Molded
Inductor
.440" ± .010"
22 AWG/TCW
LM3
.190" ± .010"
1.437”± 0.125”
Reliable subminiature inductors for your high-density applications. A convenient package without a sacrifice in electrical
quality.
TESTING MIL-C-15305.
MARKING Color Banded.
PACKAGING Bulk or Tape and Reel.
INDUCTANCES 0.15µH to 1,000µH
OPERATING TEMPERATURE RANGE -55°C to +125°C
AMBIENT TEMPERATURE +90°C
INDUCTANCE TOLERANCE ±20% from 0.15µh to 0.47µh; ±10%
from 0.56µh to 27µh;±5% from 30µh to 1,000µh.
PAR T
NUMBER
LM3-R15
LM3-R22
LM3-R33
LM3-R47
LM3-R56
LM3-R68
LM3-R82
LM3-1R0
LM3-1R2
LM3-1R5
LM3-1R8
LM3-2R2
LM3-2R7
LM3-3R3
LM3-3R9
LM3-4R7
LM3-5R6
LM3-6R8
LM3-8R2
LM3-100
LM3-120
LM3-150
LM3-180
LM3-220
LM3-270
LM3-300
LM3-330
LM3-360
LM3-390
LM3-430
LM3-470
LM3-510
LM3-560
LM3-620
LM3-680
LM3-750
LM3-820
LM3-910
LM3-101
LM3-111
LM3-121
LM3-131
LM3-151
LM3-161
LM3-181
LM3-201
LM3-221
LM3-241
LM3-271
LM3-301
LM3-331
LM3-361
LM3-391
LM3-431
LM3-471
LM3-501
LM3-511
LM3-561
LM3-621
LM3-681
LM3-751
LM3-821
LM3-911
LM3-102
INDUCT ANCE
(µh)
.15
.22
.33
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
220
240
270
300
330
360
390
430
470
500
510
560
620
680
750
820
910
1000
TEST FREQUENCY
(Mhz)
50
50
50
50
50
45
40
40
30
30
30
30
30
30
30
30
30
30
30
30
50
55
60
60
65
55
55
55
55
55
55
55
45
45
45
45
45
45
45
60
60
60
60
60
60
60
60
60
65
65
65
65
65
65
65
65
65
65
60
60
60
60
60
60
Q
MINIMUM
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
SELF RESONANT
FREQUENCY
TYPIC AL (MHz)
510
415
350
300
270
250
210
200
180
170
150
140
120
70
65
60
50
50
48
42
36
30
30
24
22
29
18
17
16
15
14
14
14
12
11
10
9.3
9.1
8.3
7.5
7.3
6.5
6.2
6.0
5.7
5.5
5.2
5.0
5.6
5.3
5.0
4.7
4.5
4.3
4.0
3.9
3.8
3.6
3.5
3.4
3.3
3.1
2.9
2.8
DC RESIST ANCE
OHMS
MAXIMUM (Ω )
.030
.035
.065
.085
.125
.150
.205
.290
.400
.485
0.740
0.970
1..200
0.140
0.155
0.210
0.280
0.375
0.440
0.605
1.050
1.200
1.950
2.200
2.750
2.1
2.3
2.4
2.5
3.0
3.4
3.7
4.1
4.2
4.2
4.2
4.4
4.7
4.9
5.1
5.4
5.7
8.2
6.6
7.1
7.5
.79
8.3
8.2
8.7
9.1
9.6
10.0
10.5
11.1
11.4
11.5
12.3
13.0
13.7
14.4
15.1
15.8
16.5
RATED DC
CURRENT MAX
(mA)
3050
2800
2000
1700
1450
1300
1100
930
785
700
550
505
460
990
870
745
645
560
540
440
370
310
255
240
205
310
300
290
285
260
245
235
225
220
220
220
215
210
205
200
195
190
180
175
170
165
160
155
110
107
105
102
100
97
95
94
93
91
88
85
83
81
79
78
