XC68HC705X4DW datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> XC68HC705X4DW

XC68HC705X4DW: Description8-BIT, OTPROM, 2.2MHz, MICROCONTROLLER, PDSO28, SOIC-28; CategoryThe embedded processor and controller Microcontrollers and processors; File Size967KB，156 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric View All

XC68HC705X4DW Overview

8-BIT, OTPROM, 2.2MHz, MICROCONTROLLER, PDSO28, SOIC-28

XC68HC705X4DW Parametric

Parameter Name	Attribute value
Maker	NXP
Parts packaging code	SOIC
package instruction	SOP,
Contacts	28
Reach Compliance Code	unknown
ECCN code	EAR99
Has ADC	NO
Address bus width
bit size	8
maximum clock frequency	22 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G28
length	17.925 mm
Number of I/O lines	16
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
ROM programmability	OTPROM
Maximum seat height	2.65 mm
speed	2.2 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	HCMOS
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	7.5 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

View All

Freescale Semiconductor, Inc.

MC68HC05X4/D Rev 1.0

Freescale Semiconductor, Inc...

MC68HC05X4

MC68HC705X4

HCMOS Microcontroller Unit

TECHNICAL DATA

For More Information On This Product,

Go to: www.freescale.com

Freescale Semiconductor, Inc.

Table of Contents

Introduction

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Mask options on the MC68HC05X4 . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Mask options on the MC68HC705X4 . . . . . . . . . . . . . . . . . . . . . . . . . 12

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Single chip mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Bootloader modes for the MC68HC05X4 and MC68HC705X4 . . . . . 15

Pin descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

CPU Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Arithmetic/Logic Unit (ALU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Instruction Set Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Addressing Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Instruction Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Resets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Interrupts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Low power modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Memory map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Non-volatile memory (NVM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

MCU registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

MCAN registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Freescale Semiconductor, Inc...

Modes of Operation

and Pin Descrip-

tions

CPU

Resets, Interrupts

and Low Power

Modes

Memory

MC68HC05X4 Rev 1.0

Table of Contents

For More Information On This Product,

Go to: www.freescale.com
