EMP108-P1
ISSUED DATE: 07-01-04
7.0 – 9.5 GHz Power Amplifier MMIC
FEATURES
•
•
•
•
•
•
7.0 – 9.5 GHz Operating Frequency Range
24.0dBm Output Power at 1dB Compression
19.0 dB Typical Small Signal Gain
-40dBc OIMD3 @Each Tone Pout 14dBm
APPLICATIONS
Point-to-point and point-to-multipoint radio
Military Radar Systems
Optional Packaging solutions are available
contact the Excelics sales team for details.
Caution! ESD sensitive device.
ELECTRICAL CHARACTERISTICS (T
a
= 25
°C,
50 ohm, VDD= 7 V, IDQ= 200 mA)
SYMBOL
F
P1dB
Gss
OIMD3
Input RL
Output RL
Idss
V
DD
Rth
Tb
SYMBOL
V
DS
V
GS
I
DD
I
GSF
P
IN
T
CH
T
STG
P
T
PARAMETER/TEST CONDITIONS
Operating Frequency Range
Output Power at 1dB Gain Compression
Small Signal Gain
Output 3
rd
Order Intermodulation Distortion
@∆f=10MHz, Each Tone Pout 14dBm
Input Return Loss
Output Return Loss
Saturate Drain Current
Power Supply Voltage
Thermal Resistance (Au-Sn Eutectic Attach)
Operating Base Plate Temperature
CHARACTERISTIC
Drain to Source Voltage
Gate to Source Voltage
Drain Current
Forward Gate Current
Input Power
Channel Temperature
Storage Temperature
Total Power Dissipation
VALUE
8V
-4V
Idss
4.5 mA
@ 3dB compression
150°C
-65/150°C
3.8W
- 35
V
DS
=3V, V
GS
=0V
244
MIN
7.0
22.5
16.0
24.0
19.0
-40
-12
-6
305
7
30
+ 85
1,2
TYP
MAX
9.5
UNITS
GHz
dBm
dB
dBc
dB
dB
366
8
o
mA
V
C/W
ºC
ABSOLUTE MAXIMUM RATINGS FOR CONTINUOUS OPERATION
1. Operating the device beyond any of the above rating may result in permanent damage.
2. Bias conditions must also satisfy the following equation V
DS
*I
DS
< (T
CH
–T
HS
)/R
TH
; where T
HS
= ambient temperature
Specifications are subject to change without notice.
Excelics Semiconductor, Inc. 310 De Guigne Drive, Sunnyvale, CA 94085
Phone: 408-737-1711 Fax: 408-737-1868 Web:
www.excelics.com
page 1 of 1
Revised July 2004
