ISL99202

OBSOLETE PRODUCT

NO RECOMMENDED REPLACEMENT

contact our Technical Support Center at

1-888-INTERSIL or www.intersil.com/tsc

DATASHEET

FN6758

Rev 2.00

December 12, 2012

60mW, Capfree, Stereo Headphone Amplifier

The ISL99202 is a stereo, capfree headphone amplifier. The

wide operating voltage of 2.4V to 5.5V makes it versatile

enough to be used in mobile battery powered applications

powered by 2 AA or Single cell Li-Ion batteries as well as

3.3/5V power supply available notebook computers.

The ISL99202 has robust RF immunity, which makes it

ideally suited for today’s mobile applications.

It has audiophile quality SNR and THD specifications and

Click/Pop suppression.

The ISL99202 comes with Comprehensive Protection

features, which include undervoltage and short-circuit

protection and thermal shutdown.

The ISL99202 lowest power consumption in the industry is

achieved by low I

qq

and current shutdown.

The product is available in 12 Ld TQFN.

Features

• Supports 16Ω to 600Ω speaker impedance

• Ground referenced: No output coupling capacitors

• Audiophile quality sound THD of 0.01%, SNR of 102dB

• PSRR < -90dB, no need for LDO

• Wide operating voltage of 2.4V to 5.5V

• < 3mA quiescent current and 0.1µA shutdown current

• State of the art pop and click suppression

• Pb-Free (RoHS Compliant)

Applications

• Mobile phones

• MP3 players

Ordering Information

PART

NUMBER

ISL99202IRTAZ (Notes 1, 2)

ISL99202IRTAZ-T (Notes 1, 2)

202A

PART

MARKING

GAIN SETTING

(dB)

-1.5V/V

TEMP. RANGE

(°C)

-40 to +85

PACKAGE

(Pb-Free)

12 Ld 3x3 TQFN

PKG.

DWG. #

L12.3x3Z

ISL99202IRTAZ-TK (Notes 1, 2) 202A

ISL99202IRTAEVZ

NOTES:

1. Please refer to

TB347

for details on reel specifications.

Evaluation Board

2. These Intersil Pb-free plastic packaged products employ special Pb-free material sets, molding compounds/die attach materials, and 100% matte

tin plate plus anneal (e3 termination finish, which is RoHS compliant and compatible with both SnPb and Pb-free soldering operations). Intersil

Pb-free products are MSL classified at Pb-free peak reflow temperatures that meet or exceed the Pb-free requirements of IPC/JEDEC J STD-20.

FN6758 Rev 2.00

December 12, 2012

Page 1 of 11

ISL99202

Pinouts

ISL99202

(12 LD TQFN)

TOP VIEW

10 OUTR

9 SVSS

THERMAL

PAD

8 INR

7 SGND

PVSS 4

SDB 5

INL 6

11 OUTL

12 VDD

CP 1

PGND 2

CN 3

Pin Descriptions

PIN NUMBER

1

2

3

4

5

6

7

8

9

10

11

12

PIN NAME

CP

PGND

CN

PVSS

SDB

INL

SGND

INR

SVSS

OUTR

OUTL

VDD

Charge pump positive terminal

Charge pump Ground

Charge pump negative terminal

Charge pump output

Active low shutdown input

Left channel input

Analog ground

Right channel input

Amplifier negative supply

Right channel output

Left channel output

Positive power supply

DESCRIPTION

NOTE: Exposed Pad is connected to PGND and SGND

FN6758 Rev 2.00

December 12, 2012

Page 2 of 11

ISL99202

Absolute Maximum Ratings

(Reference to GND)

Supply Voltage

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

-0.3V to 6V

INR, INL, CP, SDB . . . . . . . . . . . . . . . . . . . . . . -0.3V to V

DD

+ 0.3V

ESD Rating

Human Body Model

All pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2kV

OUTL, OUTR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8kV

Machine Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200V

Thermal Information

Thermal Resistance (Typical, Notes 3, 4)



JA

(°C/W)



JC

(°C/W)

TQFN Package . . . . . . . . . . . . . . . . . . . .

54

8

Maximum Junction Temperature (Plastic Package) -65°C to +150°C

Maximum Storage Temperature Range . . . . . . . . . .-65°C to +150°C

Dissipation Ratings

Derating Factor

12 LD 3x3 TQFN . . . . . . . . . . . . . . . . . . . . . . . . . . .14.7mW/°C

Power Rating T

A

12 Ld 3x3 TQFN

+25°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.84W

+70°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.12W

+85°C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.96W

Pb-Free Reflow Profile. . . . . . . . . . . . . . . . . . . . . . . . .see link below

http://www.intersil.com/pbfree/Pb-FreeReflow.asp

Operating Conditions

Ambient Temperature Range . . . . . . . . . . . . . . . . . . .-40°C to +85°C

Maximum Supply Voltage (VDD Pin) . . . . . . . . . . . . . . . . . . . . . 5.5V

Operating Supply Voltage (VDD Pin) . . . . . . . . . . . . . . . . 2.4V to 5V

CAUTION: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such conditions may adversely impact product reliability and

result in failures not covered by warranty.

NOTES:

3.



JA

is measured in free air with the component mounted on a high effective thermal conductivity test board with “direct attach” features. See

Tech Brief

TB379.

4. For theta



JC

the “case temp.” location is the center of the exposed metal pad on the package underside.

Electrical Specifications

Typical Values are Tested at V

DD

= 5V, T

A

= +25°C and R

L

= 32.

