TL02M553.00 - Rev B - Page 1 of 1
Product Family:
Part Number Series:
High Precision Chip Inductors
HPL Series
Construction:
High Purity Alumina Substrate
Wrap around electrodes
100% matte tin over Ni terminations
(RoHS compliant and Pb Free)
Features:
0201, 0402 English case sizes
Inductor values between 1-18nH
E-24 values
High volume production suitable for
commercial and special applications
Description:
These precision chip inductors are adjustment free due to their tight tolerance. These parts offer a high self-resonance
frequency along with a high Q value and excellent current rating for their size.
Product Dimensions:
Dimension
HPL0603
(0201)
L
0.024
±0.002
0.039
±0.004
W
T1
T2
0.003
±0.002
0.006
±0.004
H
0.011
±0.002
0.016
±0.004
0.012
0.005
±0.002 ±0.002
0.020
0.010
±0.004 ±0.004
HPL1005
(0402)
Note: Dimensions in inches but use metric size when ordering
as shown in the part numbering section. English size is shown in
parenthesis.
Electrical Specifications:
Type
English Size
Metric Size
Inductance Range
Inductance Tolerance
@ 300MHz
Q-Value
@ 500MHz
@ 800MHz (typ)
@1.5GHz (typ)
Self Resonance Frequency (GHz)
DC Resistance (Ω)
Rated Current (A)
1.0 ~ 5.6nH
(E-24 values)
±0.1nH (-E02),
±0.2nH
HPL0603
0201
0603
6.2 ~ 10nH
(E-24 values)
±2.0%
1.0 ~ 9.1nH
(E-24 values)
±0.1nH (-E02),
±0.2nH
HPL1005
0402
1005
10 ~ 18nH
(E-24 values)
±2.0%
---
10
17~14
25~18
10~6.0
0.1~0.8
0.5~0.2
---
10~8
16~14
20~18
3.5
0.8~1.5
0.2~0.15
20~15
---
35~25
50~30
7.0~4.0
0.01~0.4
1.8~0.34
15~13
---
25~20
30~25
3.5
0.5~0.8
0.3~0.24
HPL Series Part Numbering:
Ex: HPL10059N1
Product
Designator
HPL
Metric Size
(English)
0603 (0201)
1005 (0402)
Inductance Value
3 digits with “N” denoting
decimal position
(Ex. 9N1 = 9.1nH)
Tight Tolerance Designator
-E02 (±0.1nH)
(used to designate ±0.1nH tolerance only. Leave blank
for other tolerances. Refer to electrical table above for
availability of ±0.1nH tolerance)
Thin Film Technology Corp. / 1980 Commerce Drive, North Mankato, MN 56003 (USA) / (507) 625-8445 /
www.thin-film.com
