RoHS
FC10
0.115 MAX.
(2.92)
Ferrite Core Chip Inductors
Dimensions:
0.110 MAX.
(2.79)
0.083 MAX.
(2.11)
Inches
(mm)
0.020±0.004
(0.51±0.10)
0.015±0.004
(0.38±0.10)
0.080±0.004
(2.03±0.10)
0.050
(1.27)
0.100
(2.54)
0.040
(1.02)
Allied
Part
Number
FC10-R005K-RC
FC10-R010K-RC
FC10-R012K-RC
FC10-R015K-RC
FC10-R018K-RC
FC10-R022K-RC
FC10-R027K-RC
FC10-R033K-RC
FC10-R039K-RC
FC10-R047K-RC
FC10-R056K-RC
FC10-R068K-RC
FC10-R082K-RC
FC10-R10K-RC
FC10-R12K-RC
FC10-R15K-RC
FC10-R18K-RC
FC10-R22K-RC
FC10-R27K-RC
FC10-R33K-RC
FC10-R39K-RC
FC10-R47K-RC
FC10-R56K-RC
FC10-R68K-RC
FC10-R82K-RC
FC10-1R0K-RC
FC10-1R2K-RC
FC10-1R5K-RC
FC10-1R8K-RC
FC10-2R2K-RC
FC10-2R7K-RC
FC10-3R3K-RC
FC10-3R9K-RC
FC10-4R7K-RC
FC10-5R6K-RC
FC10-6R8K-RC
FC10-8R2K-RC
FC10-100K-RC
FC10-120K-RC
FC10-150K-RC
FC10-180K-RC
FC10-220K-RC
FC10-270K-RC
FC10-330K-RC
FC10-390K-RC
FC10-470K-RC
FC10-560K-RC
FC10-680K-RC
FC10-820K-RC
FC10-101K-RC
Inductance
(µh)
.005
.010
.012
.015
.018
.022
.027
.033
.039
.047
.056
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
Tolerance
(%)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
Min.
10
10
15
15
15
20
20
30
35
35
35
35
35
35
30
30
30
30
30
30
30
30
30
30
30
25
25
25
25
25
25
25
25
25
20
20
20
15
15
15
15
15
15
15
10
10
10
10
10
8
Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
.796
SRF
Min.
(MHz)
3000
2500
2400
2300
2200
2100
2000
1600
1500
1400
1300
1200
1100
800
700
550
500
450
425
400
375
350
325
300
260
245
230
182
135
105
70
55
48
43
42
39
36
33
30
26
24
22
21
20
18
17
16
15
13
12
DCR
Max.
(Ω)
0.25
0.25
0.26
0.28
0.30
0.35
0.40
0.42
0.45
0.50
0.60
0.65
0.75
0.80
0.30
0.35
0.40
0.50
0.55
0.60
0.65
0.68
0.75
0.85
1.00
1.10
1.20
1.30
1.45
1.55
1.70
1.90
2.10
2.30
2.50
2.70
3.05
3.50
3.80
4.40
4.80
5.50
6.30
7.10
9.50
11.1
12.1
16.6
19.0
21.0
Rated
Current
(mA)
2000
1800
1700
1600
1550
1500
1450
1400
1350
1300
1250
1240
1230
1220
900
900
850
840
830
820
810
800
800
800
800
800
790
750
750
750
740
730
700
650
640
630
600
600
550
430
400
400
360
350
330
300
270
250
200
120
Features
•
Excellent solderability and resistance to
soldering heat
•
Suitable for flow and reflow soldering
•
High reliabilty and easy surface mount
assembly
•
Wide inductance value range
Electrical
Inductance Range:
.005µh to 100µh.
Tolerance:
For 10% use K and 5% use
J as part number suffix.
Operating Temp. Range:
i-25°
to +85°C.l
Test Equipment:
Inductance, Q and DCR,
tested on an HP4286A. SRF tested on an
HP8753D and HP4286A.After
soldering,
push l0 to 2000) x 10
-6
°C.
Physical
Marking:
Color Code using standard EIA
three dot system.
Packaging:
2000 pieces per 7 inch reel.
Available in tighter tolerances.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 10/17/08
www.alliedcomponents.com
