COMMUNICATIONS TEST & MEASUREMENT SOLUTIONS
RSAM-5800
Analog QAM RF and MPEG Video Probe
Key Features
• Monitor and troubleshoot analog and digital video as
well as DOCSIS® services
• Web-based access to live and historical MPEG and RF
measurements
• Simple network management protocol (SNMP) trap
forwarding to up to five destinations
• Monitor MPEG stream errors (TR 101 290 Priority 1, 2,
and 3) and drill down to analyze individual program
performance
• Easily access performance history (RF, QAM, and MPEG)
stored in MySQL relational database
Applications
• Segments problems to a master
headend, local headend/hub, or
outside plant by comparing RF
and MPEG trends from a common
edge device or across multiple
headends/hubs
• Monitors TR 101 290 MPEG
parameters for both DVB and
ATSC providing worldwide support
• Remotely troubleshoots problems
using Web-based access to live
and historical RF and MPEG
measurements
Benefits
The JDSU RSAM-5800 Remote Service Analyzer Module provides remote analy-
sis of forward path digital and analog signals. It is specifically designed for deploy-
ment in remote, unmanned hub sites or headend locations.
The RSAM-5800 combines the extensive knowledge of JDSU in both radio
frequency (RF) and Moving Picture Experts Group (MPEG) analysis to quickly
identify real customer-affecting issues down to the individual program without
having to deploy specialists to remote hub sites. The RSAM RF and MPEG probes
provide remote monitoring and analysis with detailed views of channel
performance to the field, headend, and network operations center (NOC)
technicians using Windows® Internet Explorer®.
Simply viewing the QAM (quadrature amplitude modulation) stack with a spec-
trum analyzer or measuring and monitoring MER and BER (modulation and bit
error rates) on QAM carriers provides absolutely no insight into MPEG video
payloads. It is critical for cable network operators to have system-wide visibility
into the underlying content or MPEG protocol layer to ensure the quality of
programming content and other MPEG parameters such as PCR jitter (timing)
and continuity count for both digital video broadcasting (DVB) and Advanced
Television Systems Committee (ATSC).
The award winning RSAM-5800 helps segment video problems in minutes—not
hours—by proactively monitoring video, voice over Internet Protocol (VoIP), and
high-speed data (HSD) carriers for RF and MPEG impairments.
• Eliminate truck rolls to segment
RF and video problems
• Ensure that required truck rolls are
deployed to the right place with the
right personnel and equipment
• Increase network availability
using notification of forward path
degradation before service is
disrupted
• Intelligently filter alarms based
on severity to appropriately
alert local operations and NOC
personnel
WEBSITE
:
www.jdsu.com/test
RSAM-5800
Specifications
Frequency
Range
Accuracy
Tuning resolution
Channel bandwidth
50 to 1,000 MHz
±10 ppm at 25°C (77°F)
Analog 10 kHz, Digital 50 kHz
RSAM-5800A 8 MHz
RSAM-5800B 6 MHz
EVM
3
Accuracy
Range
Accuracy
Symbol rate
Level Measurement, Analog
Signal types
CW,Video, and Single and Dual Audio
(NTSC, PAL and SECAM)
Range
–40 to +60 dBmV
1
Resolution
0.1 dB
Resolution bandwidth
280 kHz
2
Accuracy
±1.5 dB typical @ 25°C
Range 64 QAM: 1.2 to 5.8%
±0.5% (1.2 to 2.0%)
±1.0% (2.1 to 4.0%)
±1.4% (4.1 to 5.8%)
256 QAM: 1.1 to 2.4%
±0.6%
Annex A: 5.057 to 6.952 Msps
for 64 and 256 QAM
Annex B: 5.057 Msps for 64 QAM;
5.361 Msps for 256 QAM
Annex C: 5.274 Msps for 64 QAM;
5.361 Msps for 256 QAM
Operating temperature range
5 to +45°C (41 to 113°F)
Storage temperature range
