M2 Series
5x7 mm, 3.3 Volt, HCMOS/TTL Compatible Output, Clock Oscillator
Features:
•
Leadless Chip Carrier (LCC) package
•
Seam sealed package
•
Tri-state or Standby function options
•
Stabilities to ±20 ppm
•
Fully RoHS 6 compliant
Applications:
•
Microprocessors/Controllers, DSP
•
Gig E, SONET
•
Industrial Controllers
•
Broadband Access
•
Test & Measurement Equipment
PARAMETER
Frequency Range
Operating Temperature
Storage Temperature
Frequency Stability
Aging
st
1 Year
Thereafter (per year)
Input Voltage
Input Current
Electrical Specifications
Symbol
F
T
A
T
S
F/F
Min.
1.5
-55
Max.
Units
135
MHz
(See ordering information)
+125
°C
(See ordering information)
±3
±2
3.3
ppm
ppm
V
mA
mA
mA
mA
µA
Typ.
Condition/Notes
See Note 1
Vdd
Idd
3.0
Standby Current
Output Type
Load
Symmetry (Duty Cycle)
Logic “1” Level
Logic “0” Level
Output Current
Rise/Fall Time
3.6
10
20
30
55
10
Voh
Vol
15/2
PF/TTL
(See ordering information)
90% Vdd
V
Vdd -0.5
V
10% Vdd
V
0.5
V
mA
±4
1.500 to 20.000 MHz
20.001 to 50.000 MHz
50.001 to 67.000
67.001 to 135.000 MHz
“Q” Output Type Only
HCMOS/TTL Compatible
See Note 2
½ Vdd
HCMOS Load
TTL Load
HCMOS Load
TTL Load
Tr/Tf
Standby/Tristate Function
Start up Time
Random Jitter
Mechanical Shock
Vibration
Hermeticity
Thermal Cycle
Solderability
Soldering Conditions
See Note 3
6
ns
1.500 to 50.000 MHz
4
ns
50.001 to 80.000 MHz
2
ns
80.001 to 135.000 MHz
Input Logic “1” or floating: output active
Input Logic “0”; output disables to high-Z
10
ms
Rj
4
10
ps RMS
1-Sigma
Per MIL-STD-202, Method 213, Condition C (100 g’s, 6 mS duration, ½ sinewave)
Per MIL-STD-202, Method 201 & 204 (10 g’s from 10-2000 Hz)
-8
Per MIL-STD-202, Method 112, (1x10 atm. cc/s of Helium)
Per MIL-STD-883, Method 1010, Condition B (-55°C to +125°C, 15 min. dwell, 10 cycles)
Per EIAJ-STD-002
See solder profile, Figure 1
Environmental
1. Consult factory for availability of higher frequencies.
2. HCMOS Load - See Load circuit diagram. Consult factory with nonstandard output load requirements.
3. Rise/Fall times are measured between 0.5 V and 2.4 V with TTL load, and between 10% Vdd and 90% Vdd with
HCMOS load.
MtronPTI reserves the right to make changes to the product(s) and service(s) described herein without notice. No liability is assumed as a result of their use or application.
Please see
www.mtronpti.com
for our complete offering and detailed datasheets. Contact us for your application specific requirements: MtronPTI
1-800-762-8800.
Revision:12-21-10
M2 Series
5x7 mm, 3.3 Volt, HCMOS/TTL Compatible Output, Clock Oscillator
Load Circuit Diagram
DUT Output
Test Point
C Load
Note: C Load includes probe and fixturing.
Pin Connections
PIN
1
2
3
4
Function
N/C, Tristate or Standby
Ground
Output
+Vdd
MtronPTI reserves the right to make changes to the product(s) and service(s) described herein without notice. No liability is assumed as a result of their use or application.
Please see
www.mtronpti.com
for our complete offering and detailed datasheets. Contact us for your application specific requirements: MtronPTI
1-800-762-8800.
