HELIAX
Connector
P R O D U C T
S P E C I F I C A T I O N
®
A5PDM-RCN
7-16 DIN MALE RINGFLARE for AVA5-50
CHARACTERISTICS
Components
FRONT BODY
INNER CONTACT
REAR BODY
SLIP RING
COUPLING NUT
SPRING RING
SNAP RING
INSULATOR
O-RING {SELF-LUBRICATED}
O-RING {SELF-LUBRICATED}
O RING
O RING
O RING
SAW GUIDE
Electrical
Customer Support Center:
1-800-255-1479
From North America:
+1-708-873-2307
International:
www.andrew.com
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Material:
Brass
Phosphor Bronze
Brass
Brass
Brass
Spring Steel
Phosphor Bronze
Polymethylpentene
Silicone Rubber
Silicone Rubber
Silicone Rubber
Silicone Rubber
Silicone Rubber
Nylon
Exterior finish: Trimetal Plate
Exterior finish: Silver Plate
Exterior finish: Trimetal Plate
Exterior finish: Trimetal Plate
Exterior finish: Trimetal Plate
Exterior finish: Passivate
This Specification Sheet is for reference only and is subject to change without notice.
Copyright © 2003 Andrew Corporation
12 December 2003
1
HELIAX
Connector
P R O D U C T
S P E C I F I C A T I O N
®
A5PDM-RCN
7-16 DIN MALE RINGFLARE for AVA5-50
Recommended maximum operating frequency, GHz
Peak power, max, kW
Average power, max, kW @ 900 MHz
dc test maximum voltage
RF operating voltage, max, VRMS
RF high potential, max, VRMS
Inner contact resistance, milliohms (Outer)
3rd order IM, product typical @ 910 MHz, -dBm (Method)
Insulation resistance, min, Megaohms
Shielding effectiveness, dB
Insertion loss, max, dB
Connector Return Loss, dB
Start
Stop
0.00 -
2.20 GHz
2.21 -
3.00 GHz
Mechanical
Inner attachment method
Outer attachment method
Connector weight, g
Pressurizable
Coupling nut retention force, N (lb)
Method
Minimum coupling nut torque, N-m (lb-in)
Insertion force, N (lb)
Method
Minimum connector retention tensile force, N (lb)
Minimum connector retention torque, N-m (lb-in)
Attachment durability, number of cycles
Interface durability, number of cycles
Environmental
Moisture resistance test
Mechanical shock test
Corrosion test
Thermal shock test
Vibration test
Operating temperature range, °C
Storage temperature range, °C
Immersion test, unmated connectors
Immersion depth, m
Water jetting test, unmated connectors
Return Loss
39.30
39.00
Captivated
Ring-Flare
238.00
No
1,000.00 (224.81)
MIL-C-39012C-3.25,4.6.22
25.00 (221.27)
200.00 (44.96)
MIL-C-39012C-3.12,4.6.9
1,335.00 (300.12)
8.10 (71.69)
25
50
MIL-STD-202F, Method 106F
MIL-STD-202F, Method 213B, Test Condition C
MIL-STD-1344A, Method 1001.1, Test Cond. A
MIL-STD-202F,Method 107G,Test Cond. A-1,Low
Temp-55°C
IEC 68, Part 2-6
-55.00°C - 85.00°C
-55.00°C - 85.00°C
IEC 529:1989,IP68
1.00
IEC 529:1989,IP66
5.00
40.00
2.34
4,000.00
1,415.00
1,980.00
0.80 (1.50)
120.00
5,000.00
-130.00
0.05
frequency(GHz)
Connector Limited
Cable Limited
Connector Limited
Cable Limited
Connector Limited
Connector Limited
Connector Limited
Customer Support Center:
1-800-255-1479
From North America:
+1-708-873-2307
International:
www.andrew.com
This Specification Sheet is for reference only and is subject to change without notice.
Copyright © 2003 Andrew Corporation
12 December 2003
2
