PCS62
Power Chip Shielded Inductors
Inches
(mm)
Dimensions:
Features
• Shielded SMD Power Inductor
• Available in magnetically shielded
• Low DC resistance
• Ideal for DC-DC converter
applications
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Test
Freq.
DCR
Max.
(Ω)
IDC
(A)
PCS62-2R9M-RC
PCS62-3R3M-RC
PCS62-4R0M-RC
PCS62-4R7M-RC
PCS62-5R5M-RC
PCS62-6R8M-RC
PCS62-8R2M-RC
PCS62-100M-RC
PCS62-120M-RC
PCS62-150M-RC
PCS62-180M-RC
PCS62-220M-RC
PCS62-270M-RC
PCS62-330M-RC
PCS62-390M-RC
PCS62-470M-RC
PCS62-560M-RC
PCS62-680M-RC
PCS62-820M-RC
PCS62-101M-RC
PCS62-121M-RC
PCS62-151M-RC
2.9
3.3
4.0
4.7
5.5
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
7.96MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
2.52MHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
1KHz,1V
0.06
.068
0.08
0.08
.096
0.10
0. 10
0.15
0.20
0.23
0.27
0.34
0.38
0.45
0.49
0.69
0.78
1.07
1.21
1.39
1.90
2.18
2.77
3.12
4.38
4.94
2.00
1.94
1.63
1.63
1.40
1.33
1.14
1.10
1.00
0.90
0.80
0.74
0.66
0.59
0.54
0.50
0.46
0.42
0.38
0.34
0.31
0.28
0.26
0.23
0.22
0.19
Electrical
Inductance Range:
2.9µh ~ 330µh
Tolerance:
20% over entire range
Test Frequency:
As specified with 1v OSC
Operating Temp:
-40ºC~85ºC
IDC:
Current at which inductance drop
= 35% typ.
Resistance to Soldering Heat
Pre-Heat 150ºC, 1min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC for
10 sec. +/- 1 sec.
Test Equipment
(L):
HP4192A LF Impedance Analyzer
(RDC):
Chen Hwa 502
(IDC):
Chen Hwa 1061 + Chen Hwa 301A
or HP4284A + HP42841A
Physical
Packaging:
1500 pieces per 13 inch reel.
Marking:
EIA Inductance Code
PCS62-181M-RC
PCS62-221M-RC
PCS62-271M-RC
PCS62-331M-RC
