2005 + C2:2007 + A1:2012, 3rd Edition
EN60601-1:2006 + A1:2013 + A12:2014
TP TC 004/2011
RoHS 2011/65/EU + AM2015/863
EMC Compliance
Electromagnetic compatibility of multimedia equipment - Emission
requirements
(9)
Condition
with external filter
(see filter suggestion below)
Standard / Criterion
EN55032, Class A
EN55032, Class B
EMC Filtering Suggestions according to EN55032
L
1
+V
in
C
1
+V
in
+V
out
+V
out
Component List Class A
Model
C1
RSO-0505S
RSO-1205S
RSO-2405S
10µF/100V
MLCC
C2
N/A
L1
3.9µH choke
RLS-397
-V
in
-V
in
-V
out
-V
out
RSO-4805S
C
2
Notes:
Note9: Filter suggestions are valid for indicated part numbers only.
For other part numbers, please contact RECOM tech support for advice.
Component List Class B
Model
C1
RSO-0505S
RSO-1205S
RSO-2405S
RSO-4805S
C2
L1
5.6µH choke
RLS-567
12µH choke RLS-126
ECO-4
10µF/100V
2.2nF
MLCC
www.recom-power.com
REV.: 3/2019
RSO-S(D)(Z)
DC/DC Converter
Specifications
(measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
DIMENSION AND PHYSICAL CHARACTERISTICS
Parameter
Material
Dimension (LxWxH)
Weight
Series
Type
case
potting
PCB
Value
non-conductive black plastic, (UL94 V-0)
epoxy, (UL94 V-0)
FR4, (UL94 V-0)
21.8 x 11.1 x 9.2mm
4.7g typ.
Dimension Drawing (mm)
embossed logo
21.8
9.2
Pinning information
Pin #
1
2
3
5
6
7
8
Single
-Vin
+Vin
CTRL
(10)
NC
+Vout
-Vout
NC
(11)
Dual
-Vin
+Vin
CTRL
(10)
NC
+Vout
COM
-Vout
11.1
Marking
0.50
4.10
0.51
+0.10/-0.05
0.25
±0.05
Recommended Footprint Details
1.00 Ø +0.15/-0
3.20
Bottom View
2.54
1 2 3
2.00
5 6 7 8
NC= no connection
Tolerance: xx.x= ±0.5mm
xx.xx= ±0.25mm
1 2 3
7x2.54= 17.78
2.54
Top View
5 6 7 8
Notes:
Note10: This pin provides an Off function which puts the converter into a low power mode. When the pin is ‘high’ the converter is OFF and when
the pin is open the converter is ON. There is no allowed low state for this pin. (refer to „ON/OFF CTRL“ on page 2)
Note11: This pin is used internally. No external connection allowed
PACKAGING INFORMATION
Parameter
Packaging Dimension (LxWxH)
Packaging Quantity
Storage Temperature Range
Storage Humidity
Type
tube
tube
Value
520.0 x 17.0 x 10.0mm
22pcs
-55°C to +125°C
95% RH max.
The product information and specifications may be subject to changes even without prior written notice.The product has been designed for various applications; its suitability lies in the responsibility of each customer. The
products are not authorized for use in safety-critical applications without RECOM’s explicit written consent. A safety-critical application is an application where a failure may reasonably be expected to endanger or cause
loss of life, inflict bodily harm or damage property. The applicant shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized
use of RECOM products in such safety-critical applications.
