2 TO 26 GHz IMAGE REJECTION MIXERS/IF AMP INPUT
MODELS: IRA0226LC1A, IRA0226LC1B AND IRA0226LC1C
FEATURES
• RF/LO coverage ................ 2 to 26 GHz
• IF operation ....................... 20 to 200 MHz
• LO power range ................ +10 to +13 dBm
• Conversion gain ............... 23 dB typical
• Image rejection ................. 20 dB typical
Image rejection mixers are useful for wideband test equipment or ultra-broadband receivers requiring rejection of
an unwanted sideband of signal or noise following a low-noise front-end amplifier. The IRA Series of image rejec-
tion mixers has an integrated IF amplifier, thus making the overall sensitivity less dependent on the load noise. The
mixer/IF interface is also optimized for best 2RF-2LO spur performance.
ELECTRICAL SPECIFICATIONS
INPUT PARAMETERS
RF frequency range
RF VSWR (RF = -30 dBm, LO = +12 dBm)
LO frequency range
LO power range
LO VSWR (LO = +12 dBm)
DC power
IMAGE REJECTION MIXER PRODUCTS
CONDITION
UNITS
GHz
Ratio
GHz
dBm
Ratio
MIN.
2
2
+10
TYP.
2:1
MAX.
26
26
+12
2.5:1
75
+13
+15 VDC
CONDITION
RF > LO
RF < LO
mA
UNITS
dB
dB
dB
dB
dB
15
20
MIN.
20
TRANSFER CHARACTERISTICS
Conversion gain (Note 1)
Single-sideband noise figure
Image rejection (Note 1)
LO-to-RF isolation
LO-to-IF isolation
Output power at 1 dB compression
Output two-tone third-order intercept point
OUTPUT PARAMETERS
IF frequency range
TYP.
23
15
20
35
20
+10
+20
MAX.
LO = +13 dBm
LO = +13 dBm
CONDITION
IRA0226LC1A
IRA0226LC1B
IRA0226LC1C
dBm
dBm
UNITS
MHz
MHz
MHz
Ratio
MIN.
20
40
100
TYP.
MAX.
40
80
200
IF VSWR (IF = -30 dBm, LO = +12 dBm)
1.5:1
100 Davids Drive, Hauppauge, NY 11788 • TEL: (631) 436-7400 • FAX: (631) 436-7430 •
www.miteq.com
IRA0226LC1A TYPICAL TEST DATA
VSWR
(LO = +10 dBm)
0
IMAGE REJECTION
(LO = +10 dBm)
4:1
3:1
LO
IMAGE REJECTION (dB)
21.2
26
5:1
10
20
30
40
50
VSWR (RATIO)
2:1
1:1
2
6.8
RF
11.6
16.4
FREQUENCY (GHz)
2
6.8
11.6
16.4
FREQUENCY (GHz)
LO-TO-RF ISOLATION
(LO = +10 dBm)
21.2
26
CONVERSION GAIN
(IF = 30 MHz, LO = +10 dBm)
50
0
20
CONVERSION GAIN (dB)
40
ISOLATION (dB)
2
6.8
11.6
16.4
FREQUENCY (GHz)
21.2
26
30
20
10
0
40
60
80
100
2
6.8
11.6
16.4
FREQUENCY (GHz)
21.2
26
MAXIMUM RATINGS
Specification temperature .................. +25°C
Operating temperature ........................ -54 to +85°C
Storage temperature .......................... -65 to +125°C
GENERAL NOTE
1. Standard catalog unit aligned and tested for guaranteed
RF > LO performance. RF < LO guaranteed performance
is available, please contact MITEQ.
NOTE: Test data supplied at 25°C; conversion gain and LO-to-RF isolation.
OUTLINE DRAWING
TERMINATION (50 OHMS)
2.500 [63.50]
.500 [12.70]
RF>LO
IF OUT
RF CONNECTORS SMA FEMALE
(TYP. 3 PLACES)
IMAGE REJECTION MIXER PRODUCTS
.25 [6.35]
HAUPPAUGE, N.Y. 11788
MADE IN USA
1.000 [25.40]
LO IN
2.000
[50.80]
.25
[6.35]
1.000 [25.40]
1.625 [41.28]
1.750 [44.45]
M/N XXXXXX
S/N XXXXXX
RF IN
RF<LO
+VDC
MOUNTING HOLES .100 [2.54] DIA. THRU
TYP. 4 PLACES
.075 [1.91]
2.350 [59.69]
.240 [6.10]
.030 [0.76] DIA. X .250 [6.35] LG.
(TYP. 2 PLACES)
.25 [6.35]
.500 [12.70]
FINISH: NICKEL
NOTE: All dimensions shown in brackets [ ] are in millimeters.
100 Davids Drive, Hauppauge, NY 11788 • TEL: (631) 436-7400 • FAX: (631) 436-7430 •
www.miteq.com
