Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
-40°C to 85°C
-55°C to 100°C
0.5W max.
Coaxial
ZX10-2-20+
ZX10-2-20
50Ω
200 to 2000 MHz
Features
• low insertion loss, 0.8 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected under U.S. Patent 6,790,049 & 6,963,255
CASE STYLE: FL905
Connectors Model
SMA
ZX10-2-20-S(+)
Price
$24.95
Qty.
(1-24)
Internal Dissipation (as a combiner) 0.125W max.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Applications
• PCN/PCS
• cellular/GSM
• VHF/UHF receivers/transmitters
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Splitter Electrical Specifications (T
AMB
=25°C)
FREQ.
RANGE
(MHz)
f
L
-f
U
200-2000
800-1000
500-1500
1800-2000
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 3.0 dB
Outline Drawing
PHASE
UNBALANCE
(Degrees)
Max.
6.0
2.0
3.0
6.0
AMPLITUDE
UNBALANCE
(dB)
Max.
0.4
0.3
0.4
0.4
Typ. Min.
20
22
22
20
16
17
17
17
Typ. Max.
0.8
0.5
0.5
1.6
2.2
0.9
1.3
2.2
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
200.00
300.00
400.00
600.00
700.00
3.49
3.45
3.47
3.51
3.53
3.55
3.57
3.62
3.68
3.74
3.81
3.89
3.98
4.22
4.48
ZX10-2-20
INSERTION LOSS
5.0
INSERTION LOSS (dB)
S-1
Amplitude
Unbalance
(dB)
0.25
0.19
0.17
0.14
0.11
0.10
0.07
0.06
0.03
0.01
0.01
0.02
0.02
0.07
0.14
Isolation
(dB)
Phase
Unbalance
(deg.)
1.50
0.82
0.41
0.06
0.20
0.31
0.37
0.41
0.51
0.56
0.38
0.11
0.14
0.89
2.24
VSWR
S
VSWR
1
VSWR
2
S-2
3.25
3.27
3.30
3.38
3.42
3.46
3.50
3.56
3.65
3.73
3.79
3.87
3.94
4.15
4.34
26.07
34.65
32.93
24.97
22.98
21.58
20.55
19.84
19.12
19.12
19.35
19.82
20.51
21.96
20.00
1.40
1.40
1.40
1.40
1.40
1.40
1.39
1.38
1.34
1.31
1.27
1.23
1.18
1.05
1.12
ZX10-2-20
ISOLATION
40
S-2
Outline Dimensions (
inch
)
mm
A
.74
18.80
B
.90
22.86
C
.54
13.72
D
.50
12.70
E
.04
1.02
F
.16
4.06
G
.29
7.37
1.51
1.37
1.28
1.18
1.14
1.10
1.07
1.05
1.08
1.11
1.15
1.20
1.25
1.34
1.41
1.47
1.37
1.31
1.23
1.19
1.16
1.13
1.10
1.04
1.01
1.02
1.05
1.09
1.19
1.28
800.00
900.00
1000.00
1200.00
1300.00
1400.00
1500.00
1600.00
1800.00
2000.00
H
.37
9.40
J
--
--
K
.122
3.10
L
.496
12.60
M
.106
2.69
N
wt
.122 grams
20.0
3.10
ISOLATION (dB)
4.6
4.2
3.8
3.4
3.0
200
35
30
25
20
15
560
920
ZX10-2-20
VSWR
1280
1640
2000
10
200
560
920
1280
1640
2000
FREQUENCY (MHz)
FREQUENCY (MHz)
2.0
#S-VSWR
1.8
VSWR
1.6
1.4
1.2
1.0
200
#1-VSWR
#2-VSWR
electrical schematic
560
920
1280
1640
2000
FREQUENCY (MHz)
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. E
M98898
ZX10-2-20
ED-10145/2
HY/RS/CP
070424
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
