ExitPoint™
Directional Sounder
with Voice Messaging
Description
The ExitPoint™ Directional Sounder has an integral audio
amplifier that produces a pulsating sound consisting of
broadband low, mid, and high range sounds. The broad-
band noise makes it possible to determine the location of
the sound. There are four (4) pulse patterns that can be
used to create an egress pathway out of a building and to
mark perimeter exits. In addition to the broadband noise,
the sound is capable of playing an alert message in the
form of a recorded voice message or other audible sig-
nals.
These messages will instruct the occupants of what action
to take as they approach the directional sounder, and will
allow them to react quickly and confidently when the
sounder is activated. Fifteen different language combina-
tions are available to instruct occupants on the direction
they are approaching (for example, provides the location
of an exit, an up stairway, a down stairway, or an area of
refuge. The directional sounder also incorporates an
optional disable feature for use in conjunction with a con-
trol module or heat sensor.
The directional sounder features a number of field select-
able power settings including high, medium-high, medium-
low, and low. It is simple to install with its aesthetic low
profile compact design and contains a flush mount in a
4”x 4” x 2 1/4” backbox.
ExitPoint directional sounders, fitted for normal building
evacuation sounders, also direct people to evacuation
routes when either clear or poor visibility conditions exist.
The directional sounder can be used in a wide range of
building applications. Trials consistently have shown an
improvement of up to 75 percent in evacuation times in
smoke and up to 35 percent without smoke. The 2007
Edition of NFGA 72 now provides the installation and
maintenance guidelines on directional sounders.
Directional Sounder
with Voice Messaing
ExitPoint
Features
•
•
•
•
•
•
•
•
•
Listed to UL Standard 464 (indoor applications only)
Five (5) field-selectable power settings
Four (4) field-selectable routing evacuation patterns
Constructed to be effective in unfamiliar surroundings
or poor visibility
Designed to work in open areas, corridors, or stairs
Fifteen (15) different language selections available
Reduces evacuation times by as much as 75 percent
Optional disable feature for use in conjunction with a
control module or heat sensor
Low profile, compact design
Ordering Information
Part Number
PF24V
Description
ExitPoint Directional Sounder with Voice
Messaging
BBS-SP201W
Surface mount backbox skirt for PF24V
An ISO 9000-2000 Company
SIGNALING
FM
ExitPoint™ is a registered trademark of Honeywell International Inc.
APPROVED
MEA
Approved
S4011 3027815 492-04-E 7135-1653:175
Specifications are for information only, are not intended for installation purposes, and are subject to change without notice. No responsibility is assumed by Gamewell-FCI for their use.
www.gamewell-fci.com
9021-60255 Rev. A page 1 of 3
©2008 Honeywell International Inc. All rights reserved.
12 Clintonville Road, Northford, CT 06472-1610 USA • Tel: (203) 484-7161 • Fax: (203) 484-7118
GAMEWELL-FCI
Specifications
Electrical Specifications
Voltage Input:
Regulated 24 Volts
Operating Voltage Range:
16 to 33 Volts
Operating Temperature:
32 F to 120 F (0 C to 49 C)
Power Setting:
High, medium-high, medium,
medium-low, low
Mechanical Specifications
Input Terminals:
12-24 AWG
Speaker Size:
4” (101 mm)
Grille Size:
4 7/8” (127 mm)
DIP Switch
Position 1
Setting
Off
On
Off
Off
On
Power Setting Guide
DIP Switch
Position 2
Setting
Off
Off
On
Off
On
DIP Switch
Position 3
Setting
Off
Off
Off
On
On
Power
Setting
High
Med-High
Med
Med-Low
Low
Language/Audible Tone Selection Guide
Rotary Switch Selection
Tone/Language
Audible tone/sweep
English
Spanish
French
English/Spanish
English/French
Korean
Cantonese
Mandarin
English/Cantonese
English/Mandarin
Catonese/Mandarin
English/Korean
English/Portuguese
English/Russian
English/Polish
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Additional Tone Selection
Switch
Position 5
Setting
On
On
Off
Off
Switch
Position 6
Setting
On
Off
On
Off
Sound Output
Area of Refuge
Up Stairs
Down Stairs
Exit Here
Enable/Disable Selection
Switch
Position 4
Setting
On
On
Off
Off
Terminals 3 & 4 Sound Output
Open
Closed
Open
Closed
Disabled
Enabled
Enabled
Disabled
12 Clintonville Road, Northford, CT 06472-1610 USA • Tel: (203) 484-7161 • Fax: (203) 484-7118
9021-60255 Rev. A page 2 of 3
