NPIS64D560MTRB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> NPIS64D560MTRB

NPIS64D560MTRB: DescriptionGeneral Purpose Inductor, 56uH, 20%, 1 Element, SMD, 2626,; CategoryPassive components inductor; File Size451KB，8 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp

Download Datasheet Parametric Compare View All

NPIS64D560MTRB Overview

General Purpose Inductor, 56uH, 20%, 1 Element, SMD, 2626,

NPIS64D560MTRB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	2626
Reach Compliance Code	compliant
ECCN code	EAR99
uppercase and lowercase codes	2626
structure	Shielded
DC Resistance	0.202 Ω
Nominal inductance(L)	56 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e0
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	4 mm
Package length	6.6 mm
Package form	SMT
Package width	6.6 mm
method of packing	TR
Maximum rated current	0.85 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	0.1 MHz
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

NPIS Shielded Power Inductors

FEATURES

• SHIELDED POWER INDUCTOR

• SMALL SIZE WITH CURRENT RATINGS TO 3.0 AMPS)

• SURFACE MOUNTABLE CONSTRUCTION

• HIGH INDUCTANCE (UP TO 100µH)

• TAPED AND REELED FOR AUTOMATIC INSERTION

• FOR USE IN DC/DC CONVERTERS

CHARACTERISTICS

Case Size

Inductance Range

Temperature Range

Temperatrue Rise at

I rms

Inductance Change

at I sat

Inductance Tolerance

Resistance to Solder

Heat

NPIS21D NPIS24D NPIS28D NPIS36D

NPIS42D

NPIS43D

NPIS52D

NPIS__D Series

includes all homogeneous materials

*See Part Number System for Details

RoHS

Compliant

NPIS53D

NPIS63D

NPIS64D

1.5 ~ 10µH 1.5 ~ 12µH 2.2 ~ 47µH 3.3 ~ 47µH 10 ~ 180µH 1.2 ~ 180µH 4.1 ~ 100µH 2.6 ~ 100µH 3.0 ~ 100µH 3.3 ~ 100µH

-55°C ~ +125°C

+40°C max.

-35% typical

±20% (M), ±30% (y)

250°C for 10 seconds

DIMENSIONS (mm)

Series

NPIS21D

NPIS24D

NPIS28D

NPIS36D

NPIS42D

NPIS43D

NPIS52D

NPIS53D

NPIS63D

NPIS64D

3.2 max.

4.0 max.

4.8 ± 0.5

5.6 ± 0.5

6.6 ± 0.5

3.2 max.

4.0 max.

4.8 ± 0.5

5.6 ± 0.5

6.6 ± 0.5

1.3 max.

1.6 max.

2.0 max.

1.9 max

2.0 max

3.0 max

2.0 max

3.0 max

4.0 max

1.0 typ

1.1 typ

1.6 ref

2.0 ref

PART NUMBER SYSTEM

NPIS 42 D 150 M TR F

Termination Finish:

F = Standard Pb-free (100%Sn)

B = Sn-Pb (Optional)

Packaging: TR = Tape & Reel

Inductance Tolerance Code: M=±20%, Y=±30%

Inductance Code (µH): 1st two digits are significant,

3rd digit is multiplier.

Construction Code (see drawing for details)

Size Code (see table for details)

Series

NPIS21D, 24D, 28D & 36D

NPIS42D, 43D, 52D, 53D, 63D & 64D

Termination

Terminations

Part Number

NPIS21D1R5YTRF

NPIS21D2R2YTRF

NPIS21D3R3YTRF

NPIS21D4R7YTRF

NPIS21D6R8YTRF

NPIS21D100YTRF

STANDARD VALUES - CASE SIZE 21 (3.2 x 3.2 x 1.3mm)

Inductance Value

DC Resistance

DC Current

Test Frequency

(µH)

(Ω)

Isat/Irms (Amps)

1.5 ± 30%

0.068

1.48

2.2 ± 30%

0.098

1.27

3.3 ± 30%

4.7 ± 30%

6.8 ± 30%

10 ± 30%

0.123

0.170

0.260

0.400

1.02

0.88

0.78

0.65

100KHz

Maximum +40°C temperature rise at Irms. Typical -35% inductance change at Isat.

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

NPIS64D560MTRB Related Products

	NPIS64D560MTRB	NPIS64D7R4MTRB	NPIS64D680MTRB	NPIS64D470MTRB	NPIS64D3R3MTRB	NPIS64D390MTRB	NPIS64D270MTRB	NPIS64D150MTRB	NPIS64D100MTRB	NPIS64D6R2MTRB
Description	General Purpose Inductor, 56uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 7.4uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 68uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 47uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 3.3uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 39uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 27uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 15uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 10uH, 20%, 1 Element, SMD, 2626,	General Purpose Inductor, 6.2uH, 20%, 1 Element, SMD, 2626,
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
package instruction	2626	2626	2626	2626	2626	2626	2626	2626	2626	2626
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compli
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
uppercase and lowercase codes	2626	2626	2626	2626	2626	2626	2626	2626	2626	2626
structure	Shielded	Shielded	Shielded	Shielded	Shielded	Shielded	Shielded	Shielded	Shielded	Shielded
DC Resistance	0.202 Ω	0.031 Ω	0.234 Ω	0.155 Ω	0.02 Ω	0.138 Ω	0.109 Ω	0.057 Ω	0.038 Ω	0.027 Ω
Nominal inductance(L)	56 µH	7.4 µH	68 µH	47 µH	3.3 µH	39 µH	27 µH	15 µH	10 µH	6.2 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
JESD-609 code	e0	e0	e0	e0	e0	e0	e0	e0	e0	e0
Number of functions	1	1	1	1	1	1	1	1	1	1
Number of terminals	2	2	2	2	2	2	2	2	2	2
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package height	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm
Package length	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm
Package form	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT
Package width	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm	6.6 mm
method of packing	TR	TR	TR	TR	TR	TR	TR	TR	TR	TR
Maximum rated current	0.85 A	2.3 A	0.75 A	0.95 A	3.5 A	1 A	1.2 A	1.6 A	2 A	2.5 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal location	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED
Terminal shape	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND
Test frequency	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.1 MHz
Tolerance	20%	20%	20%	20%	20%	20%	20%	20%	20%	20%
