CT0805HT Series
From 1.8 nH to 1000 nH
Part
Number
CT0805HT_-1N8K
CT0805HT_-3N9K
CT0805HT_-4N7_*
CT0805HT_-6N8_*
CT0805HT_-8N2_*
CT0805HT_-10N_
CT0805HT_-12N_
CT0805HT_-15N_
CT0805HT_-18N_
CT0805HT_-22N_
CT0805HT_-27N_
CT0805HT_-33N_
CT0805HT_-39N_
CT0805HT_-47N_
CT0805HT_-56N_
CT0805HT_-68N_
CT0805HT_-82N_
CT0805HT_-R10_
CT0805HT_-R12_
CT0805HT_-R15_
CT0805HT_-R18_
CT0805HT_-R22_
CT0805HT_-R27_
CT0805HT_-R33_
CT0805HT_-R39_
CT0805HT_-R47_
CT0805HT_-R56_
CT0805HT_-R62_
CT0805HT_-R68_
CT0805HT_-R75_
CT0805HT_-R82_
CT0805HT_-1R0_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0805HT-4N7_
G = ±2%, J = ±5%, K = ±10%
* = J or K only
CT0805HTF
Please specify “F” for RoHS compliant
L Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
150
100
100
50
25
25
25
25
25
25
Q
Fact.
Min.
55
50
50
50
50
55
55
50
50
50
50
55
55
50
50
50
50
50
40
40
40
40
40
40
35
25
18
18
18
18
18
17
Q Test
Freq.
(MHz)
1500
1000
1000
1000
1000
750
750
500
500
500
500
500
500
500
500
500
500
500
250
250
250
250
250
250
250
100
50
50
50
50
50
50
SRF
Min.
(MHz)
9400
6100
5500
5500
4800
3300
3800
2950
3100
2900
2450
2350
2200
2000
1850
1500
1500
1200
1150
1050
950
900
850
800
700
600
550
450
420
400
400
330
DCR
Max.
Ω
(Ω)
0.03
0.06
0.06
0.08
0.08
0.08
0.1
0.1
0.13
0.15
0.23
0.28
0.33
0.39
0.39
0.4
0.44
0.64
0.68
0.8
0.9
0.98
1.3
1.45
1.6
1.8
1.9
2
2.1
2.2
2.5
2.6
Rated
DC
(mA)
800
800
800
800
800
800
800
800
800
800
600
600
600
600
500
500
500
400
300
300
300
300
300
300
300
300
300
300
300
300
300
300
Inductance
(nH)
1.8
3.9
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
620
680
750
820
1000
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD ceramic core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-40°C to +125°C
Storage Temperature:
-25°C to +85°C
Inductance Tolerance:
±2%, ±5%, ±10%
Testing:
Inductance and Q are tested on an HP4287A at
specified frequency
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant available.
Marking:
Color dot
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
2.16
0.085
B
Max.
1.52
0.060
C
Max.
0.89
0.035
D
0.43
0.016
E
1.14
0.045
F
1.27
0.05
PAD LAYOUT
