cpi
|
8560as
cpi | 4cW50,000J
8560as
The 8560AS is intended for use as an RF amplifier
or oscillator or in audio amplifier or modulation
service. It has electrical characteristics simi-
lar but not identical to the 4CX250B/7203. The
8560AS is designed for conduction cooling and is
nominally rated for 200 watts anode dissipation.
chaRacteRistics
Plate Dissipation (Max.)
Screen Dissipation (Max.)
Grid Dissipation (Max.)
Frequency for Max. rating (CW)
Amplification Factor
Filament/Cathode
Voltage
Current
Capacitance
Input
Output
Feedthrough
Capacitance
Input
Output
Feedthrough
Cooling
Base
Air Socket
Air Chimney
Boiler
Length
Diameter
Weight
200 Watts
12 Watts
2 Watts
500 MHz
5
Oxide Coated
6.3 Volts
2.6 Amps
Grounded Cathode
16.5 pf
4.6 pf
.04 pf
---
--- pf
--- pf
--- pf
Conduction
9 Pin Special
n/a
---
---
2.45 in; 62.1 mm
1.63 in; 41.4 mm
8.2 oz; 235 gm
type of service
RF amplifier
RF amplifier plate modulated
RF linear amplifier
RF amplifier or modulator
MaxiMuM Ratings
plate
Voltage
(Volts)
2,000
1,500
2,000
2,000
plate
current
(amps)
0.25
0.20
0.25
0.25
ypical OpeRatiOn
t
plate
current
(amps)
0.25
0.20
0.25
0.50
Drive
Output
power power
(Watts) (kiloWatts)
2.9
1.7
---
---
0.390
0.235
0.300
0.600
class of
Operation
c
c
aB1
aB1
plate
screen
Voltage Voltage
(Volts)
(Volts)
2,000
1,500
2,000
2,000
250
250
350
350
The values listed above represent specified limits for the product and are subject to change. The data should be used for basic
information only. Formal, controlled specifications may be obtained from CPI for use in equipment design.
For information on
this and other CPI products, visit our website at: www.cpii.com,
or contact: CPI MPP Division, Eimac Operation, 607 Hansen Way, Palo Alto, CA 94303
telephone
:
1(800) 414-8823.
fax
:
(650) 592-9988 |
