Hi-Rel AC/DC PFC MODULE
HGMM-35 : 35W POWER
Hi-Rel
Grade
115 VAC/400Hz Active Power Factor Corrected
Variable Frequency 360-800Hz
Dual Isolated Output
Metallic Case
• AC/DC Isolated Power Factor Corrected Module
• 115 VAC single phase
• Input range : 95 - 140 VAC
• Variable frequency : 360 - 800 Hz
• MIL-STD-704, ABD100 compliant
• Low input current harmonic distorsion < 10%
• Output Power : 35W
• Active inrush current limitation
• Isolation : 1 500 Vrms
• Inhibition function
• RoHS or Leaded process option
1- General
The GAIA Converter HGMM-35 series designates
a family of active power factor corrected AC/DC
isolated modules designed to be compatible with
the latest airborne input bus with single phase
115VAC/400Hz variable frequency.
This module accepts a variable frequency input
from 360 to 800 Hz in the range of 95 to 140Vac
and an active power factor that enables a very
low level of current and voltage harmonic
distorsion over the entire frequency excursion.
The HGMM-35 series is compliant with numereous
avionics/military standards among them with :
• the latest Airbus standards ABD100 :
- permanent input range : 108-122Vac
- transient : 71Vac/15ms - 180Vac/100ms
- variable frequency : 360 - 800 Hz
- power factor : > 0,95
• the international standard DO-160D :
- permanent input range : 100-122Vac
- transient : up to 180Vac/100ms
• the US military standard MIL-STD-704E :
- permanent input range : 108-118Vac
- transient : 80Vac/10ms - 180Vac/100ms
The HGMM-35 series includes a soft start, a per-
manent short circuit protection and an inhibit
fuction.
The soft-start allows current limitation and
eliminates inrush current during start-up. The
short circuit protection completely protects the
module against short-circuits of any duration by
a shut down and restores to normal when the
overload is removed.
The HGMM-35 series includes a model available
with dual 2 x 17 Vdc outputs serialisable/
parallable 17 or 34 Vdc to optimize the use of
hold-up capacitance.
The HGMM-35 series has to be used as front-end
in conjunction with a capacitance for hold-up
and DC/DC modules at the output.
The design has been carried out with
surface mount components and is manufactured
in a fully automated process to guarranty high
quality. Every module is tested with a Gaïa
Converter automated test equipment. The mo-
dules are potted with a bi-component thermal
conductive compound and packaged in a metalic
case to ensure the module’s integrity under high
environmental conditions.
4
2- Product Selection
HGMB - 35 -
input
output
/
option
suffix
Input Voltage Range
Output
W : 95-140 VAC/400 Hz
17 : 2 x 17 VDC
Options :
/T : option for -55°C start up operating temperature
/S : option for screening and serialization
REDEFINING THE SOURCE OF POWER
Suffix :
nothing : RoHS process
-L : leaded process
(available in N. America)
©
Gaia Converter FC05-049.09/17 Revision F
For locations, phone, fax, E-Mail see back cover
HGMM-35 Series
3- Electrical Specifications
Data are valid at +25°C, unless otherwise specified.
Parameter
Input
Full temperature range
between phase and neutral
Permanent input voltage Full temperature range
range (Ui)
between phase and neutral
Full temperature range
Transient input voltage
between phase and neutral
Frequency range
Full temperature range
permanent
Ui min. to max.
Frequency range
Full temperature range
transient
Ui min. to max.
Nominal input voltage
Power Factor (PF)
Total Harmonic
Distorsion (THD)
Individual current
harmonic distorsion
Start up input voltage
Start up time
Inrush current
Input current in short
circuit mode (Average)
No load input current
Current in inhibit mode
Output
Output voltage
Set point accuracy
Output power
Output current
Full temperature range
Ui min. to max.,
Full load
Ambient temperature : +25°C
Ui nominal, 75% load, 400Hz
Full temperature range
Ui min. to max.
Full temperature range
Ui min. to max.
Ui nominal, 400Hz
Full load
with 4.400µF output capacitor
per output BW=20MHz
Ui min. to max., 400Hz
Full load
Ui nominal, 400Hz
25% to full load
Ui nominal, 400Hz
Full load
Ui nominal, 400Hz
Full load
Dual output
Nominal
Isolated
VDC
%
Maximum
Maximum
W
A
Ui nominal
at 400Hz
Ui min. to max.
Ui min. to max.
from 360Hz to 800Hz
Full load with nominal output
Ui min. to max., 400Hz
at full load with resistive load
Ui nominal, 400Hz
Ui nominal, 400Hz
Short-circuit
Ui nominal, 400Hz
No load
Ui nominal, 400Hz
Inhibit
Nominal
Min. - Max.
Min. - Max.
Min. Max.
VAC
VAC
VAC/ms
Hz
Conditions
Limit or
typical
Units
Hi-Rel
Grade
HGMB-35-W-17
115
95 - 140
71 / 15
180 / 100
360 - 800
320 / 0,3
0,99
0,98
0,90
< 10
see page 3
TBD
60
1
TBD
45
30
Transient compliant with
Hz/s
ABD100
At full load
At half load
/
At quarter load
from 50% to full load
%
from 400Hz to 800Hz
on all harmonics
Minimum
Maximum
Nominal
Maximum
Maximum
Maximum
/
VAC
ms
A
mA
mA
mA
4
2 x 17 VDC
+/-4
35
1,05
Ripple output voltage
Maximum
mVpp
200
Line regulation
Load regulation
Efficiency
Maximum admissible
capacitive load
Maximum
Maximum
Typical
Maximum per output
%
%
%
µF
+/-1
+/-4
80
14 000
2
©
Gaia Converter FC05-049.09/17 Revision F
For locations, phone, fax, E-Mail see back cover
HGMM-35 Series
3- Electrical Characteristics (continued)
3-1 Power Factor (PF) Characteristics
The Power Factor (PF) is the ratio of the «real» power to
the apparent power.
