Document 613-1
Hexa-Path Magnetics
HP1, HPH1
HP2, HPH2
HP3, HPH3
HP4, HPH4
HP5, HPH5
HP6, HPH6
• Six 1
:
1 isolated windings that can be
connected in series or parallel
• Tightly coupled windings
• 500 Vrms, one minute isolation
between each winding
• Power range: 5 – 50 Watts as inductor
and flyback transformer; up to
150 Watts as forward transformer
• Frequency range up to 1 MHz
Winding Layouts
HP1, HP2, HPH1, HPH2
Winding Layouts
HP3, HP4, HP5, HP6
Outer
6
7
8
9
4
3
10
11
12
Two trifilar windings
2
1
Three bifilar windings
HPH3, HPH4, HPH5, HPH6
Outer
6
5
7
8
12
11
10
9
8
7
3
2
1
One 6-filar winding
5
4
Middle
9
10
Inner
3
2
1
Percent of rated current
These off-the shelf parts can be used
to create thousands of configurations,
providing a convenient method for
designers to create custom magnetics.
By connecting the windings in series
or parallel, the Hexa-Path compo-
nents can be configured as inductors,
coupled inductors and transformers for
use in virtually any application: flyback,
buck/boost, push-pull, forward, full and
half bridge, Cuk, and SEPIC.
There are six different sizes available
with five HP parts and five HPH parts
in each size. The HP offers lower DCR
and higher
Irms
ratings. The HPH
offers higher inductance and greater
energy storage capabilities.
6
5
4
Inner
11
12
Current Derating
120
110
100
90
80
70
60
50
40
20
10
0
-40
-20
0
20
25°C
40
30
60
80
100
120 140
Ambient temperature (°C)
Specifications subject to change without notice.
US
+1-847-639-6400 sales@coilcraft.com
Please check
sales@coilcraft-europe.com
UK
+44-1236-730595
our website for latest information.
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 613-1
Revised 09/05/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 613-2
Hexa-Path Magnetics
Part
number
1
HP1-1400L_
HP1-0190L_
HP1-0102L_
HP1-0076L_
HP1-0059L_
HP2-1600L_
HP2-0216L_
HP2-0116L_
HP2-0083L_
HP2-0066L_
HP3-0950L_
HP3-0138L_
HP3-0084L_
HP3-0055L_
HP3-0047L_
HP4-1150L_
HP4-0140L_
HP4-0075L_
HP4-0060L_
HP4-0047L_
HP5-1200L_
HP5-0155L_
HP5-0083L_
HP5-0067L_
HP5-0053L_
HP6-2400L
HP6-0325L
HP6-0158L
HP6-0121L
HP6-0090L
HPH1-1400L_
HPH1-0190L_
HPH1-0102L_
HPH1-0076L_
HPH1-0059L_
HPH2-1600L_
HPH2-0216L_
HPH2-0116L_
HPH2-0083L_
HPH2-0066L_
HPH3-0950L_
HPH3-0138L_
HPH3-0084L_
HPH3-0055L_
HPH3-0047L_
HPH4-1150L_
HPH4-0140L_
HPH4-0075L_
HPH4-0060L_
HPH4-0047L_
HPH5-1200L_
HPH5-0155L_
HPH5-0083L_
HPH5-0067L_
HPH5-0053L_
HPH6-2400L
HPH6-0325L
HPH6-0158L
HPH6-0121L
HPH6-0090L
Inductance
2
(µH)
89.6 ±25%
12.2 ±20%
6.5 ±15%
4.9 ±10%
3.8 ±5%
78.4 ±25%
10.6 ±20%
5.7 ±15%
4.1 ±10%
3.2 ±5%
77.0 ±25%
11.2 ±20%
6.8 ±15%
4.5 ±10%
3.8 ±5%
93.2 ±25%
11.3 ±20%
6.1 ±15%
4.9 ±10%
3.8 ±5%
76.8 ±25%
9.9 ±20%
5.3 ±15%
4.3 ±10%
3.4 ±5%
86.4 ±25%
11.7 ±20%
5.69 ±15%
4.36 ±10%
3.24 ±5%
202
±25%
27.4 ±20%
14.7 ±15%
10.9 ±10%
8.5 ±5%
160
±25%
21.6 ±20%
11.6 ±15%
8.3 ±10%
6.6 ±5%
160
±25%
23.6 ±20%
14.2 ±15%
9.3 ±10%
7.94 ±5%
194
±25%
23.7 ±20%
12.7 ±15%
10.1 ±10%
7.94 ±5%
173
±25%
22.3 ±20%
12.0 ±15%
9.65 ±10%
7.63 ±5%
194
±25%
26.3 ±20%
12.8 ±15%
9.8 ±10%
7.29 ±5%
DCR
max
3
(Ohms)
0.130
0.130
0.130
0.130
0.130
0.085
0.085
0.085
0.085
0.085
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.045
0.045
0.045
0.045
0.045
0.020
0.020
0.020
0.020
0.020
0.340
0.340
0.340
0.340
0.340
0.155
0.155
0.155
0.155
0.155
0.125
0.125
0.125
0.125
0.125
0.078
0.078
0.078
0.078
0.078
0.070
0.070
0.070
0.070
0.070
0.030
0.030
0.030
0.030
0.030
Volt-time Peak energy
product
4
storage
5
(V-µsec)
(µJ)
23.4
Note 8
23.4
29.8
23.4
55.1
23.4
74.7
23.4
93.8
30.8
Note 8
30.8
79.2
30.8
184
30.8
228
30.8
252
