T-1 (3mm) RIGHT ANGLE LED INDICATOR
L-934JQ/2ID
L-934JQ/2SRD
L-934JQ/2YD
L-934JQ/2GD
HIGH EFFICIENCY RED
SUPER BRIGHT RED
YELLOW
GREEN
Features
!
PRE-TRIMMED LEADS FOR PC BOARD MOUNTING.
!
COLORS
Description
The High Efficiency Red source color devices are made
with Gallium Arsenide Phosphide on Gallium Phosphide
Orange Light Emitting Diode.
The Super Bright Red source color devices are made
with Gallium Aluminum Arsenide Red Light Emitting
Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
CAN BE MIXED IN A SINGLE HOUSING.
!
I.C. COMPATIBLE.
!
BLACK
!
HIGH
!
UL
CASE ENHANCES CONTRAST RATIO.
RELIABILITY - LIFE MEASURED IN YEARS.
RATING : 94V-0.
MATERIAL: TYPE 66 NYLON.
!
HOUSING
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAD0576
APPROVED: J.LU
REV NO: V.1
CHECKED: Allen Liu
DATE: MAR/09/2003
DRAWN: X.T.HU
PAGE: 1 OF 6
Selection Guide
Iv (m c d )
@ 10m A *20m A
Min .
L-934JQ/2ID
L-934JQ/2SRD
L-934JQ/2YD
L-934JQ/2GD
HIGH EFFICIENCY RED (GaAsP/GaP)
SUPER BRIGHT RED (GaAlAs)
YELLOW (GaAsP/GaP)
GREEN (GaP)
RED DIFFUSED
RED DIFFUSED
YELLOW DIFFUSED
GREEN DIFFUSED
8
*110
5
8
Ty p .
20
*300
15
20
V i ew i n g
An g l e
2θ1/2
60°
60°
60°
60°
P ar t N o .
Dic e
L en s Ty p e
Notes:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
2. * Luminous intensity with asterisk is measured at 20mA.
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
P ar am et er
D ev i c e
High Efficiency Red
Super Bright Red
Yellow
Green
High Efficiency Red
Super Bright Red
Yellow
Green
Ty p .
627
660
590
565
625
640
588
568
45
20
35
30
15
45
20
15
2.0
1.85
2.1
2.2
2.5
2.5
2.5
2.5
10
Max .
Un its
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
I
F
= 2 0 m A
λ
D
Dominate Wavelength
nm
I
F
= 2 0 m A
∆λ
1/2
High Efficiency Red
Super Bright Red
Spectral Line Half-width Yellow
Green
Capacitance
High Efficiency Red
Super Bright Red
Yellow
Green
High Efficiency Red
Super Bright Red
Yellow
Green
All
nm
I
F
= 2 0 m A
C
pF
V
F
= 0 V;f= 1 M Hz
V
F
Forward Voltage
V
I
F
= 2 0 m A
I
R
Reverse Current
uA
V
R
= 5V
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 2mm below package base.
H i g h E f f i c i en c y R ed
105
30
160
5
S u p er B r i g h t R ed
100
30
155
5
Yello w
105
30
140
5
Gr een
105
25
140
5
Un its
mW
mA
mA
V
-40
°
C To +85
°C
260
°
C For 5 Seconds
SPEC NO: DSAD0576
APPROVED: J.LU
REV NO: V.1
CHECKED: Allen Liu
DATE: MAR/09/2003
DRAWN: X.T.HU
PAGE: 2 OF 6