–20 to +50°C (0 to 120°F)
Power supply input
47–63 Hz, ~110 VA,100–265 VAC
MPEG TR101-290 Measurements
Priority 1
– Synch loss error
– Synch byte error
– PAT error
– Continuity count error
– PMT error
– Referenced PID error
Priority 2
– Transport error
– CRC error
– PCR repetition error
– PCR discontinuity error
– PCR accuracy error
– PTS error
– CAT error
Priority 3
– Unreferenced PID error
– Program and system integration protocol (PSIP) error (ATSC)
– SI error (DVB)
Typical detectable range
Accuracy for levels between –20 to 55 dBmV;
additional uncertainty ±0.5 dB across
3
Accuracy and behavior from 50 to 1,000 MHz
for levels between 0 to 50 dBmV (typical)
1
2
Standards Compliance
Shock and vibration
Drop
Handle stress
Safety—emissions
Safety—immunity
IEC 60068
IEC 61010
IEC 61010
EN 55022
EN 61000
Level Measurement, Digital
Modulation types
Range
Resolution
Resolution bandwidth
Accuracy
2
QPSK, QAM (16, 64, 256) DVB/ACTS
–20 to +50 dBmV
1
0.1 dB
280 kHz
±2.0 dB typical @ 25°C
Interfaces
RF
RS232
Ethernet
AUX
75Ω, F81 or BNC option
Max. sustained voltage 100 VAC, 140 VDC
Standard via DB-9
Supports RJ45, 10BaseT,TCP/IP, and UDP
TTL-compatible output for controlling accessories
Downstream QAM Demodulation
Modulation types
Input range (lock range)
MER
3
Accuracy
64 and 256 QAM, ITU-T J.83
–15 to +50 dBmV total
for 256 QAM
Range 256 QAM: 28 to 35 dB
Range 64 QAM: 21 to 35 dB
±2.0 dB typical
General
Dimensions
Weight
48.3 x 34.3 x 8.9 cm (19 x 13.5 x 3.5 in)
3.4 kg (7 lb 7oz)
Ordering Information
Model
RSAM-5800A
RSAM-5800B
RSAM-MPEG
RSAMMPEG-UG-FLD
ISS-5116
PVM Server Software
PVM Client Software
Hardware Upgrades
RSAM-5600B to RSAM-5700B
RSAM-5800A-UPGX
RSAM-5800B-UPGX
RSAM-5800A-UPGX
RSAM-5800B-UPGX
Part Number
RSAM5800A
RSAM5800B
RSAM-MPEG
RSAMMPEG-UG-FLD
1010-00-0906
PVM-SERVER
PVM-CLIENT
RSM5700B-UG-FAC
RSAM58ARFUPGX56
RSAM5800BUPGX57
RSAM5800AUPGX56
RSAM5800BUPGX56
Description
Remote Service Analyzer Module—RF Video Probe—Rack-mounted RF/QAM analyzer (8 MHz tuner), including RF monitoring.
This unit is field upgradeable to add MPEG.
Remote Service Analyzer Module—RF Video Probe—Rack-mounted RF/QAM analyzer (6 MHz tuner), including RF monitoring.
This unit is field upgradeable to add MPEG.
Factory installed—Add MPEG capability for RSAM-5800 at time of purchase.
Field upgrade—Add MPEG capability in the field for RSAM-5800, does not include calibration.
16x1 RF Input Selector Switch for RSAM—20 MHz to 1 GHz
PathTrak™ Video Monitoring (PVM) Server and Client software includes 5 client licenses.
Provides Web access for live troubleshooting and displaying performance history.
PathTrak Video Monitoring (PVM) Client software—Supports configuration and access to RSAM-5700 and RSAM-5800 probes.
Upgrade RSAM-5600B to RSAM-5700B for RF monitoring applications. Includes calibration and deep interleave upgrade (factory
upgrade).
Exchange RSAM-5600A for an RSAM-5800A with RF ONLY (without the MPEG option).
Exchange RSAM-5700B for an RSAM-5800B with the MPEG option.
Exchange RSAM-5600A for an RSAM-5800A with the MPEG option.
Exchange RSAM-5600B for an RSAM-5800B with the MPEG option
Test & Measurement Regional Sales
NORTH AMERICA
TOLL FREE
:
1 866 228 3762
FAX
:
+1 301 353 9216
LATIN AMERICA
TEL
:
+1 954 688 5660
FAX
:
+1 954 345 4668
ASIA PACIFIC
TEL
:
+852 2892 0990
FAX
:
+852 2892 0770
EMEA
TEL
:
+49 7121 86 2222
FAX
:
+49 7121 86 1222
30162564 000 1208
www.jdsu.com/test
Product specifications and descriptions in this document subject to change without notice. © 2008 JDS Uniphase Corporation
RSAM5800.DS.CAB.TM.AE
December 2008