30.4
Note 8
30.4
59.6
30.4
111
30.4
156
30.4
173
47.3
Note 8
47.3
142
47.3
307
47.3
386
47.3
490
62.8
Note 8
62.8
281
62.8
562
62.8
626
62.8
946
87.9
Note 8
87.9
332
87.9
981
87.9
1485
87.9
1833
35.1
Note 8
35.1
31.1
35.1
60.2
35.1
99.2
35.1
107
44.0
Note 8
44.0
82.3
44.0
177
44.0
302
44.0
333
43.9
Note 8
43.9
52.5
43.9
98.0
43.9
169
43.9
196
68.3
Note 8
68.3
138
68.3
314
68.3
368
68.3
529
94.2
Note 8
94.2
248
94.2
546
94.2
700
94.2
809
131.9
Note 8
131.9
477
131.9
1176
131.9
1783
131.9
1944
Isat
6
(A)
Note 8
0.440
0.820
1.10
1.40
Note 8
0.770
1.60
2.10
2.50
Note 8
0.650
1.14
1.66
1.90
Note 8
1.00
2.00
2.50
3.20
Note 8
1.50
2.90
3.40
4.70
Note 8
1.50
3.70
5.20
6.70
Note 8
0.300
0.570
0.850
1.00
Note 8
0.550
1.10
1.70
2.00
Note 8
0.420
0.740
1.20
1.40
Note 8
0.680
1.40
1.70
2.30
Note 8
0.940
1.90
2.40
2.90
Note 8
1.20
2.70
3.80
4.60
Irms
7
(A)
0.74
0.74
0.74
0.74
0.74
1.13
1.13
1.13
1.13
1.13
1.73
1.73
1.73
1.73
1.73
1.88
1.88
1.88
1.88
1.88
2.25
2.25
2.25
2.25
2.25
3.50
3.50
3.50
3.50
3.50
0.62
0.62
0.62
0.62
0.62
0.83
0.83
0.83
0.83
0.83
1.13
1.13
1.13
1.13
1.13
1.65
1.65
1.65
1.65
1.65
1.95
1.95
1.95
1.95
1.95
2.90
2.90
2.90
2.90
2.90
1. Please specify
termination
and
packaging
codes:
HPH1-1400LD
Termination: L
= RoHS compliant tin-silver over
tin over nickel over phos bronze.
Special order:
T
= RoHS tin-silver-copper
(95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: All but HP6 and HPH6:
D
= 13″ machine-ready reel.
EIA-481 embossed plastic tape
B
= Less than full reel. In tape, but
not machine ready. To have
a leader and trailer added
($25 charge), use code letter D
instead.
HP6 and HPH6:
24 per tray (no code)
2. Inductance is per winding, measured at 100 kHz,
0.1 Vrms, 0 Adc.
3. DCR is per winding, measured on Cambridge
Technology micro-ohmmeter or equivalent.
4. Volt-time product is for a single winding or multiple
windings connected in parallel. To calculate volt-
time product for windings connected in series, mul-
tiply the value specified in the table by the number
of windings connected in series.
5. Peak energy storage is for any combination of wind-
ings, assuming saturation current applied. See note
6 for definition of saturation current.
6. DC current at which the inductance drops 30% typ
from its value without current, based on current
applied to all six windings connected in series. For
applications where all windings are not connected
in series, use the following equation to calculate
Isat:
Isat
=
Isat
table
× 6 ÷ number of windings in series.
7. Current that causes a 40°C rise from 25°C ambient
due to self heating, tested with continuous current
flow through all windings connected in series.
Application temperature rise will depend on the op-
erating current, duty cycle, and winding connection.
8. Part is designed exclusively for use as a forward
converter transformer and was not tested for en-
ergy storage and saturation current.
9. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering
Core material
Ferrite
Terminations
RoHS tin-silver over tin over nickel
over phos bronze. Other terminations available at
additional cost.
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to +125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three
40 second reflows at +260°C, parts cooled to room
temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited
floor life at <30°C / 85% relative humidity)
Failures in Time (FIT)
38 per billion hours
Mean Time Between Failures (MTBF)
26,315,789 hours, calculated per Telcordia SR-332
PCB washing
Tested with pure water or alcohol only.
