SMD Wire-wound Chip Inductors
ctparts.com
CT1008HS Series
From 10 nH to 1,000 nH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1008HS-330_
G = ±2%, J = ±5%, K = ±10%, M = ±20%
* M also (all other values are G, J, K only)
Inductance
(nH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
620
680
750
820
910
1000
L Test
Freq.
(MHz)
50
50
50
50
50
50
50
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
Q
Fact.
Min.
60
60
60
60
60
65
65
65
68
68
68
68
62
62
46
48
48
48
48
48
48
48
48
48
48
48
48
44
Q Test
Freq.
(MHz)
500
500
500
350
350
350
350
350
350
350
350
350
350
350
100
100
100
100
100
100
100
100
100
100
100
100
50
50
SRF
Min.
(MHz)
4100
3300
2500
2500
2400
1600
1600
1500
1500
1300
1300
1200
1000
950
850
750
700
600
570
500
450
415
375
375
360
350
330
310
DCR
Max.
(Ω)
Ω
.05
.09
.13
.08
.13
.12
.14
.15
.16
.18
.21
.22
.35
.38
.40
.42
.54
.50
.70
.72
.95
1.2
1.3
1.4
1.5
1.5
2.0
2.1
Rated
DC
(mA)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
750
750
750
750
600
600
550
550
520
420
320
400
370
400
350
340
CT1008HS-100_*
CT1008HS-120_*
CT1008HS-150_*
CT1008HS-180_*
CT1008HS-220_*
CT1008HS-270_
CT1008HS-330_*
CT1008HS-390_*
CT1008HS-470_
CT1008HS-560_
CT1008HS-680_
CT1008HS-820_
CT1008HS-101_
CT1008HS-121_
CT1008HS-151_
CT1008HS-181_
CT1008HS-221_
CT1008HS-271_
CT1008HS-331_
CT1008HS-391_
CT1008HS-471_
CT1008HS-561_
CT1008HS-621_
CT1008HS-681_
CT1008HS-751_
CT1008HS-821_
CT1008HS-911_
CT1008HS-102_
CHARACTERISTICS
Description:
SMD ceramic core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±2%, ±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4286A or
HP4287A at specified frequency
Packaging:
Tape & Reel
Marking:
Reels are marked with inductance code and tolerance
Coated:
Epoxy resin on top of the part to permanently set the coil
Miscellaneous:
Parts are also available with a clear plastic cap.
Other values available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
2.55
0.1
B
Max.
2.38
0.09
C
Max.
2.1
0.08
D
2
0.08
E
0.5
0.02
F
1.43
0.06
PAD LAYOUT
12.14.01
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2003 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL
