Ordering number : ENA1492
Bi-CMOS IC
LV4991M
Overview
For Portable Audio Equipment
Monaural BTL Power Amplifier
LV4991M incorporates the power amplifier circuit operable at low voltage (2.7V or more) and has additionally the standby
function to reduce the current drain. This is the best IC for speaker drive for the audio of low-power range system and home
appliance. There are The LV4991TT: MSOP8 (150mil) and The LV4991TH: HMSOP8 (150mil) in the package change
goods.
Function and Feature
•
Monaural BTL power amplifier incorporated
Standard output power 1 = 450mW (VCC = 3.6V, RL = 8Ω, THD = 10%)
Standard output power 2 = 1000mW (VCC = 5V, RL = 8Ω, THD = 10%)
Output coupling capacitor not necessary because of differential output type
•
Operation at low voltage possible
VCC = 2.7V or more
•
Standby function incorporated
Standard current drain at standby = 0.1µA (VCC = 3.6V)
•
Second amplifier stop control function incorporated : Reducing the pop sound at startup, simple MUTE
•
Overheat protection circuit incorporated
•
Gain setting possible
BTL voltage gain = 0 to 26dB
•
Output phase compensation capacitor not necessary
