Module no:3003431 LabelId:3003431 Operator:Phoenix
18:45:42, Donnerstag, 28. Juni 2001
ZIK 2,5-PE/L/NT
Terminal width 6.2
(IEC)
[mm ]
DIN VDE 0611
2
rigid
solid
0.2-4
flexible
stranded AWG
0.2-2.5
24-12
I
[A]
30
U
[V]
*
400
250
250
Type
Order No.
30 03 43 1
Pcs.
Pkt.
50
* Phase conductor/phase
conductor
Phase conductor/PE
Phase conductor/N
Description
Three level installation terminal block,
with
green-yellow
PE
connection, phase conductor connection
ZIK 2,5-PE/L/NT
L
and blue neutral disconnection
NT
Accessories
(1)
End cover
(2)
Fixed bridge,
for
cross-connections in the terminal
center, screw heads with insulating
collar, 10-pos., divisible, with 10
screws
(3)
Isolator bridge bar,
10-pos.,
divisible, with 10 screws, for switchable
branches with
(4)
Bridge bar isolator IS-K 4
as
distance piece
(5)
Partition plate,
for optical and
electrical separation of terminal block
groups, 2 mm thick
(6)
Neutral connection terminal
block,
steel, yellow chromated
up to 16 mm solid, 10.3 mm wide
up to 35 mm solid, 14.4 mm wide
(7)
Screwdriver,
for actuating the
tension spring
(8)
Neutral busbar,
3 x 10 mm, 1 m long, copper,
tin-plated
(9)
Zack marker sheet, flat,
100-section, for labelling the outer
marker grooves
2
2
D-ZIK 2,5
FBI 10-6
30 00 93 9
I
max.
: 30 A
02 03 25 0
50
10
ISSBI 10-6
IS-K 4
ATP-ZIK
I
max.
: 26 A
03 01 50 5
13 02 33 8
30 06 46 7
10
100
50
AKG 16 BU
AKG 35 BU
SZF 1 - 0,6 x 3,5
NLS-CU 3/10
04 23 01 4
04 24 01 3
12 04 51 7
I
max.
: 140 A
04 02 17 4
50
50
1
10
ZBFM 6
(see
info)
Phoenix Contact Elektronischer Katalog
Page 1 / 2
Module no:3003431 LabelId:3003431 Operator:Phoenix
Technical data
Dimensions
Width / length / end cover width
Height (NS 35:7.5 / NS 35:15)
Technical data in accordance with IEC/ DIN VDE
Maximum load current / cross section
Current carrying capacity of the neutral
busbar
Rated surge voltage / contamination class
Surge voltage category / insulation material
group
Connection capacity
stranded with ferrule with plastic sleeve
stranded with ferrule without plastic sleeve
stranded with TWIN ferrule with plastic
sleeve
Disconnect slide
Thread / torque
Stripping length
Internal cylindrical gage (IEC 947-1:1988)
Insulation material
Inflammability class acc. to UL 94
Temperature indices RTI / Ti
Block diagram
– / [Nm]
[mm]
[mm ]
[mm ]
[mm ]
2
2
2
18:45:42, Donnerstag, 28. Juni 2001
[mm]
[mm]
6.2 / 118.5 / 2
51 / 58.5
30 / 4
140
4/3
III / I
[A] / [mm ]
[A]
[kV] / –
–/–
2
0.25-2.5
0.25-2.5
0.5
M 2.5 / 0.5-0.6
10
A3
PA
V0
130 / 120
Phoenix Contact Elektronischer Katalog
Page 2 / 2
