SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
2SC3505
DESCRIPTION
·With TO-3PN package
·High voltage ,high reliability
·High speed switching
APPLICATIONS
·Switching regulators
·Ultrasonic generators
·High frequency inverters
·General purpose power amplifiers
PINNING
PIN
1
2
3
Base
Collector;connected to
mounting base
Emitter
Fig.1 simplified outline (TO-3PN) and symbol
DESCRIPTION
Absolute maximum ratings (Ta=25 )
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature
T
C
=25
CONDITIONS
Open emitter
Open base
Open collector
VALUE
900
700
10
6
3
80
150
-55~150
UNIT
V
V
V
A
A
W
THERMAL CHARACTERISTICS
SYMBOL
R
th j-a
PARAMETER
Thermal resistance from junction to case
MAX
1.5
UNIT
/W
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
CHARACTERISTICS
Tj=25
unless otherwise specified
PARAMETER
Collector-emitter breakdown voltage
Collector-base breakdown voltage
Collector-emitter saturation voltage
Base-emitter saturation voltage
Collector cut-off current
Emitter cut-off current
DC current gain
CONDITIONS
I
C
=10mA ;I
B
=0
I
C
=1mA ;I
E
=0
I
C
=2A ;I
B
=0.4A
I
C
=2A ;I
B
=0.4A
V
CB
=900V; I
E
=0
V
EB
=10V; I
C
=0
I
C
=2A ; V
CE
=5V
10
MIN
700
900
2SC3505
SYMBOL
V
(BR)CEO
V
(BR)CBO
V
CEsat
V
BEsat
I
CBO
I
EBO
h
FE
TYP.
MAX
UNIT
V
V
0.5
1.2
1.0
1.0
V
V
mA
mA
Switching times
t
on
t
stg
t
f
Turn-on time
Storage time
Fall time
I
C
=3A;I
B1
=0.6A;I
B2
=-1.2A
R
L
=100D,P
W
=20µs
DutyE2%
1.0
5.0
1.0
µs
µs
µs
2
