RoHS
RFC20
Radial Flat Coils
Dimensions:
Inches
(mm)
0.40
MAX.
(10.16)
0.15±0.05
(3.81±1.27)
0.35±0.05
(8.89±1.27)
1.0
NOMINAL
(25)
24AWG
0.35±0.05
(8.89±1.27)
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Q
Min.
Test
Freq.
(MHz)
Features
•
Radial leaded for easy P.C.B. mounting.
•
Narrow Design ideal for densely
populated boards.
•
Wide range of inductance values.
•
Non-standard values available upon
request.
Electrical
Inductance Range:
1.0µh to 10,000µh
Tolerance:
±10%
on all values.
Testing:
Inductance and Q measured on
HP4342A at specified frequency.
Operating Temp. Range:
-20° to +100°C.
Rated Current:
Based on
∆
T= 20ºC
temperature rise.
Physical
Marking (On Part):
4 Dot EIA Code.
Marking (On Reel):
Manufacturers
Name, Part Number, Customers
Part Number, Invoice Number, Lot
or Data Code.
DCR
Max.
(Ω)
Rated
Current
(A)
Packaging:
250 pieces per bag.
RFC20-1R0K-RC
RFC20-1R2K-RC
RFC20-1R5K-RC
RFC20-1R8K-RC
RFC20-2R2K-RC
RFC20-2R5K-RC
RFC20-2R7K-RC
RFC20-3R3K-RC
RFC20-3R9K-RC
RFC20-4R7K-RC
RFC20-5R0K-RC
RFC20-5R6K-RC
RFC20-6R8K-RC
RFC20-7R6K-RC
RFC20-8R2K-RC
RFC20-100K-RC
RFC20-120K-RC
RFC20-150K-RC
RFC20-180K-RC
RFC20-220K-RC
RFC20-250K-RC
RFC20-270K-RC
RFC20-330K-RC
RFC20-390K-RC
RFC20-470K-RC
RFC20-560K-RC
RFC20-680K-RC
RFC20-750K-RC
RFC20-820K-RC
RFC20-101K-RC
RFC20-121K-RC
RFC20-151K-RC
RFC20-181K-RC
RFC20-221K-RC
RFC20-251K-RC
RFC20-271K-RC
RFC20-331K-RC
RFC20-391K-RC
RFC20-471K-RC
RFC20-501K-RC
RFC20-561K-RC
RFC20-681K-RC
RFC20-751K-RC
RFC20-821K-RC
RFC20-102K-RC
RFC20-122K-RC
RFC20-152K-RC
RFC20-182K-RC
RFC20-222K-RC
RFC20-252K-RC
RFC20-272K-RC
RFC20-332K-RC
RFC20-392K-RC
RFC20-472K-RC
RFC20-562K-RC
RFC20-602K-RC
RFC20-682K-RC
RFC20-752K-RC
RFC20-822K-RC
RFC20-103K-RC
1.0
1.2
1.5
1.8
2.2
2.5
2.7
3.3
3.9
4.7
5.0
5.6
6.8
7.6
8.2
10
12
15
18
22
25
27
33
39
47
56
68
75
82
100
120
150
180
220
250
270
330
390
470
500
560
680
750
820
1000
1200
1500
1800
2200
2500
2700
3300
3900
4700
5600
6000
6800
7500
8200
10000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
37
39
35
37
37
40
43
35
37
37
40
38
29
30
32
80
40
40
40
40
50
50
45
45
45
40
40
40
50
80
70
70
70
50
40
50
50
45
40
35
40
45
30
40
70
70
62
62
60
60
60
50
50
50
30
35
23
25
23
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.015
.012
.014
.020
.025
.030
.028
.036
.050
.053
.080
.092
.113
.110
.116
.119
.140
.158
.180
.230
.285
.300
.346
.371
.502
.687
.808
1.200
1.450
1.160
1.725
1.855
2.070
2.105
2.500
2.700
3.335
3.450
5.290
5.350
5.405
5.930
6.200
6.325
8.600
10.00
14.26
15.75
17.70
18.00
19.10
21.74
26.00
28.90
32.00
31.00
45.00
50.00
57.00
70.00
7.0
6.0
5.0
4.8
4.4
4.1
4.0
3.7
3.4
3.2
2.9
2.8
2.6
2.5
2.2
2.1
2.0
1.6
1.6
1.4
1.3
1.3
1.2
1.1
1.03
.95
.90
.86
.86
.70
.65
.60
.58
.49
.49
.45
.41
.39
.35
.34
.32
.29
.28
.27
.21
.21
.19
.17
.15
.14
.14
.13
.12
.11
.10
.10
.07
.08
.07
.07
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 08/09/08
www.alliedcomponents.com
