942-M3A-2D-1G1-65E datasheet, PDF

Datasheet> All Categories > The sensor> Sensor/transducer> 942-M3A-2D-1G1-65E

942-M3A-2D-1G1-65E: DescriptionUltrasonic Sensor, 800mm Min, 8000mm Max, 0-10V,; CategoryThe sensor Sensor/transducer; File Size87KB，2 Pages; ManufacturerHoneywell; Websitehttp://www.ssec.honeywell.com/; Environmental Compliance

Download Datasheet Parametric View All

942-M3A-2D-1G1-65E Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	942-M3A-2D-1G1-65E	-	-	View	Buy Now

942-M3A-2D-1G1-65E Overview

Ultrasonic Sensor, 800mm Min, 8000mm Max, 0-10V,

942-M3A-2D-1G1-65E Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	unknown
Other features	REVERSE POLARITY, SHORT CIRCUIT PROTECTION, IP 40, IT HAVE REPEATABILITY OF PLUS OR MINUS 0.2 PERCENT PLUS OR MINUS 1.0 MM
shell	PLASTIC
Maximum measuring range (mm)	8000 mm
Minimum measuring range (mm)	800 mm
Maximum working current	50 mA
Maximum operating temperature	50 °C
Minimum operating temperature
Output interface type	RS-232, 3-WIRE INTERFACE
Output range	0-10V
Output type	ANALOG VOLTAGE
Sensor/Transducer Type	LINEAR POSITION SENSOR,ULTRASONIC
Maximum supply voltage	30 V
Minimum supply voltage	19 V
Termination type	SCREW
Base Number Matches	1

Preview

Download Datasheet

View All

Sensing and Control

942-M3A-2D-1G1-65E

(

Home

Products

Sensors

Position Sensors

Ultrasonic Sensors

942

)

Serie s 942 Separate control box, 1500 m m [59.0 in] s can dis tance, tw o analog

outputs (0 Vdc to 10 Vdc and 4 m A to 20 m A) , tw o sw itching outputs PNP and

digital link , to us e w ith 942 or 947 se nsor he ad

Actual product

appearance may vary.

Product Specifications

Sensing Range

Range Type

Supply Voltage

Beam Angle

Oscillating Frequency

Integrated Temperature

Compensation

Repeatability

Output Type

Sw itching Output Type

Max. Sw itching Frequency

Adjustment Method

Analog Output Slope Selection

Operating Temperature

Storage Temperature

Linearity

Load Resistance

Maximum Output Current

Hysteresis

Adjustable Sensitivity

Indicators

Additional Inputs/Outputs

Computer Interface

Memory

Current Consumption

Circuit Protection

Housing Style

Housing Material

Sealing

Mounting

Termination Type

800 mm to 8000 mm [31.5 in to 315.0 in]

Long range > 2,0 m [80.0 in] and up

19 Vdc to 30 Vdc

8°

220 KHz

Yes

± 0.2 % ± 1,0 mm [0.039 in]

Analog 0 Vdc to 10 Vdc|Analog 4 mA to 20 mA|RS-232 Interface|Sw itching 2

x PNP

1 Normally Open/1 Normally Closed

8 Hz

Thumb Wheels or PC softw are

0 °C to 50 °C [32 °F to 122 °F]

-25 °C to 85 °C [-13 °F to 185 °F]

0.3 % ± 2,0 mm [0.079 in]

> 1.45 Kohm (Voltage), < 250 Ohm (Current)

100 mA

Programmable by softw are (default 1 %)

Sw itch (33 % or 100 %)

5 LED

Overrange, underrange, parallell outputs, Hold/Synchronisation

RS-232, 3 w ire

EEPROM (non-volatile)

50 mA maximum

Reverse Polarity, voltage spikes on supply and output lines, short circuit on

sw itching output

Separate head and control box

Polyethylenterephtalat

IP40

Din rail or 2 holes dia. 4 mm

Screw terminals
