217 SERIES RADIAL LEAD INDUCTORS
Features
Designed for use in EMI filters and telephones
Inductance Range from 0.1µH to 1.5mH
Materials meet UL94V-0
Operating Temp. -40°C to +130°C
(see note below)
Custom Inductance Values Available
ELECTRICAL SPECIFICATIONS AT 25ºC
Part Number
PT21701
PT21702
PT21703
PT21704
PT21705
PT21706
PT21707
PT21708
PT21710
PT21711
PT21712
PT21713
PT21714
PT21715
PT21716
PT21717
PT21718
PT21719
PT21720
PT21731
PT21732
PT21733
PT21734
PT21735
PT21736
PT21737
PT21738
PT21739
PT21740
PT21741
PT21742
PT21743
PT21744
PT21745
PT21746
PT21747
PT21761
PT21762
PT21763
PT21764
PT21765
PT21766
PT21767
PT21768
PT21769
Note:
1.
2.
Full rated current is based on an ambient operating temperature of 85ºC with a 45ºC maximum temperature rise in free air, all
materials are rated at 155ºC or higher.
For non-RoHS parts consult factory for special part numbers.
Inductance
(uH)
1.0 ±20%
1.5 ±20%
2.2 ±20%
3.3 ±20%
4.7 ±20%
6.8 ±20%
10 ±10%
15 ±10%
22 ±10%
33 ±10%
47 ±10%
68 ±10%
100 ±10%
150 ±10%
220 ±10%
330 ±10%
470 ±10%
680 ±10%
1000 ±10%
3.3 ±10%
4.7 ±10%
8.8 ±10%
10 ±10%
15 ±10%
22 ±10%
33 ±10%
47 ±10%
68 ±10%
100 ±10%
150 ±10%
220 ±10%
330 ±10%
470 ±10%
680 ±10%
1000 ±10%
1500 ±10%
1.0 ±10%
1.5 ±10%
2.2 ±10%
3.3 ±10%
4.7 ±10%
6.8 ±10%
10 ±10%
15 ±10%
22 ±10%
Q
Typ
30
“
”
”
”
30
70
60
60
55
45
45
35
50
35
36
55
40
140
25
25
25
60
45
60
45
40
35
30
35
25
30
20
20
50
90
20
20
20
20
20
20
75
70
65
Test
Frequency
(MHz)
7.960
“
”
”
”
7.960
2.520
“
“
2.520
“
“
0.796
“
0.796
“
“
“
0.252
7.960
“
“
2.520
“
2.520
“
“
“
0.796
0.796
“
“
“
“
0.252
“
0.796
“
“
“
“
0.796
2.52
“
“
SRF
Typ
(MHz)
100
78
63
50
41
33
27
21
17
13
11
9.0
7.2
5.7
4.5
3.6
2.9
2.3
1.9
54
50
38
30
24
17
15
13
10
8.2
6.6
5.3
4.2
3.4
2.5
2.3
1.8
150
110
68
59
45
34
26
19
14
DCR
Ohms
(Max)
0.006
0.006
0.010
0.018
0.022
0.028
0.043
0.056
0.086
0.140
0.170
0.260
0.330
0.560
0.720
1.100
1.700
2.300
4.300
0.013
0.017
0.022
0.031
0.042
0.070
0.082
0.130
0.160
0.230
0.400
0.430
0.750
1.000
1.500
2.200
3.500
0.004
0.006
0.006
0.006
0.009
0.012
0.015
0.019
0.026
Rated DC
Current
(A) (Max)
5.00
4.30
3.90
2.90
2.60
2.30
1.90
1.60
1.30
1.00
0.94
0.73
0.67
0.52
0.46
0.37
0.30
0.26
0.19
3.40
3.00
2.60
2.20
1.90
1.50
1.20
1.00
0.97
0.81
0.61
0.52
0.44
0.39
0.32
0.26
0.21
8.40
5.60
5.00
4.50
4.00
3.50
3.20
2.80
2.40
Package
Schematic
A
“
”
”
”
A
“
“
“
A
“
“
”
”
A
“
”
”
”
B
”
”
”
”
B
“
”
”
”
B
“
”
”
”
”
”
C
“
”
”
”
C
“
”
”
DATATRONIC
:
28151 Highway 74, Romoland, CA 92585
Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong Kong Tel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
March 27, 2006
MECHANICAL OUTLINES
A
1
B
D
E
2
SCHEMATIC
C
UL TUBE
F
Dimensions
A
Max
10.0mm
0.393”
B
C
D
Max
8.0mm
0.314”
E
Max
0.70mm
0.027”
F
Ref
1.5mm
0.059”
Package A
12.0-15.0mm
0.472-0.590”
5.0±0.5mm
0.196±0.020”
Package B
10.5mm
0.413”
15.0-20.0mm
0.590-0.787”
5.0±0.5mm
0.196±0.020”
9.5mm
0.374”
0.70mm
0.027”
1.5mm
0.059”
Package C
13.0mm
0.511”
15.0-20.0mm
0.590-0.787”
5.0±0.5mm
0.196±0.020”
10.5mm
0.413”
0.70mm
0.027”
1.5mm
0.059”
DATATRONIC
:
28151 Highway 74, Romoland, CA 92585
Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong Kong Tel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
