Power Chip Inductors
Dimensions:
Inches
(mm)
PC03021
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Test
Freq.
DCR
(Ω)
IDC
(A)
Features
• Unshielded SMD Power Inductor
• Available in magnetically shielded
• Suitable for large currents
• Ideal for DC-DC converter applications
Electrical
Inductance Range:
1µh to 1000µh
Tolerance:
20% over entire range
Also available in tighter tolerances
Operating Temp:
-40ºC ~ +85ºC
IDC:
Current at which Inductance drops 10%
of original value with a
∆
T= 40ºC
whichever
is lower.
PC03021-1R0M-RC
PC03021-1R4M-RC
PC03021-1R5M-RC
PC03021-1R8M-RC
PC03021-2R2M-RC
PC03021-2R7M-RC
PC03021-3R3M-RC
PC03021-3R9M-RC
PC03021-4R7M-RC
PC03021-5R6M-RC
PC03021-6R8M-RC
PC03021-7R0M-RC
PC03021-8R2M-RC
PC03021-100M-RC
PC03021-120M-RC
PC03021-150M-RC
PC03021-180M-RC
PC03021-220M-RC
PC03021-270M-RC
PC03021-330M-RC
PC03021-390M-RC
PC03021-470M-RC
PC03021-500M-RC
PC03021-560M-RC
PC03021-680M-RC
PC03021-750M-RC
PC03021-820M-RC
PC03021-101M-RC
PC03021-121M-RC
PC03021-151M-RC
PC03021-181M-RC
PC03021-221M-RC
PC03021-271M-RC
PC03021-301M-RC
PC03021-331M-RC
PC03021-391M-RC
PC03021-461M-RC
PC03021-471M-RC
PC03021-561M-RC
PC03021-681M-RC
PC03021-821M-RC
PC03021-102M-RC
1.0
1.4
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
7.0
8.2
10
12
15
18
22
27
33
39
47
50
56
68
75
82
100
120
150
180
220
270
300
330
390
460
470
560
680
820
1000
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
0.07
0.09
0.11
0.11
0.13
0.14
0.17
0.19
0.21
0.22
0.25
0.28
0.28
0.32
0.35
0.40
0.48
0.58
0.65
0.80
0.90
1.19
1.22
1.27
1.73
1.90
1.99
2.52
2.90
3.36
5.10
5.80
7.80
8.10
9.24
10.14
11.15
11.48
19.49
22.00
23.98
28.80
2.08
1.86
1.80
1.80
1.39
1.32
1.25
1.20
1.13
0.91
0.85
0.82
0.82
0.74
0.64
0.60
0.54
0.50
0.43
0.40
0.37
0.36
0.33
0.31
0.30
0.29
0.28
0.25
0.20
0.19
0.17
0.16
0.14
0.14
0.13
0.12
0.09
0.08
0.08
0.08
0.07
0.06
Resistance to Soldering Heat
Test Method:
Pre-Heat 150ºC, 1 Min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC for 10 sec ± 1 sec.
Test Equipment
(L):
HP4192A LF Impedence Analyzer
(RDC):
Chen Hwa 502BC
(IDC):
HP4284A with HP42841A or
Chen Hwa 1061 + Chen Hwa 301A
Physical
Packaging:
3000 pieces per 13 inch reel.
Marking:
2 Character Alpha Code
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 1/14/09
15
www.alliedcomponents.com