For other solvents, see Doc787_PCB_Washing.pdf
Document 613-2
Revised 09/05/13
Specifications subject to change without notice.
US
+1-847-639-6400 sales@coilcraft.com
Please check
sales@coilcraft-europe.com
UK
+44-1236-730595
our website for latest information.
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 613-3
Hexa-Path Magnetics
HP1, HPH1
Dot indicates pin 1
1
12
0.063
1,60
1
0.394
10,00
12
0.028
0,70
0.079
2,00
HP1-1234L
0.512 max
13,0
0.079
2,00
XXXXY
0.362
9,20
0.055
1,40
Recommended
Land Pattern
0.244max
6,20
0.433
11,00
0.512max
13,0
0.004 / 0,10
Dimensions are in
inches
mm
Weight:
1.4 g
Packaging
500 per 13″ reel Plastic tape: 24 mm wide,
0.5 mm thick, 20 mm pocket spacing, 6.6 mm pocket depth
HP2, HPH2
Dot indicates pin 1
1
0.098
2,50
0.098
2,50
1
0.512
13,00
12
0.028
0,70
0.098
2,50
12
HP2-1234L
XXXXY
0.508
12,90
0.642 max
16,30
0.069
1,75
Recommended
Land Pattern
0.291max
7,40
0.575
14,60
0.661max
16,80
0.004 / 0,10
Dimensions are in
inches
mm
Weight:
2.7 – 2.8 g
Packaging
400 per 13″ reel Plastic tape: 32 mm wide,
0.4 mm thick, 20 mm pocket spacing, 7.6 mm pocket depth
Specifications subject to change without notice.
US
+1-847-639-6400 sales@coilcraft.com
Please check
sales@coilcraft-europe.com
UK
+44-1236-730595
our website for latest information.
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 613-3
Revised 09/05/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 613-4
Hexa-Path Magnetics
HP3, HPH3
Dot indicates pin 1
1
12
0.135
3,43
0.098
2,50
1
0.665
16,88
12
0.028
0,70
0.098
2,50
HP3-1234L
XXXXY
0.591
15,00
0.677 max
17,20
0.069
1,75
Recommended
Land Pattern
0.291max
7,40
0.693
17,60
0.865 max
22,00
0.004 / 0,10
Dimensions are in
inches
mm
Weight:
4.2 – 4.6 g
Packaging
200 per 13″ reel Plastic tape: 44 mm wide,
0.4 mm thick, 28 mm pocket spacing, 9.6 mm pocket depth
HP4, HPH4
Dot indicates pin 1
1
12
0.130
3,30
0.100
2,54
1
0.748
19,0
12
0.028
0,70
0.100
2,54
HP4-1234L
XXXXY
0.699
17,00
0.685 max
17,40
Recommended
Land Pattern
0.069
1,75
0.382 max
9,70
0.004 / 0,10
0.799
20.30
0.950 max
24,13
Dimensions are in
inches
mm
Weight:
6.8 – 7.5 g
Packaging
200 per 13″ reel Plastic tape: 44 mm wide,
0.4 mm thick, 24 mm pocket spacing, 10.56 mm pocket depth
Specifications subject to change without notice.
US
+1-847-639-6400 sales@coilcraft.com
Please check
sales@coilcraft-europe.com
UK
+44-1236-730595
our website for latest information.
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 613-4
Revised 09/05/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 613-5
Hexa-Path Magnetics
HP5, HPH5
1
Dot indicates pin 1
12
0.130
3,3
0.118
3,00
1
0.930
23,62
12
0.028
0,70
HP5-1234L
XXXXY
0.118
3,00
0.810 max
20,57
Recommended
Land Pattern
0.069
1,75
0.827
21,0
0.425 max
10,80
0.969
24,6
1.148
max
29,15
0.004 / 0,10
Dimensions are in
inches
mm
Weight:
10.6 – 11.5 g
Packaging
175 per 13″ reel Plastic tape: 44 mm wide,
0.4 mm thick, 28 mm pocket spacing, 12.0 mm pocket depth
HP6, HPH6
Dot indicates pin 1
1
0.108
2,75
12
1
1.10
28,2
12
0.039
1,00
0.148
3,75
1.053 max
26,75
HP6-1234L
XXXXY
Recommended
Land Pattern
0.148
3,75
0.079
2,00
1.024
26,0
0.535 max
13,6
1.173
29,80
1.285 max
32,65
0.004 / 0,10
Dimensions are in
inches
mm
Weight:
22.4 – 24.3 g
Packaging
24 per tray
Specifications subject to change without notice.
US
+1-847-639-6400 sales@coilcraft.com
Please check
sales@coilcraft-europe.com
UK
+44-1236-730595
our website for latest information.
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 613-5
Revised 09/05/13
© Coilcraft Inc. 2014
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
京公网安备 11010802033920号
EEWORLD
