SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
2SC4161
DESCRIPTION
·With TO-220F package
·High breakdown voltage.
·High reliability.
·Fast switching speed
APPLICATIONS
·Switching regulator applications
PINNING
PIN
1
2
3
Base
Collector
Emitter
Fig.1 simplified outline (TO-220F) and symbol
DESCRIPTION
Absolute maximum ratings (Ta=25
)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector current-peak
Base current
T
C
=25
P
C
Collector dissipation
2
T
j
T
stg
Junction temperature
Storage temperature
150
-55~150
CONDITIONS
Open emitter
Open base
Open collector
VALUE
500
400
7
7
14
3
30
W
UNIT
V
V
V
A
A
A
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
CHARACTERISTICS
Tj=25
unless otherwise specified
PARAMETER
Collector-emitter breakdown voltage
Collector-base breakdown voltage
Emitter-base breakdown voltage
Collector-emitter saturation voltage
Base-emitter saturation voltage
Collector cut-off current
Emitter cut-off current
DC current gain
DC current gain
DC current gain
Output capacitance
Transition frequency
CONDITIONS
I
C
=5mA ; R
BE
=8
I
C
=1mA ; I
E
=0
I
E
=1mA ; I
C
=0
I
C
=4A ;I
B
=0.8A
I
C
=4A ;I
B
=0.8A
V
CB
=400V; I
E
=0
V
EB
=5V; I
C
=0
I
C
=0.8A ; V
CE
=5V
I
C
=4A ; V
CE
=5V
I
C
=10mA ; V
CE
=5V
I
E
=0; V
CB
=10V;f=1MHz
I
C
=0.8A ; V
CE
=10V
15
10
10
MIN
400
500
7
SYMBOL
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
V
CEsat
V
BEsat
I
CBO
I
EBO
h
FE-1
h
FE-2
h
FE-3
C
OB
f
T
2SC4161
TYP.
MAX
UNIT
V
V
V
0.8
1.5
10
10
50
V
V
µA
µA
80
20
pF
MHz
Switching times
t
on
t
s
t
f
Turn-on time
Storage time
Fall time
I
C
=5A; I
B1
=1A
I
B2
=-2A
V
CC
=200V ,R
L
=40A
0.5
2.5
0.3
µs
µs
µs
h
FE-1
Classifications
L
15-30
M
20-40
N
30-50
2
