SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
2SD1398
DESCRIPTION
·With TO-3PN package
·Built-in damper diode
·High voltage ,high reliability
·High speed switching
APPLICATIONS
·For TV and CRT display horizontal
output applications
PINNING
PIN
1
2
3
Base
Collector;connected to
mounting base
Emitter
Fig.1 simplified outline (TO-3PN) and symbol
DESCRIPTION
Absolute maximum ratings (Ta=25
)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
P
C
T
j
T
stg
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current (DC)
Collector power dissipation
Junction temperature
Storage temperature
T
C
=25
CONDITIONS
Open emitter
Open base
Open collector
VALUE
1500
800
7
5
120
150
-55~150
UNIT
V
V
V
A
W
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
CHARACTERISTICS
Tj=25
unless otherwise specified
PARAMETER
Collector- emitter sustaining voltage
Collector-base breakdown voltage
Emitter-base breakdown voltage
Collector-emitter saturation voltage
Base-emitter saturation voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Transition frequency
Diode forward voltage
CONDITIONS
I
C
=100mA; R
BE
=;
I
C
=5mA; I
E
=0
I
E
=200mA; I
C
=0
I
C
=4A; I
B
=0.8A
I
C
=4A; I
B
=0.8A
V
CB
=800V; I
E
=0
V
EB
=4V; I
C
=0
I
C
=1A ; V
CE
=5V
I
C
=1A ; V
CE
=10V
I
EC
=5A
40
8
MIN
800
1500
7
2SD1398
SYMBOL
V
CEO(SUS)
V
(BR)CBO
V
(BR)EBO
V
CEsat
V
BEsat
I
CBO
I
EBO
h
FE
f
T
V
F
TYP.
MAX
UNIT
V
V
V
5.0
1.5
10
130
V
V
µA
mA
3
2.0
MHz
V
2
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
PACKAGE OUTLINE
2SD1398
Fig.2 outline dimensions (unindicated tolerance:±0.10 mm)
3
