F-211 SUPPLEMENT
YFW–20–07–H–10–SB
®
(1,27mm) .050"
YFW–30–25–H–10–SB
YFW–20–07–H–05–SB
YFW SERIES
ELEVATED OPEN PIN FIELD STACKER
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?YFW
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Brass
Current Rating:
2A @ 80°C ambient
Operating Temp Range:
-55°C to +125°C
Plating:
Au over 50µ" (1,27µm) Ni
RoHS Compliant:
No
Lead-Free Solderable:
No
Mates with:
YFS
Five, eight
or ten rows
(1,27mm)
.050"
pitch
®
fina
l
i
nch.com
Polarized
Choice of
board stack
heights
Tin-Lead
Solder Balls
TYPE
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
below.
PLATING
OPTION
ROW
OPTION
SB
OTHER
OPTION
YFW
= Stacker
– 20, – 30,
–40, –50
–H
= 30µ" (0,76µm)
Gold on post
– 05
= Five Row
–K
=Polyimide Film Pick
& Place Pad
(–07, –09 and –12 only)
– 08
= Eight Row
(Lead styles
–07, –09 &
–12 only)
– TR
=Tape & Reel
(–07, –09 and –12 only)
Style –12 50x10 not
available
10
(No. of pins/row x (1,27) .050)
+ (2,54) .100
(1,27) .050
– 10
500
= Ten Row
LEAD
STYLE
– 07
– 09
(2,67)
.105
No. of
rows
x
(1,27) (3,94)
.050 .155
+
(3,05)
.120
01
491
A
(6,65)
.262
(8,64)
.340
(11,63)
.458
(18,62)
.733
(24,61)
.969
STACK HEIGHTS
YFT/YFW
MATED
HEIGHT
YFS
–12
–19
(1,27)
.050
–25
(0,41)
.016
DIA
HEADER/
STACKER
YFT-05*
YFW-07
YFW-09
YFW-12
YFW-19
YFW-25
MATED
HEIGHT
(5,00) .197
(7,00) .276
(9,00) .354
(12,00) .472
(19,00) .748
(25,00) .984
A
Processing conditions
will affect mated height.
* See YFT Series for
specifications
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(0,76) .030 DIA
WWW.SAMTEC.COM