The apparent power is the product of the rms volts measured
with one meter and the rms amps measured with another
meter (value in VA).
The «real» power is the time average of the instant product
of voltage and current (value in Watts).
Hi-Rel
Grade
The «real» power cannot be measured directly with 2 meters
as it has to integrate the phase shift between voltage and
current. This phase shift between voltage and current
reduces the effective power delivered.
The Power Factor (PF) is a measure of the effectiveness
with which an AC load can extract the usable power from
an AC source.
Power Factor (PF) versus Load at 115Vac
1,2
1
0,8
Power Factor
F=400Hz
F=800Hz
0,6
0,4
0,2
0
0
5
10
15
20
Load
25
30
35
40
3-2 Total Harmonic Distorsion Factor (THD) Characteristics
The Total Harmonic Distorsion (THD) is the ratio between
the total energy contained in all row harmonic (except
fundamental harmonic) by the fundamental harmonic wave.
The following curves represent the HGMM-35 Total Harmonic
Distorsion Factor at frequency of 400 Hz and at frequency
of 800 Hz.
4
Total Harmonic Distorsion Factor (THD) versus Load at 115Vac
45
40
35
30
THD
25
20
15
10
F=400Hz
F=800Hz
5
0
0
5
10
15
20
Load
25
30
35
40
3-3 Individual Current Harmonic Distorsion Characteristics
The individual current harmonic distorsion requirement is
a very specific requirement defining for each harmonic
row, the maximum admissible current in all functionning
conditions.
This requirement induced the Total Harmonic Distorsion
Factor (THD) defined above.
These requirements are defined by the aircraft
manufacturers in proprietary (and confidential) standards.
GAIA Converter HGMM series comply with individual current
harmonic distorsion requirements of :
• AIRBUS ABD100 section 1.8 with specific limits on :
odd non triplen and odd triplen harmonics
even 2 & 4 and other even harmonics
• BOEING D6-44588 with specific limits on
odd non triplen and odd triplen harmonics
even harmonics
3
Gaia Converter FC05-049.09/17 Revision F
©
For locations, phone, fax, E-Mail see back cover
HGMM-35 Series
4- Switching Frequency
Parameter
Switching frequency
Conditions
Full temperature range
Ui min. to max.
No load to full load
Limit or typical
Nominal, fixed
Specifications
160 KHz
Hi-Rel
Grade
5- Isolation
Parameter
Electric strength test voltage
Isolation resistance
Conditions
Input to output
Input to case
Output to case
500 VDC
Limit or typical
Minimum
Minimum
Minimum
Minimum
Specifications
1 500 VAC / 1 min
1 500 VAC / 1 min
1 500 VAC / 1 min
100 MOhm
6- Protection Functions
Characteristics
Output short circuit protection (SCP)
Output overvoltage protection (OVP)
Protection Device
Hiccup circuitry with
auto-recovery
Zener clamp
Recovery
Automatic
recovery
/
Limit or typical
Permanent
Maximum
Specifications
See section 11
20 VDC
4
7- Reliability Data
Characteristics
Conditions
Ground fixed (Gf)
Mean Time Between Failure (MTBF)
According to MIL-HDBK-217F
Airborne, Inhabited,
Cargo (AIC)
Civilian avionics,
calculators
Temperature
Case at 40°C
Case at 85°C
Case at 40°C
Case at 85°C
Ambient at 55°C
100% time on
Specifications
730 000 Hrs
230 000 Hrs
415 000 Hrs
145 000 Hrs
640 000 Hrs
Mean Time Between Failure (MTBF)
According to IEC-62380-TR
©
4
Gaia Converter FC05-049.09/17 Revision F
For locations, phone, fax, E-Mail see back cover
HGMM-35 Series
8- Electromagnetic Interference
Hi-Rel
Grade
Electromagnetic interference requirements according to DO-160D or MIL-STD-461D/E can be easily achieved as
indicated in the following table with the use of an additionnal external filter as described hereafter.
Standards
Conducted emission (CE) :
Low frequency
High frequency
Conducted susceptibility (CS) :
low frequency
High frequency
Radiated emission (RE) :
Magnetic fireld
Electrical field
Radiated susceptibility (RS) :
Magnetic field
Electrical field
DO-160D
Section 21
MIL-STD-461E
CE 101
CE 102
CS 101
CS114
RE 101
RE 102
RS 101
RS 013
Compliance
compliant module stand alone
compliant with additionnal filter
compliant with additionnal filter
compliant with additionnal filter
compliant module stand alone
compliant module stand alone
compliant module stand alone
compliant module stand alone
Section 20
Section 21
Section 20
L1
L2
C2(*)
1
8
Phase
Vo2
C1
M1
2
Neutral
Go2
7
HGMB35
L3
C3(*)
3 On/Off
Vo1
6
4
Recommended list of components :
L1 ........ : Common mode chole 4.4mH (Epcos B82720S2601N040)
(or API Delevan CM6460-505)
L2, L3 ... : Inductance 1mH (Wurth 74477030)
C1 ......... : Ceramic 1206 33NF/630V capacitors (TDK C3216JB2J333M)
C2, C3 .... : Ceramic 1206 4.7nF/500V capacitors (AVX 1206 7 C 472 M)
M1 ........ : MOV type S14K230 or S20K230 (Epcos)
4
On/off_ref
Go1
5
Fig : D0-160D Conducted Noise Emission
©
5
Gaia Converter FC05-049.09/17 Revision F
For locations, phone, fax, E-Mail see back cover