PARAMETER

OUTPUT POWER

Output Power

P

OUT

R

L

= 32,THD = 1%

R

L

= 16

Total Harmonic Distortion + Ratio

THD+N

R

L

= 1k,V

OUT

= 1.5V

RMS

, f = 1kHz

R

L

= 32,P

OUT

= 50mW, f = 1kHz

R

L

= 16,P

OUT

= 35mW, f = 1kHz

PROTECTION

Thermal Shutdown

Thermal Shutdown Hysteresis

Overcurrent Protection

Undervoltage Shutdown

LOGIC INPUTS (SDB)

Input Voltage High

Input Voltage Low

POWER SUPPLY

Supply Voltage Range

Power Supply Rejection Ratio

V

DD

PSRR

V

DD

= 2.5V to 5.0V at 217Hz

V

DD

= 2.5V to 5.0V at 1kHz

V

DD

= 2.5V to 5.0V at 20kHz

Quiescent Current

Shutdown Current

I

qq

I

SDB

V

DD

= 5.0V

SDB = GND, V

DD

= 5.0V

2.4

96

88

76

3

0.1

4.6

1.1

5.5

V

dB

mA

µA

V

INH

V

INL

1.4

0.9

V

OCP

OTP

160

15

200

2.4

°C

mA

V

30

63

70

0.003

0.01

0.02

mW

%

SYMBOL

TEST CONDITIONS

MIN

(Note 5)

TYP

MAX

(Note 5) UNITS

FN6758 Rev 2.00

December 12, 2012

Page 3 of 11

ISL99202

Electrical Specifications

Typical Values are Tested at V

DD

= 5V, T

A

= +25°C and R

L

= 32.

(Continued)

PARAMETER

GAIN CONTROL

Voltage Gain

Ch to Ch Gain Tracking

Total Harmonic Distortion + Ratio

THD+N

R

L

= 1k,V

OUT

= 1.5V

RMS

, f = 1kHz

R

L

= 32,P

OUT

= 50mW, f = 1kHz

R

L

= 16,P

OUT

= 35mW, f = 1kHz

NOISE PERFORMANCE

Signal to Noise Ratio

SNR

R

L

= 1k, V

OUT

= 1.5V

RMS

, BW = 22Hz to 20kHz

R

L

= 1k, V

OUT

= 1.5V

RMS

, BW = 22Hz to 20kHz, A-weighted

R

L

= 32, P

OUT

= 35mW, BW = 22Hz to 20kHz

R

L

= 32, P

OUT

= 35mW, BW = 22Hz to 20kHz, A-weighted

Slew Rate

Capacitve Drive

Crosstalk

Charge Pump Oscillation

Frequency

Click and Pop Level

V

DD

= 3.0V

Power Supply Rejection Ratio

PSRR

217Hz

1kHz

20kHz

Quiescent Current

Shutdown Current

Output Offset Voltage

Output Power at 32Load

Output Power at 16Load

Total Harmonic Distortion + Noise

Ratio

THD+N

I

qq

I

SDB

VOS

R

L

= 32,THD = 1%

R

L

= 16,THD = 1%

R

L

= 1k,V

OUT

= 1.5V

RMS

, f = 1kHz

R

L

= 32,P

OUT

= 50mW, f = 1kHz

R

L

= 16,P

OUT

= 35mW, f = 1kHz

NOTE:

5. Parameters with MIN and/or MAX limits are 100% tested at +25°C, unless otherwise specified. Temperature limits established by characterization

and are not production tested.

SDB = GND

-1

96

88

76

2.4

0.1

0.05

54

56

0.005

0.01

0.02

3.6

1.1

1

dB

mA

µA

mV

mW

%

SR

C

L

xtalk

f

soc

K

CP

R

L

= 32,Peak voltage, Awtg. 32 sam/sec

R

L

= 16,P

OUT

= 15mW, f = 10kHz

400

102

105

100

113

0.5

100

-76

500

-67

600

dB

VµS

pF

dB

kHz

dB

A

V

-1.55

-1.50

±0.15

0.005

0.01

0.04

-1.45

V/V

%

SYMBOL

TEST CONDITIONS

MIN

(Note 5)

TYP

MAX

(Note 5) UNITS

FN6758 Rev 2.00

December 12, 2012

Page 4 of 11

ISL99202

Block Diagram

VDD

SDB

SDB LOGIC

CLICK AND POP

SUPPRESSION

POSITIVE VOLTAGE

REGULATOR

PVSS

BIAS AND REFERENCE

INR

-

AMPR

+

SGND

SVSS

+

INL

AMPL

-

OVERCURRENT

PROTECTION

OUTR

OUTL

PGND

DYNAMICALLY

ADJUSTED

VOLTAGE

REGULATOR

PVSS

CP

CN

CLOCK GENERATOR

Typical Performance Curves

100

V

DD

= 3V

R

L

= 16

THD + NOISE RATIO (%)

10

100

V

DD

= 3V

R

L

= 32

10kHz

10

1.0

20Hz

0.1

10kHz

1.0

20Hz

0.1

0.01

1kHz

0.01

1kHz

0.001

1

10

OUTPUT POWER (mW)

100

0.001

1

10

OUTPUT POWER (mW)

100

FIGURE 1. TOTAL HARMONIC DISTORTION + NOISE RATIO

vs OUTPUT POWER

FIGURE 2. TOTAL HARMONIC DISTORTION + NOISE RATIO

vs OUTPUT POWER

FN6758 Rev 2.00

December 12, 2012

Page 5 of 11
