MHz Band Ceramic Resonators (SMD)
PBRV-H/ PBRV-M/ PRQV Series
for Automotive Applications
Features
• Stable oscillation by using fundamental
vibration in all frequencies
• Small & low profile
• Built-in capacitor structure
• Reflow solderable
How to Order (PBRV-H,PBRV-M)
PBRV 15.00 H R 50 Y 000
①
②
③ ④ ⑤ ⑥ ⑦
①
Series (PBRV: Automotive)
②
Frequency (MHz)
③
Type (H, M)
④
Packing R: Tape & Reel
PBRV-H (2000 pcs./ Reel)
PBRV-M (3000 pcs./ Reel)
(Null): Bulk
⑤
Frequency Tolerance at 25
°
C
10
30
50
±
0.1%
±
0.3%
±
0.5%
−
40
°
C to 85
°
C
−
40
°
C to 150
°
C
20
40
70
Y
±
0.2%
±
0.4%
±
0.7%
−
40
°
C to 125
°
C
Applications
• Automotive
• ABS
• ECU
• Air-Bag System
RoHS Compliant
Specifications
Frequency
Frequency Temperature
Series
Range (MHz) Tolerance (25
°
C) Stability
Temperature Range
(
°
C)
Test Circuit
Operating
V
DD
=5.0V
14
⑥
Operating Temperature
X
Z
PBRV-HR
2.0 to 8.0
±
0.50%
±
0.30%
−40
to 125
⑦
Unique Code
8.1 to 20.0
±
0.50%
±
0.10%
−40
to 125
8.0 to 20.0
±
0.50%
±
0.10%
−40
to 125
MC14069UB or MC74HCU04
1
2
3
4
Out
R
f
Resonator
(1)
C
1
(3)
C
2
7
How to Order (PRQV)
PRQV 8.00 C R 50 10 Y 000
①
②
③ ④ ⑤ ⑥ ⑦ ⑧
①
Series (PRQV: Automotive)
②
Frequency (MHz)
③
Type (C)
④
Packing R: Tape & Reel (3000 pcs./ Reel)
(Null): Bulk
Frequency Tolerance at 25
°
C
⑤
30
50
±
0.3%
±
0.5%
40
70
±
0.4%
±
0.7%
PBRV-MR
4.0 to 10.0
±
0.50%
±
0.30%
−40
to 125
10.1 to 20.0
±
0.50%
±
0.50%
−40
to 125
PRQV
8.0 to 20.0
±
0.50%
±
0.50%
−40
to 125
*
Please contact us for products without built-in capacitors.
*
Please contact us for the operating temperature range of
−
40 to 150
°
C.
(2)
PBRV-H Type
R
f
=1MΩ,
C
1
=C
2
=10pF,
30pF
(2.00 to 8.00MHz) IC: MC14069UB
(8.01 to 20.0MHz) IC: MC74HCU04
PBRV-M Type
R
f
=1MΩ,
C
1
=C
2
=10pF,
15pF, 33pF
(4.00 to 8.00MHz) IC: MC14069UB
(8.01 to 20.0MHz) IC: MC74HCU04
PRQV Type
R
f
=1MΩ,
C
1
=C
2
=5pF,
10pF
(8.00 to 20.0MHz) IC: MC74HCU04
* C1, C2 are for Reference.
Note)
• This product includes built-in capacitors, but values may
not be the most appropriate depending on IC’s.
• Evaluation of circuit with IC is necessary. IC circuit match-
ing may be referenced with
1) IC data books
2) List of Recommended circuits in Kyocera website.
• Please contact IC manufacturer or Kyocera when there are
difficulties in finding recommended circuits.
⑥
Built-in Capacitance 10pF: 10 5pF: 05
⑦
Operating Temperature
X
Z
−
40
°
C to 85
°
C
−
40
°
C to 150
°
C
Y
−
40
°
C to 125
°
C
⑧
Unique Code
Dimensions
PBRV-H
(Unit: mm)
PBRV-M
(Unit: mm)
PRQV
(Unit: mm)
XXXX
7.4
6.7
XXX
4.5
4.1
2.0 max.
K
XXX
0.5
3.2
0.4
0.5
3.4
1.6
2.0
1.2 max.
6-R0.2
1
2
3-1.2
3
1
6-R0.45
2
0.4
1.2
1.2
6-0.3
3
0.4
1
0.4
2
0.4
3
3.0
2.5
2.5
1.5
1.5
1.7
1.2
1.2
Standard Tol.:
±0.3
Termination: Ni+Au Flash Plating
Standard Tol.:
±0.2
Termination: Ni+Au Flash Plating
Standard Tol.:
±0.15
Termination: Ni+Sn Plating
1.0 max.
0.6
0.4
1.3
